- Page 6 1. Insert 2 barrel nuts (#B) into the holes along each end of the side rails (#5, 6). Make sure the nut opening faces the holes. 2. Align the side rails (#5,6) to the holes along the lower end guardrails (#1, 2).
- Page 7 Align the guardrail supports (#11) to the holes along the guardrails. Insert 3 bolts (#E) into each and secure using the Allen wrench (#I). Insert a metal dowel (#G) into each hole along the top of the lower end guardrails. Carefully place the upper bed onto those dowels.
- Page 8 1. Insert the ladder rungs (#13,14) into the slots along the left and right ladder rails (#19,20). Insert a bolt (#C) into each end. Secure using the Allen wrench (#J). 2. Align the ladder rail support (#18) to the holes along the ladder rail (#20).
- Page 9 Align the support legs (#17) to the holes along the lower full slat kit (#20). Insert a screw (#I) into each from above. Secure using a Phillips screwdriver. Place the twin slat kit (#15) onto the top bed, then place the full slat kit (#16) onto the lower bed.
