QuickSpecs
Overview
The HP Smart Array P430 Controller is a low profile, PCIe3 x8, 12 Gb/s capable Serial Attached SCSI (SAS) RAID controller that provides
enterprise class storage performance and data protection for select HP ProLiant Gen8 rack and tower servers. It features eight internal
physical links and delivers increased server uptime by providing advanced storage functionality, including online RAID level migration
(between any RAID levels) with flash back write cache, global online spare, and pre-failure warning. Data compatibility between HP
Smart Array Controllers means customers can easily upgrade to future Smart Array Controllers.
What's New
HP Smart Array P430 controller with 4GB Flash Backed Write Cache kit with battery
HP Secure Encryption is supported on P430 as an option
12 Gb/s SAS performance when used on a DL580 Gen8 with 12 Gb/s devices (SSDs or HDDs)
Models
HP Smart Array P430
Controller
HP Smart Array P430/2GB FBWC 6Gb 1-port Int SAS Controller
HP Smart Array P430/4GB FBWC 6Gb 1-port Int SAS Controller
DA - 14624 Worldwide — Version 3 — March 31, 2014
HP Smart Array P430 Controller
698529-B21
698530-B21
Page 1
Advertisement
Related Manuals for HP Smart Array P430
Summary of Contents for HP Smart Array P430
- Page 1 Overview The HP Smart Array P430 Controller is a low profile, PCIe3 x8, 12 Gb/s capable Serial Attached SCSI (SAS) RAID controller that provides enterprise class storage performance and data protection for select HP ProLiant Gen8 rack and tower servers. It features eight internal physical links and delivers increased server uptime by providing advanced storage functionality, including online RAID level migration (between any RAID levels) with flash back write cache, global online spare, and pre-failure warning.
-
Page 2: Standard Features
Use of Smart Array products across multiple applications results in a Advantage much lower Total Cost of Ownership (TCO) than any other server storage RAID product. The HP Smart Array family brings an unparalleled return on investment through: Data Compatibility among most current shipping Smart Array controllers allows simple and easy upgrades any time as needs for higher performance, capacity, and availability increase. - Page 3 QuickSpecs HP Smart Array P430 Controller Standard Features Management Features Online array expansion Online capacity expansion Online logical drive extension Online RAID level migration Online stripe size migration Online mirror split, recombine and rollback Online and high performance offline Rapid Parity Initialization (RPI)
- Page 4 The following features offer detection of possible failures before they occur, allowing preventive action to be taken: S.M.A.R.T.: Self Monitoring Analysis and Reporting Technology first developed at HP detects possible hard disk failure before it occurs, allowing replacement of the hard drive before a real failure occurs.
- Page 5 With up to 4x better SSD read performance, HP SSD Smart Path chooses the optimum path to the SSD and accelerates reads for all RAID levels and RAID 0 writes. HP SSD Smart Path requires updated firmware, drivers, and configuration utility available at: www.hp.com/go/hpssa. HP SSD Smart Path is ideal for read intensive workloads and is included as a base feature on HP Smart Array P-series controllers.
- Page 6 Management Mode is for enterprise wide deployments and requires HP Integrated Lights Out (iLO) Advanced or Scale Out editions v 1.40 or later and HP Enterprise Secure Key Manager (ESKM) 3.1 or any later release. The HP ESKM manages all the encryption deployments from just a few servers to thousands of servers and 2 million keys per HP ESKM 3.1 cluster.
- Page 7 VMware ESXi 5.1 U1 VMware vSphere 5.5 NOTE: For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization Software and the latest listing of software drivers available for your server and Smart Array RAID controller, please visit our Support Matrix at: http://www.hp.com/go/ossupport...
-
Page 8: Service And Support
Protect your business beyond warranty with HP Care Pack Services When you buy HP Options, it's also a good time to think about what level of service you may need. HP Care Pack services provide total care and support expertise with committed response choices designed to meet your IT and business need. - Page 9 Now, you can get access to personalized IT support anywhere, anytime. HP Insight Remote Support and HP Support Center are available at no additional cost with a HP warranty, HP Care Pack or HP contractual support agreement.
-
Page 10: Related Options
HP 1TB 6G SAS 7.2K rpm LFF (3.5-inch) SC Midline 1yr Warranty Hard Drive 652753-B21 HP SAS Hot Plug Drives HP 900GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive 619291-B21 HP 600GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive 581286-B21 HP 450GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive... - Page 11 658071-B21 6G SATA Non-hot Plug LFF (3.5-inch) Midline (MDL) Drives HP 3TB 6G SATA 7.2K rpm LFF (3.5-inch) Non-hot plug Midline 1yr Warranty Hard Drive 628065-B21 HP 2TB 6G SATA 7.2K rpm LFF (3.5-inch) Non-hot plug Midline 1yr Warranty Hard Drive 659339-B21 HP 1TB 6G SATA 7.2K rpm LFF (3.5-inch) Non-hot plug Midline 1yr Warranty Hard Drive...
- Page 12 QuickSpecs HP Smart Array P430 Controller Related Options HP 200GB 12G SAS Mainstream Endurance SFF 2.5-in SC Enterprise Mainstream 3yr Wty 741138-B21 Solid State Drive 6G SATA ME Hot Plug SFF (2.5-inch) Enterprise Mainstream Solid State Drives HP 800GB 6G SATA Mainstream Endurance SFF 2.5-in SC Enterprise Mainstream 3yr Wty...
- Page 13 HP Internal SAS 68-pin SFF-8087 2x36-pin SFF-8087 Left Exit Cable 730603-B21 NOTE: This cable is for DL360p Gen8 and DL360p Gen8 SE SFF models. HP Smart Array P430 is supported in the x16 PCIe slot. See server QuickSpecs for details.
- Page 14 (Worldwide) For more information visit: www.hp.com/go/smartcache HP Secure Encryption NOTE: HP Secure Encryption licensing is based on the number of physical drives requiring encryption. HP Secure Encryption No Media E-LTU per Drive D8S85AAE HP Secure Encryption No Media Flexible License per Drive...
-
Page 15: Technical Specifications
