OPERATION AND MAINTENANCE MANUAL
Power source
on the bottom
MYT-TR0320L-D
MYT-TR0830L-D
MYT-TR0205L-D
MYT-TR0103LF-D
MYT-TR1235LF-D
MYT-TR0205LF-D
MYT-TR2507L-D
DC-TYPE Automatic Non-Carbon-Brush Series
MYT-TR0320L-U
MYT-TR0830L-U
MYT-TR0205L-U
MYT-TR0103LF-U
MYT-TR1235LF-U
MYT-TR0205LF-U
MYT-TR2507L-U
SAING EI CORP.
https://www.mytorqtools.com
Power source
on the top
Y2F185A-3E-001
Advertisement
Table of Contents
Related Manuals for MYTORQ MYT-TR0320L-D
Summary of Contents for MYTORQ MYT-TR0320L-D
- Page 1 OPERATION AND MAINTENANCE MANUAL Power source Power source on the top on the bottom MYT-TR0320L-U MYT-TR0320L-D MYT-TR0830L-U MYT-TR0830L-D MYT-TR0205L-U MYT-TR0205L-D MYT-TR0103LF-U MYT-TR0103LF-D MYT-TR1235LF-U MYT-TR1235LF-D MYT-TR0205LF-U MYT-TR0205LF-D MYT-TR2507L-U MYT-TR2507L-D DC-TYPE Automatic Non-Carbon-Brush Series SAING EI CORP. https://www.mytorqtools.com Y2F185A-3E-001...
- Page 2 NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. SAING EI CORP. is not responsible for customer modification of tools for applications on which SAING EI CORP. was not consulted. WARNING Important safety information enclosed. Read all these instructions before placing tool in service or operation this tool and save these instructions.
-
Page 3: Important Safety Rules
Important Safety Rules WARNING! Read all instructions Failure to follow all instructions listed below may result in electric shock fire and/or serious injure. The term “power tool” in all of the warning listed below refer to your mains operated (corded) power tool or battery operated (cordless) power tool. - Page 4 d) Store idle power tools out of reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. Do not let visitors touch the tool or extension cord. All visitors should be kept away from work area. e) Maintain power tools.
- Page 5 Product Name Description Use Convenient Production Lines Able to Hook Hanging Device Balancers Work Together With Suspension Hook The Tools to be More Efficiently。 15 cm cord to connect to cable。 Fixed Bit Use。 Bit Sleeve for Hex Adjust torque Use。 Torque Adjusting Ring Fixed upside-underside housing and clutch Use。...
-
Page 6: Do Not Operate This Tool Without Protective Earth Connected
WARNING！ DO NOT OPERATE THIS TOOL WITHOUT PROTECTIVE EARTH CONNECTED Grounding Instructions 1、This tool should be grounded while in use to protect the operator from electric shock. NOTICE! To ensure the grounding result, the grounding conductor of the power cord must be well connected with the grounding terminal of power facility. This tool is equipped with grounding conductors. - Page 7 Operations Cautions 1) Before changing bits from MYT-TR Series screwdriver, make sure the Forward / Reverse switch stays at the middle position the screwdriver must be unplugged. 2) To avoid damaging the housing of screwdriver, do not allow chemicals get in touch with housing of screwdriver. Ex.: Acetone, benzene, thinner, trichloroethylene ketone, and other similar chemicals.
-
Page 8: Description Of Operation
CAUTION ● Do not drop or abuse the tool. ● Whenever a tool is not being used, position the Power Switch to the “middle” position and unplug the power cord. Description of Operation Attaching / detaching bit and bit type Push down the holder clamp by fingertip, and it will be unlocked. -
Page 9: Do Not Attempt To Repair This Electric Screwdriver
CAUTION 1. The use of other than genuine SAING EI CORP. replacement parts may Result in decreased tool performance and increased maintenance and may invalidate all warranties. 2. All repairs and maintenance of this tool and its word must be performed by an authorized service center. 3. -
Page 10: Specifications
Specifications MODEL (MYT-) TR0320 TR0830 TR0205 TR0103F TR1235F TR0205F TR2507 Input voltage (DC) DC 40V Power Consumption Torque (N.m) 0.3~2 0.8~3 1.2~3.5 2.5~7 1200 1200 3300 1700 1000 Unloaded Rotation Speed (R.p.m) ±10% 2475 1275 Repeatable Torque ±5% Accuracy (%) Torque Adjustment Stepless Machine... -
Page 11: Torque Adjustment Operation
Torque Adjustment Operation To adjust the torque on these screwdrivers. Proceed as follows: 1. Determine the torque output of the tool by checking a tightened Fastener with a torque wrench. 2. Increase or decrease the torque by rotating the Spring Adjusting Ring.
