Part List:
Top Deck/Header and Rear Bows assembly-QTY 1
Driver side quarter Window - QTY 1
Passenger side quarter window - QTY 1
Rear window - QTY 1
Center bow assembly- QTY 2
Driver side door surround- Qty 1
Passenger side door surround- QTY 1
Door surround Rubber - Qty 2
Door Surround Screws - Qty 4
Door surround knobs-QTY 8
Tailgate Bar - QTY 1
Tailgate Bar Corner Mounts - QTY 2
Corner Mounts short knobs - QTY 2
Rear bow screws & nuts - Qty 4
Rear bracket screws & nuts - Qty 2
Rear Main bracket screws and nuts - Qty 2
4mm Allen Wrench - QTY 1
Rear Main Bracket Screws M6 - Qty 4
5mm Allen Wrench - Qty 1
Loss of vehicle control involves risk of death or serious injury, particularly to parts of your body not
WARNING
restrained within vehicle. This product is intended for weather protection only and should not be relied
upon to contain occupants in the event of an accident or to protect from either ground contact or fall-
ing objects. To reduce risk of accident or injury:
•
ALWAYS WEAR SEATBELTS
•
Always keep head, arms & body parts within vehicle.
•
Fully secure or stow the soft top before driving according to instructions. Never try to latch or fold
soft top while driving. Do not use if damaged or worn.
•
Read and follow all instructions & warnings accompanying this product, in your vehicle owner's
manual and Off Road Driving Supplement.
RISK OF EYE INJURY. Safety glasses should be worn at all times while installing or maintaining this
CAUTION
product.
Installation Instructions
MasterTop Complete Soft Top for 18-Current
Jeep
JLU 4Dr. Wrangler
®
Item
156016XX
#
Required Tools:
Safety glasses
Socket wrench
10mm socket & driver
Phillips head screw driver
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for MasterTop 156016XX
Summary of Contents for MasterTop 156016XX
- Page 1 Installation Instructions MasterTop Complete Soft Top for 18-Current Jeep JLU 4Dr. Wrangler ® Item 156016XX Required Tools: Part List: Safety glasses Top Deck/Header and Rear Bows assembly-QTY 1 Socket wrench Driver side quarter Window - QTY 1 10mm socket & driver...
- Page 2 Important Safety information Your MasterTop® Complete Soft Top is intended to increase the utility and enjoyment of your off road capable vehicle. Before installation, please take a moment to review the following safety information and installation instructions. Important safety information is generally preceded by one of three signal words indicating the relative risk of injury.
- Page 3 Step 2: Rear Over Door Surround Assembly Locate the driver’s side rear over door assembly, the driver’s side Pillar assembly, The Rubber seal FIG 2 and the 4mm Allen head wrench (Fig 2). Passenger side Rear Over-Door On the driver’s side rear over door assembly, Passenger Front door surround Assembly there are two screws installed for shipping (Fig 3).
- Page 4 Step 4: Secure Front & Rear Door Surrounds to the Roll Bar Locate the two sets of screw knobs and the driver’s FIG 10 side front and rear door surrounds. There should be 2 sets four knobs. These knobs go on the front and rear holes of the Brackets pre- viously installed in step 3 on the door surrounds.
- Page 5 Step 6: Installing the Center Bow #1 & #2 Locate the center bow #1 (Fig 14). Each Bow has FIG 14 Center Bow #1 been labeled to make identification easier. Loos- Center Bow #2 en the screws holding on the top brackets. With the help of a friend, place the Quick release end on the bottom of the bow leg over the second ver- tical bracket (Fig 15).
- Page 6 Step 8: Installing the Deck and Front Windshield Header Continued The bow arms will install to the front bow mount FIG 19 brackets located on the top of the door sur- rounds. Loosen the bow mount brackets mounted on the door surround. With the help of a friend, lift each of the bow legs over the bow mount bracket (Fig 19).
- Page 7 Step 10: Installing the Rear Main Bracket to the Vehicle On the rear sport bar, pull off the plastic bracket FIG 27 FIG 28 that comes with the jeep, there is two metal clips that hold it in place (Fig 27). Line up the rear main bracket over the holes (Fig 28).
- Page 8 Step 12: Installing the Top Deck Once the rear bow is installed (Step 11), SLOWLY FIG 36 fold the front header down resting the windshield header on the windshield (fig 38). The first time you fold this header down it will be very tight. Make sure before you fold down the header that the front two header corner pockets are in place and not lifted up over the header.
- Page 9 Step 15: Insert the side corner window FIG 47a FIG 49 FIG 48 Corner support FIG 47 On the rear of the quarter window there is a corner support installed. The quarter window corner support will engage with the plastic piece up in the in the soft top (fig 47 & 47a). Once the upper is secure, in the bottom of this corner support is a tab that locks to the corner bracket mount installed in step 14, see Fig 48 &...
- Page 10 When removing the quarter and rear windows from the Top deck be sure to slide them out completely before pulling down. Disengage the side hook and loop before sliding the win- NOTICE dows out. DO NOT “Peel” the windows out! Failure to completely disengage the windows from the “C”...
- Page 11 Step 18: Securing the tailgate bar & rear window to the vehicle FIG 64 FIG 62 FIG 63 FIG 65 FIG 67 FIG 66 Take the tailgate bar and orient the “C“-Channel with the round seal facing down and slide the “C” Channel onto the rear window retainer as shown in FIG 62 &...
- Page 12 Using Your Complete Soft Top Continued Option #3 & #4 FIG 71 Fully Open Front and Rear Passenger “Sun Roof”: These options open both the front cab and rear cab portions of the top. This option requires you to remove the front header arms and the two bows from the bow mount brackets.
- Page 13 Using Your Soft Top Hardware Continued Fold Back down Feature Use and secure: FIG 75 To fold back down and secure, remove the rear Front Bow Center Bow #1 and quarter windows from your soft top. Unlatch Center Bow #2 the quick release knobs (both sides) from the front, Center #1, Center #2 bows (fig 75), unhook the pin securing the rear leg (fig 75a).
- Page 14 Care and Maintenance of your MasterTop® Product: Your MasterTop Fastback made of the finest materials available but to keep it looking new and for the maximum possible wear, it will need periodic cleaning and basic maintenance. The main threat to your soft top is pollutants, dirt and grime.
-
Page 15: Limited 3 Year Warranty
Top branded accessories first sold in the United States, MasterTop warrants to the initial retail purchaser only that your MasterTop accessory shall be free of defects in material and workmanship; for a period of 3 years from date of initial retail sale.
