Assembly Instructions
CM-BK608T
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
assembling a specific product (with 1 being
(Included)
easy and 5 being difficult). For some
Phillips Screwdriver
products, two persons are recommended.
(Not Included)
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 10
Rev.14-09-24
Advertisement
Related Manuals for Furniture of America CM-BK608T
Summary of Contents for Furniture of America CM-BK608T
- Page 1 Assembly Instructions CM-BK608T ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 2 Page 2 of 10...
- Page 3 Before you begin, please read Page 2 for “Assembly and Care Advice” AND Page 10 for “Safety Warnings”. And remember, do not tighten until each step is completed or instructed. Parts List #1 x 2 pcs #2 x 1 pc Lower End G/Rail Upper Lt.
- Page 4 Due to the size and/or weight of this product, it is highly recommended that the assembly should be done near the area of its intended location. Make sure you have enough space to move around during the assembly. ALWAYS have at least two people to help with transporting and assembling the product to avoid any potential injury and/or damage.
- Page 5 Turn right (clockwise) to tighten #A x 8 pcs #B x 8 pcs Turn right (clockwise) to tighten #A x 12 pcs #B x 12 pcs #G x 8 pcs Page 5 of 10...
- Page 6 #A x 2 pcs #B x 2 pcs #C x 6 pcs #G x 4 pcs Turn right (clockwise) to tighten #H x 4 pcs Page 6 of 10...
- Page 7 Turn right (clockwise) to tighten #F x 8 pcs #E x 8 pcs Turn right (clockwise) to tighten Page 7 of 10...
- Page 8 #D x 6 pcs Turn right (clockwise) to tighten Turn right (clockwise) to tighten #F x 8 pcs Page 8 of 10...
- Page 9 Turn right (clockwise) to tighten #F x 8 pcs Safety is ALWAYS the main priority. Please take the time to inspect the assembly and FULLY tighten all bolts/screws. Read and follow the information on the WARNINGS shown on the end structure of the upper bunk and on the carton.
- Page 10 Safety Warnings for Bunk Beds Read and follow the information on the WARNINGS shown on the end structure of the upper bunk and on the carton. Do not remove warning label from the bed. Keep these instructions for future reference. IMPORTANT: Must use Bunkie mattress or Bunkie board.
