MasterTop 15433301 Installation Instructions Manual

Complete Hardware Installed
with no Soft Top Material
Part List:
a) Header Assembly - Qty 1
b) Driver Side Over Door Bow - Qty 1
c) Passenger Side Over Door Bow - Qty 1
d) Center Bow Assembly - Qty 1
e) Center Bow Legs - Qty 2
f) Driver Side Door Surround - Qty 1
g) Passenger Side Door Surround - Qty 1
h) Door Surround Knobs Qty 4
i) Roll Bar Bow Mount Brackets - Qty 2
j) M6x20 Torx Bolts - Qty 4
k) Rear Bow Legs - Qty 2
l) Rear Bow -Qty1
m) Tailgate Bar - Qty 1
n) Tailgate Bar Brackets - Qty 2
o) 4mm Allen Key - Qty 1
This Replacement hardware is designed to fit on your 2 Dr Jeep® Wrangler when the original soft top
NOTICE
or hard top has been completely removed. Before beginning your installation of this product, you
will need to remove your existing soft top fabric, hardware or Hard top.
Loss of vehicle control involves risk of death or serious injury, particularly to parts of your
body not restrained within vehicle. This product is intended for weather protection only
WARNING
and should not be relied upon to contain occupants in the event of an accident or to pro-
tect from either ground contact or falling objects. To reduce risk of accident or injury:
• ALWAYS WEAR SEATBELTS
• Always keep head, arms & body parts within vehicle.
• Fully secure or stow the soft top before driving according to instructions. Never try to
latch or fold soft top while driving. Do not use if damaged or worn.
• Read and follow all instructions & warnings accompanying this product, in your vehi-
cle owner's manual and Off Road Driving Supplement.
RISK OF EYE INJURY. Safety glasses should be worn at all times while installing or main-
CAUTION
taining this product.
Installation Instructions
Replacement Soft Top Hardware for 2007-2018
a)
o)
h)
f)
Required Tools:
Safety Glasses
Phillips Head
Screwdriver
Socket wrench 10mm
T-30 Torx Driver
2 Door Jeep Wrangler JK
®
Item 15433301
#
e)
n)
g) d)
k)
c)
k)
j)
b)
i)
e)
m)
l)
n)
