Hardware Part List:
Bow Assemblies (L&R) - Qty 2
Windshield Channel - Qty 1
Side Belt Rail (L&R)- Qty 2
Corner Belt Rail (L&R) - Qty 2
Tailgate Brackets w/screws (L&R) - Qty 2
Bow Conectors - Qty 2
Upper Door Windshield Insert (L&R) - Qty 2
Tailgate Bar - Qty 1
5/16" Torx Screws - Qty 12
5/16" Tapping Plates - Qty 12
5/16" Flat Washers -Qty12
#8x1/2" Pan Self Screws - Qty 10
#8x1/4" Tap Mod Screws - Qty 11
(Note: There maybe an extra hardware in package)
This Complete Soft Top Kit is designed to fit on your YJ Wrangler when the hard top or original soft top has
been completely removed. Before beginning your installation of this product, carefully remove your hard
NOTICE
top or current soft top hardware. During the installation of this product you will encounter several steps
that will require two people to properly install the hardware.
Loss of vehicle control involves risk of death or serious injury, particularly to parts of your body not
restrained within vehicle. This product is intended for weather protection only and should not be
WARNING
relied upon to contain occupants in the event of an accident or to protect from either ground contact
or falling objects. To reduce risk of accident or injury:
•
ALWAYS WEAR SEATBELTS
•
Always keep head, arms & body parts within vehicle.
•
Fully secure or stow the soft top before driving according to instructions. Never try to latch or
fold soft top while driving. Do not use if damaged or worn.
•
Read and follow all instructions & warnings accompanying this product, in your vehicle owner's
manual and Off Road Driving Supplement.
RISK OF EYE INJURY. Safety glasses should be worn at all times while installing or maintaining this
CAUTION
product.
Installation Instructions
Complete Soft Top Kit with Upper Doors
for 88-95 Jeep
Soft Part List:
Fabric Top - Qty 1
Quarter Window, Right - Qty 1
Quarter Window, Left - Qty 1
Rear Window - Qty 1
Upper Door Skin Right - Qty 1
Upper Door Skin Left - Qty 1
Door Frame Right - Qty 1
Door Frame Left - Qty 1
Wrangler YJ
®
Item
1560X1XX
#
Required Tools:
Safety Glasses
Phillips Head Screwdriver
#40 Torx socket and Driver pliers
Drill
1/8" Drill Bit (optional)
3/16" Drill Bit (optional)
Shoe horn or large Spoon
Razor Knife
Phillips Screw Driver
Large Beach Style
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for MasterTop 1560 1 Series
Summary of Contents for MasterTop 1560 1 Series
- Page 1 Installation Instructions Complete Soft Top Kit with Upper Doors for 88-95 Jeep Wrangler YJ ® Item 1560X1XX Hardware Part List: Soft Part List: Required Tools: Bow Assemblies (L&R) - Qty 2 Fabric Top - Qty 1 Safety Glasses Windshield Channel - Qty 1 Quarter Window, Right - Qty 1 Phillips Head Screwdriver Side Belt Rail (L&R)- Qty 2...
- Page 2 Before you begin Installation: We are excited that you have chosen the MasterTop Complete Soft top Hardware System. This high quality bow and door surround system is designed to provide a platform for the installation of a fabric soft top. Please note that it is important that you become familiar with the installation process of this top by reading the following instruction sheet and warnings thoroughly.
- Page 3 Installation of Soft Top Hardware Step 2B: Install Upper Door Windshield Inserts FIG 5 FIG 6 IIF you are installing soft top hardware for the first time, Locate the upper driver’s side upper door wind- shield insert and position it over the windshield flange lining up the horizontal reinforcement with the top of the flange.
- Page 4 Installation of Soft Top Hardware Step 5b: Tailgate Bracket Installation IF you are soft top hardware for the first time, Lo- Bracket should line up with FIG 13 cate the passenger and Drivers side Tailgate Brackets, inside edge of tailgate. (4) #10 - 24x ½”...
- Page 5 Installation of Soft Top Hardware Step 8b: Attach Bows to Side Belt Rails FIG 20 FIG 21 With the bow assemblies in place, insert the plastic locking tab over the windshield inserts large pin and slide the tab towards the rear of the vehicle locking the over door surround in place.
- Page 6 Installation of Soft Top Hardware Step 12: Secure the Front Bow Assembly FIG 29 FIG 28 Push the front bow assembly all the way forward into the notch found on the side belt rail. See Figs. 28 & FIG 30 Step 13: Install Rear Corners Make sure the white clear...
- Page 7 Step 18: Attach Side Curtains to Body Belt Rail FIG 38 FIG 39 While pulling down, slip the side curtain bottom retain- ing channel into the body belt rail starting from one end and pressing down to the other as shown in Figs 38 &...
- Page 8 Care and Maintenance of your MasterTop® Product: Your MasterTop Replacement Top is made of the finest materials available but to keep it looking new and for the maximum possible wear, it will need periodic cleaning and basic maintenance. The main threat to your soft top is...
-
Page 9: Limited 3 Year Warranty
Top branded accessories first sold in the United States, MasterTop warrants to the initial retail purchaser only that your MasterTop accessory shall be free of defects in material and workmanship; for a period of 3 years from date of initial retail sale.
