- Page 7 2. Align each end of the upper head panel (#5) to the holes along the posts, then insert a bolt (#H) into each hole and secure using the Allen wrench. 1. Align and slide the lower head panel (#6) onto the post, then insert the bolts (#H) into each hole.
- Page 8 Align each end of the upper bed frame (#9) to the holes along the posts, then insert the bolts (#A) with metal plates (#20) into each. Secure using the Allen wrench. 2. Insert the bolts (#H) into the top holes and secure. 1.
- Page 9 Align the rear upper and lower tubes to the holes along the posts, then insert a bolt (#D) with washer (#L) into each end. Secure using the Allen wrench (#N). Align the back frame (#10) to the holes along the rear, then insert a bolt (#G) into each hole and secure.
- Page 10 1. Insert the wheel (#26) into the slots along the left seat (#13), then insert a bolt (#I) and a nut (#K). Secure. Insert bolts (#H) and secure. 2. Insert the threaded ends of the spring 3. Align the support tubes (#18) (#O) into the holes, to the holes, then insert the turn right to tighten.
- Page 11 Align the left and right seat (#13,14) to the holes along the panels, then insert the bolts (#B) and secure. Place the back cushions (#15) onto the panels, and secure.
- Page 12 Align the connect plate (#22) to the holes along the bottom, the insert the bolts (#H) and secure.
- Page 13 1. Align the support plate (#25) to the holes along the desk panel (#17), then insert the bolts (#C) and secure using the Allen wrench (#N). 3. Insert the bolts (#C) into the holes and secure. 2. Slide the desk panel (#17) into the slots. Align the extension tube (#19) to the holes, then insert the bolt (#I) and nut...
- Page 14 Align the ladder (#16) to the guardrail, then insert a bolt (#F) with washer (#L) into each hole. Secure.
