- Page 1 -- PFN-12 -- (12 FT FIELDPRO NETTING SYSTEMS) Installation Instructions Call Jaypro Sports Equipment at 1-800-243-0533 during regular business hours for technical support. www.jaypro.com Rev: A2 Page 1 of 9...
- Page 2 USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE HAZARDOUS. ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR REPLACEMENT, CONTACT YOUR DEALER OR JAYPRO SPORTS. * HARDWARE FOR IS FOR BOTH END UPRIGHTS AND INTERMEDIATE UPRIGHTS (NOT ALL HARDWARE WILL BE USED).
-
Page 3: Tools Required
TOOLS REQUIRED: (1) 3/8” Socket Wrench and Box Wrench (1) 7/16” Nut Driver (1) 9/16” Socket Wrench and Box Wrench (1) Cable Cutters (1) 15/16” Socket Wrench and Box Wrench SPECIAL NOTES: • Max spacing between uprights should not exceed 20 ft. •... - Page 4 Base Wheels: Install the bracket for the wheels onto the outside of the base frame. Use 3/8” x 1” long carriage bolt to attach wheel bracket. Use 5/8” hardware for installing the wheels to the plates as shown in Figure 2 WHEEL BRACKET 3/8"-16 HEX HD LOCKNUT 3/8"...
- Page 5 Install Upright Hardware: Assemble 3/8” eyebolt hardware & cord loop assembly hardware and upright cap onto the uprights as shown in Figure 3 & Figure 4. 3/8"-16 HEX HD LOCKNUT 3/8" FLAT WASHER BLACK PLASTIC CAP TOP OF UPRIGHT 3/8" FLAT WASHER 3/8"-16 x 3"...
- Page 6 Install Uprights: Before inserting the Uprights onto the base frame, check to make sure: 1. Note orientation (see Figure 5). 2. Assemble Uprights onto the base frame as shown (Figure 6). 3. Fill jugs with water. Cleat Intermediate Upright End Upright Eyebolt &...
- Page 7 Place jugs and fill with sand or water before installing net: Net: Lay the net out lengthwise, extending each end enough to make up the loop. Make up a loop, as shown in, on both ends of the cable. Attach a cable to both the top and bottom edges of the net using the cable ties (Figure 7).
- Page 8 Install Net: Lay the net sections out lengthwise along the base of the uprights. Attach D-Ring to the net at each intermediate upright location. Attach the snap hooks to each cable end and D- Ring. Slowly raise the net up, attaching the sliding cable loops to the net approximately center of the upright While raising the net, attach any net sections together using cable ties located about 12”...
-
Page 9: Maintenance
MAINTENANCE: • Before and after each season, thoroughly inspect the net for wear. Repair any holes to prevent them from getting wider. • Remove and store the net after the seasons use. • Remove and or lower and secure all netting if a major storm or extreme winds, in excess of 50 mph, are forecasted.
