- Page 1 OPERATION AND MAINTENANCE MANUAL MY2-EP0235L MY2-EP0507L MY2-EP0110L MY2-EP0235LS5 MY2-EP0235LS6 MY2-EP0235LS7 Ver. 4.0 MY2-EP0110P DC-TYPE Automatic Non-Carbon-Brush with Counter Series SAING EI CORP. https://www.mytorqtools.com Y2F141Q-12E-001...
- Page 2 NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. SAING EI is not responsible for customer modification of tools for applications on which SAING EI was not consulted. WARNING Important safety information enclosed. Read all these instructions before placing tool in service or operation this tool and save these instructions.
- Page 3 Important Safety Rules WARNING! Read all instructions Failure to follow all instructions listed below may result in electric shock fire and/or serious injure. The term “power tool” in all of the warning listed below refers to your mains operated (corded) power tool or battery operated (cordless) power tool.
- Page 4 d) Store idle power tools out of reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. Do not let visitors touch the tool or extension cord. All visitors should be kept away from work area. e) Maintain power tools.
- Page 5 WARNING！ DO NOT OPERATE THIS TOOL WITHOUT PROTECTIVE EARTH CONNECTED Grounding Instructions 1、This tool should be grounded while in use to protect the operator from electric shock. NOTICE! To ensure the grounding result, the grounding conductor of the power cord must be well connected with the grounding terminal of power facility. This tool is equipped with grounding conductors.
- Page 6 Operations Cautions 1) Whenever changing a bit, make certain the Forward / Reverse Switch is in the “OFF “position and tool is unplugged. 2) Do not allow chemicals such as acetone, benzene, thinner, trichloroethylene ketone, or other similar chemicals to come in contact with the screwdriver housing as damage will result.
- Page 7 Description of Operation Attaching / detaching bit and bit type Push up the holder clamp by fingertip, and it will be unlocked. Thus, the bit can be freely attached and detached (single finger notion type) select such a bit whose shank is equal to the size shown below. ...
- Page 8 CAUTION 1. The use of other than genuine KILEWS replacement parts may Result in decreased tool performance and increased maintenance and may invalidate all warranties. 2. All repairs and maintenance of this tool and its word must be performed by an authorized service center. 3.
- Page 9 Specifications MODEL (MY2-) EP0235L EP0507L EP0110L EP0235LS5 EP0235LS6 EP0235LS7 EP0110P Input voltage(DC) DC 24V OR 32V Power Consumption (kgf.cm) 0.2~3.5 0.5~7 1~10 0.2~3.5 0.2~3.5 0.2~3.5 2~10 (Lbf.in) 0.18~3.01 0.44~6.10 0.89~8.67 0.18~3.01 0.18~3.01 0.18~3.01 1.77~8.67 Torque (N.m) 0.02~0.34 0.05~0.69 0.10~0.98 0.02~0.34 0.02~0.34 0.02~0.34 0.2~0.98...
- Page 10 Panel Specifications Name Function Three-Color Light To Show operating is OK, N.G or in the mode condition. Panel To show set value, set screws number and other value Push five seconds: to disable COUNTING FUNCTION Power Switch CLEAR Push three seconds: CLEAR SELECT Key Push three seconds: Enter the system Up Key...
- Page 11 ※SELECT (P+UP Enter into Menu) Sr Key Function Set up Time Factory default Description Buzz Time/ Light Name and Value settings OKALL display mode _Y: Small loop；N: Big loop Y or N ※Auto learning mode “Ln” (S+P Enter into Menu) SL=SC=At=RC=SP=Ht=P Key Function Set up Time Factory default...
- Page 12 ※MY2-EP PCB has three kinds of signal, OKALL、NG、OK and is an open collector type. ※Output users need input voltage to drive the buzzer, the input voltage can’t be over DC24V 10mA. ※There is a new judgment which is the screwdriver will judge a N.G.in the case of there is a start signal and it is OFF before Lt. ※If operator controls these functions from PLC close short circuit will take 500ms at least.
- Page 13 ※LED light flash in simulate-learning.( means under simulate- learning condition), push P key to record value after simulate -learning. ) ※Has no use of screwdrivers: UP and push P key can set up waiting time. If three seconds are set, but no starting signal after set time, it will buzz. ※Push R key to restore to factory settings.
- Page 14 Torque Adjustment Operation To adjust the torque on these screwdrivers. Proceed as follows : 1. Determine the torque output of the tool by checking a tightened Fastener with a torque wrench. 2. Increase or decrease the torque by rotating the Spring Adjusting Ring. Rotating the Ring clockwise to a higher number on the torque Scale increase torque output while rotating the Ring counterclockwise to a lower number decreases the torque output.
