Parts List:
Top Deck - Qty 1
Driver Side Quarter Window - Qty 1
Passenger Side Quarter Window - Qty 1
Rear Window - Qty 1
Driver Side Over Door Bow - Qty 1
Passenger Side Over Door Bow - Qty 1
Center Bow Assembly - Qty 1
This Replacement Fabric kit is designed to fit on your Factory soft top installed 2 Dr Jeep
the original soft top rear bow assembly has been completely removed. Before beginning your installation
of this product, you will need to remove your existing soft top fabric and factory rear bow.
Loss of vehicle control involves risk of death or serious injury, particularly to parts of your body not
restrained within vehicle. This product is intended for weather protection only and should not be relied upon
to contain occupants in the event of an accident or to protect from either ground contact or falling objects.
To reduce risk of accident or injury:
RISK OF EYE INJURY. Safety glasses should be worn at all times while installing or maintaining
this product.
Installation Instructions
Installation Instructions
Replacement Soft Top for 2007-2018
2 Door Jeep
•
ALWAYS WEAR SEATBELTS
•
Always keep head, arms & body parts within vehicle.
•
Fully secure or stow the soft top before driving according
to instructions. Never try to latch or fold soft top while
driving. Do not use if damaged or worn.
•
Read and follow all instructions & warnings accompanying
this product, in your vehicle owner's manual and Off Road
Driving Supplement.
SkyMaster™ Fastback Fabric Only
®
Wrangler JK Item
Required Tools:
Safety Glasses
Phillips Screw Driver
Flat Head Screw Driver
Pliers
Large Towel
#
157013XX
®
Wrangler when
