- Page 1 Automatic Industrial Cordless Brushless Power Torque Screwdrivers Series OPERATION AND MAINTENANCE MANUAL MYBT-HD0320F MYBT-HD0830 MYBT-HD1545 MYBT-HD0206 Rechargeable -TYPE Automatic Brushless Series SAING EI CORP. https://www.mytorqtools.com Y2F227A-3E-001...
-
Page 2: Icon Instructions
Before you use the Cordless Screwdriver for the first time, it is essential to read and understand the manual completely (including the spare parts view). The term “Cordless Screwdriver” in all of the warning listed below refers to your main operated appliance. Icon Instructions 1. - Page 3 Warning Read all instructions and make sure the appearance of the device has no damage before you use it. Failure to follow all instructions listed below may result in electric shock fire and/or serious injury. 1. Keep the working area nice and clean. 1.1 Mess and dark areas may cause of accidents.
- Page 4 Cordless Tool Protections ▉Over electric current protection ▉Prevent from low power ▉Thermal Protector ▉Stall protection ▉Slow rotation protection ▉Reverse control protection ▉Battery Identification ▉Sleep & power saving mode Warning Do not attempt to repair or disassemble this cordless screwdriver, the warranty will be considered void.
-
Page 5: Insert Battery Steps
2. Follow below steps to correctly install & remove battery. Insert Battery Steps Remove Battery Steps (1) Take screwdriver (1) Press the release button and take it out of the and battery. Device. Battery Release Button (2) Insert the rechargeable battery into the device (2) Follow the arrow direction. -
Page 6: Function / Operating Introduction
Function / Operating Introduction Function Name Table Description Description Trigger Switch S Waist Hook Forward/Reverse Lever OK/NG/Power/Hi & Lo Indicating Light Bit Sleeve battery Torque Fixing Ring Driver Hook Torque Fixing Ring/Coupler... -
Page 7: Manual / Function
Manual / Function 1. Full Auto Shut-Off Screwdriver It stops automatically when the screw has been tightened up and reached the set-up torque level. The device will not cause damage of task since no continue running after screws are tightened. (1) Trigger Switch The LED lights are on when the trigger switch has been pressed about one-third down, and then the screwdriver starts functioning when the switch trigger has been pressed half way down;... - Page 8 (3) Bit Sleeve To Switch the bit and compatibility, pull the head of the type B screwdriver, and install the bit according to the diagram below, and push it in following the arrow indicated on the diagram. Pull the bit holder Insert the bit (4) Torque Adjustment Ring: Turn torque adjust ring counter clock wise to increase torque output, on the other hand decrease...
- Page 9 (7) OK/NG/Power/Hi& Lo Indicating Light Explanation Protection Explanation: The indicating LEDS will show Hi/Lo when push Forward/Reverse lever to the middle position. Speed can't be adjusted when temperature protection is activated. Please wait until temperature protection is deactivated. Release Screw Current switch to reaches set...
-
Page 10: Other Cautions
Other Cautions 1. The best condition of using the tool is under 8 hours a day, do not over loaded. cording to operating frequency and torque loaded; we suggest adding lubricating oils in clutch per 3-6 months, and kindly contact with distributor when product's maintenance. 2. -
Page 11: Specifications
Specifications MODEL ( MYBT-) HD0320F HD0830 HD1545 HD0206 INPUT VOLTAGE(DC) DC 10.8V hard joints 0.5-2 0.8-3 1.5-4.5 TORQUE soft joints (N.m) 0.5-1.6 0.8-2.4 1.5-3.6 2-4.8 80%↓ Torque accuracy (%) ±3% Torque adjustment Stepless Unloaded 2700 1400 Speed 1900 1000 (min )±10% Screw size Machine screw... -
Page 12: Torque Adjustment Operation
Torque Adjustment Operation To adjust the torque on these screwdrivers. Proceed as follows : 1. Determine the torque output of the tool by checking a tightened fastener with a torque wrench. 2. Increase or decrease the torque by rotating torque Adjusting Ring. Rotating the Ring clockwise to a higher number on the torque Scale increase torque output while rotating the Ring counterclockwise to a lower number decreases the torque output.
