Table 1-5 Connecting the computer (continued)
Cables
(2) Mini DisplayPort cable
(3) USB cable
(4) RJ-45 (network) jack cable
(5) Power input (optional when a 10-pin cable is connected)
(6) Network jack uplink cable
Connecting to AC power (select products only)
An AC outlet is required for the HP Remote System Controller for Universal KVM (7K7N2AA) version of
the product. You must connect the AC adapter to an AC power source. When connected to power, the
AC power source provides up to 40 W of power through the power connector. The HP Remote System
Controller uses up to 18 W when all computer resources are in use, but typically idles at less than 5 W of
power.
WARNING!
● Plug the power cord into an AC outlet that is easily accessible at all times.
● Disconnect power from the equipment by unplugging the power cord from the AC outlet.
● If provided with a 3-pin attachment plug on the power cord, plug the cord into a grounded (earthed)
3-pin outlet. Do not disable the power cord grounding pin, for example, by attaching a 2-pin adapter.
The grounding pin is an important safety feature.
To ensure the correct performance of all features, connect the HP Remote System Controller to an AC
power source using the AC adapter.
1. Connect one end of the power cord to the AC adapter (1), and connect the other end of the power
cord to an AC outlet (2).
2. Connect the AC adapter to the power connector (3) on the HP Remote System Controller.
To reduce the risk of electric shock or damage to the equipment:
Connecting to AC power (select products only) 5
