- Page 1 AXIAL FAN CHICO Users manual...
-
Page 2: Table Of Contents
Maintenance ......................16 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about purpose, technical details, operating principle, design, and installation of the CHICO unit and all its modifications. This exhaust fan MUST be installed by a Qualified Electrical Contractor in accordance with the local regulations, and all loc al, state and national electrical codes. - Page 3 This unit is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the unit by a person responsible for their safety. Children should be supervised to ensure that they do not play with the unit.
- Page 4 Connection to the mains must be made through a disconnecting device, which is integrated into the fixed wiring system in accordance with the wiring rules for design of electrical units, and has a contact separation in all poles that allows for full disconnection under overvoltage category III conditions.
- Page 5 The recommended installation height for the Chico 100, 125 and 150 mm, is 2.1 meters or higher from the floor.
- Page 6 All user’s manual requirements as well as the provisions of all the applicable local and national construction, electrical, and technical norms and standards must be observed when installing and operating the unit. Disconnect the unit from the power supply prior to any connection, servicing, maintenance, and repair operations.
- Page 7 efficient air flow. Do not sit on the unit and do not put objects on it. The information in this user’s manual was correct at the time of the document’s preparation. The Company reserves the right to modify the technical characteristics, design, or configuration of its products at any time in order to incorporate the latest technological developments.
-
Page 8: Delivery Set
Hazardous parts access and water ingress protection rating IP34. The fan is rated for operation at ambient temperatures ranging from +1 °C to +40 °C. The unit is rated as a Class II electrical appliance. Performance CHICO 100 CHICO 125 CHICO 150... -
Page 9: Mounting And Set-Up
Model А Capacity, m Noise, DBA, 3m CHICO 100 CHICO 125 CHICO 150 For fans with a non-return valve option, the overall length of the outlet pipe increases by 14 mm. The fan shown in the figures may slightly differ from your model, while the installation sequence is maintained. - Page 10 The fan mounting sequence is shown in figures.
-
Page 12: Electronics Operation Algorithm
ELECTRONICS OPERATION ALGORITHM The fan with the timer and the humidity sensor TH – the fan starts after the control voltage is supplied to the input LT or if indoor humidity level H exceeds the set point adjustable from ~60 % to ~90 %. After the control voltage is off or the humidity level has decreased, the fan will keep running within the time set by the ti mer ranging from 2 to 30 minutes. - Page 13 Wiring diagram for a fan CHICO. Wiring diagram for a fan CHICO 150 TH equipped with a humidity sensor. L(~) L (~) LT (ST) LT (ST) N (~) N (~) Terminal designations on wiring diagrams: – line – external switch –...
-
Page 14: Troubleshooting
TROUBLESHOOTING Problem Possible reasons Troubleshooting Make sure the power supply line No power supply. is connected correctly, otherwise When the unit is connected to power troubleshoot the connection error. mains, the fan does not rotate and does not respond to any controls. Internal connection fault. -
Page 15: Fanco Manufacturer Warranty - Warranty Against Defects
FANCO MANUFACTURER WARRANTY – WARRANTY AGAINST DEFECTS Fanco warrants this product against defects in manufacture and workmanship for a period of 2 years from date of purchase when installed for residential use. When installed in a commercial or other non-domestic application, Fanco warrants this product for a period of 3 months from date of purchase. -
Page 16: Maintenance
150LD K Chico 150 220-240 Vac 24 Watt 150LD TH K Chico 150 TH 220-240 Vac 24 Watt MAINTENANCE Disconnect the fan from power supply prior to maintenance and servicing operations. The fan surfaces must be regularly cleaned from dirt and dust. To clean the fan, use a soft cloth or a brush wetted in a mild detergent solution. Do not allow water or liquid... - Page 17 Sold by (name and stamp of the seller) Quality Inspector’s Stamp Purchase Date Manufacture Date...
- Page 18 Certificate of acceptance CHICO The fan is recognized as serviceable. Fanco01EN_16LD-01...
