StarTech.com H2MPV-MONITOR-MOUNT Quick Start Manual

Dual Monitor Desk Mount - Single Heavy-Duty Pole - Up to 49" 32:9 Monitors
Product ID
H2MPV-MONITOR-MOUNT
1
1
2
8
For additional self-service support options and community forums, please visit: www.StarTech.com/support
2
3
4
5
6
4
5
6
7
*Product may vary from image
Feature
• Use to mount a Monitor onto the Monitor Mount
1 VESA Plate • Features a Quick-Release design for mounting and
unmounting of the Monitor
2 • Secures the Monitor along the Pole
Monitor Mount
• Enables to pass-through Cables into the Pole
3
Pole Cap
• Composed of two halves that are press fitted onto the Pole
• Supports the weight of the Monitor while adjusting the
Monitor Mount around the Pole
• Set Screws secure it into place
4 Support Collar
Note: The Support Collar is not meant to solely support the
Monitor weight
5 Monitor Mount Lever • Use to tighten or loosen the Monitor Mount
6 • Route cables through the Pole for Cable Management
Cable Pass-Through Hole
• Enables to vary the height of the Monitors
7 Pole Assembly
• A single assembly composed of the Pole and Desk Clamp,
Upper
• Secures the Monitor Desk Mount to a desk or table
8
Desk Clamp, Lower • Adjustable height to match the thickness of the desk or table
• Supported thickness range of 1to 3.9-inch (25 to 100mm)
Package Contents
• Desk Clamp, Lower (A) x 1
• Pole Assembly (B) x 1
• Pole Cap (C) x 1
• Monitor Mount (D) x 2
• VESA Plate (E) x 2
• Support Collar (F) x 2
• M4x10mm Screws (G)x 8
• M4x16mm Screws(H) x 8
• 3/8" x 1/2" Screws (I) x 2
• Spacers (J) x 8
• M6 Hex Key (K) x 1
• M3 Hex Key (L) x 1
• Wrench (M) x 1
Quick-Start Guide
Function
Revision: October 24, 2024
