- Page 6 1. Insert 2 bolts (#A) into each side of the lower LEFT end guardrails (#1,2), then apply a barrel nut (#B) onto each bolt (#A). BACK 2. Place the lower front FRONT and back side panels RIGHT (#5,6) onto those bolts. Secure using the Allen wrench (#K).
- Page 7 1. Insert a wood dowel (#H) into one end of the front guardrails (#10), then insert into the top holes along the upper end guardrail (#3). Note: Make sure the bolts enter the nut. 3. Insert a wood dowel (#H) into the remaining ends of the front guard- rails (#10), then apply the guardrail bar (#12) onto those dowels.
- Page 8 Insert a metal dowel (#G) into each hole along the top of the bottom bed, then carefully place the top bed onto those dowels. Align the support woods (#18) to the rear holes, then insert 2 bolts (#D) into each and secure.
- Page 9 1. Insert each end of the ladder rungs (#16,15) into the slots along the ladder rails (#13,14). Note, ladder rung (#16) is placed on top and the rest are ladder rungs (#15). After that, insert a bolt (#C) into each end and secure. LEFT RIGHT 2.
- Page 10 Align the support legs (#19) to the holes along the full slat kit (#21), then insert a screw (#J) into each. Secure using a screwdriver. Place the twin slat kit (#20) onto the top bed and the full slat kit (#21) onto the bottom bed, then insert a screw (#I) into each hole and secure using a screwdriver.
