Shenzhen Growatt New Energy Co., Ltd.
4-13/F, Building A, Sino-German (Europe) Industrial Park,
Hangcheng Blvd, Bao'an District, Shenzhen, China
T
+86 755 2747 1942
service@ginverter.com
E
en.growatt.com
W
GR-UM-449-A-01 (PN:044.0138001)
Installation
&
Operation Manual
NEO 1600M-X2
NEO 1800M-X2
NEO 2000M-X2
NEO 2250M-X2
NEO 2500M-X2
Advertisement
Table of Contents
Related Manuals for Growatt NEO 1600M-X2
Summary of Contents for Growatt NEO 1600M-X2
- Page 1 NEO 1800M-X2 NEO 2000M-X2 NEO 2250M-X2 NEO 2500M-X2 Installation & Download Manual Operation Manual Shenzhen Growatt New Energy Co., Ltd. 4-13/F, Building A, Sino-German (Europe) Industrial Park, Hangcheng Blvd, Bao'an District, Shenzhen, China +86 755 2747 1942 service@ginverter.com en.growatt.com GR-UM-449-A-01 (PN:044.0138001)
- Page 2 Important Notice Copyright © 2024 Shenzhen Growatt New Energy Co., Ltd. All rights reserved. No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photographic, magnetic or otherwise, without the prior written permission of Shenzhen Growatt New Energy Co., Ltd.
-
Page 3: Table Of Contents
Contents LED Indicator Status ..................26 Notes on this manual ..............1 Microinverter Replacement................27 1.1 Introduction......................1 6 Warranty................. 28 1.2 Target Group ......................1 1.3 Additional information ..................1 Decommissioning ..............29 1.4 Symbols in this document ................... 1 7.1 Removing the Microinverter ................ -
Page 4: Notes On This Manual
1.3 Additional information Risk of fire or explosion Find further information on special topics in the download area at en.growatt.com The manual and other documents must be stored in a convenient place and be Risk of burns due to hot surface available at all times. -
Page 5: Radio Interference Statement
Description receiver is connected. PV modules Keep a safe distance of at least 20 cm from the microinverter at all times. Growatt assumes no responsibility for compliance to EMC regulations for the Microinverter entire system. AC load circuit breaker Energy meter... -
Page 6: Installation Warnings
2.7 Declaration of conformity Ø Persons with limited physical or mental abilities may only work This product complies with the following regulations and requirements: with the Growatt Microinverter following proper instructions Electromagnetic Compatibility Directive:2014/30/EU (EMC) Ÿ and under constant supervision. -
Page 7: Product Description
3 Product description 3.3 Dimensions and weight 3.1 Overview 45mm 670mm 315mm 81mm Position Description Dimensions and weight AC cable Model Width (W) Height (H) Depth (D) Weight Antenna NEO 1600-2500M-X2 396 mm 270 mm 45mm 5.1kg Heat sink PV terminal 3.4 Highlights Back plate Ø... -
Page 8: Microinverter Installation
WiFi version: Growatt NEO Microinverter + WiFi Router Risk of burns due to hot enclosure parts LoRa version: Growatt NEO Microinverter + Shine WeLink + WiFi Router The Microinverter should be protected against accidental contact. The microinverter generates heat when it is in operation. Do Solar Panel not touch the enclosure of the device;... -
Page 9: Accessories
4.4 Selection of the Over Current Protection Device and the Cable 1. Growatt NEO Microinverters can be connected using the 12 AWG or 10 AWG AC trunk cable and the AC trunk connector. The limits on the number of Microinverters on each AC branch shown below should be strictly adhere to. - Page 10 We advise to install a RCD breaker only if it is required by the local recommended by your module racking vendor. electrical code. Growatt recommends the use of a type-A RCD breaker with a rated residual current over 100 mA.
- Page 11 Step 2 Ground the system 2. Loosen the three screws with the screwdriver, untighten the cap and remove the cable. a) The AC cable has an embedded earth wire, which might be sufficient to ensure proper grounding. b) In areas with special grounding requirements, external grounding can be done by grounding the screw hole on the handle.
- Page 12 3. Tighten all screws, and tighten the cap. Install the cover back to the Trunk b) Strip each cable to a length of 13 mm and crimp the E2508 cord end terminal connector. with the hxagonal wire crimper. Assign the L, N and PE cable to the corresponding slots, tighten the screws and assemble the connector.
- Page 13 Step 5. Create an Installation Map (Optional) b) Connect the AC end cable to the distribution panel, and wire it to the local grid a) Peel the removable serial number label from each Microinverter. network. c) Please fit the AC Trunk Port Cap on each vacant AC Trunk Port to keep them watertight and dustproof.
- Page 14 Step 6. Connect the PV Module Step 8. Set up the monitoring system 1. Download the APP If the DC cable is too short for installation, use the PV Extension Method 1: Scan the QR code. Cable to connect PV modules to the NEO Microinverter, otherwise Method 2: Search for ShinePhone in Apple Store or Google Play.
-
Page 15: Troubleshooting
5 Troubleshooting Event code Description Suggestion All faults will be reported to ShinePhone APP or Growatt Server 1.Check if the inverter is grounded Webpage. For details, please refer to Growatt Server Webpage. properly. NOTICE 2.Check the insulation of PV cables. -
Page 16: Inverter Faults
1s) The Microinverter is powered by PV modules. If the LED indicator is off, please check the DC side connection. If the connection is correct and the PV voltage is higher than 16V, contact your distributor or Growatt customer service. -
Page 17: Warranty
Close the branch circuit breaker and check the operation status of the replacement unit. e) Add the new device on the ShinePhone APP or the Growatt Server Webpage to update the relevant information. Replace the label with the serial number of the... -
Page 18: Technical Data
The storage temperature should be always between - tracker 40℃ and +65℃. Keep the storage relative humidity lower than 95%. Output data(AC) Ø After long-term storage, the local installer or personnel from Growatt service AC nominal power 1600W 1800W... -
Page 19: Dc Connector Info
Model Model 1600M-X2 1800M-X2 2000M-X2 2250M-X2 2500M-X2 1600M-X2 1800M-X2 2000M-X2 2250M-X2 2500M-X2 Specifications Specifications Overvoltage WiFi/LoRa Optional PV:II AC:III category Warranty:12/15years Yes/Optional Efficiency Max. efficiency 96.5% Wireless parameters(2.4GHz WiFi) CEC efficiency Wireless standard 802.11 b/g/n MPPT efficiency 99.5% Wireless frequency 2412-2472MHz Protection Maximum output... -
Page 20: Declaration Of Conformity
Restriction of Hazardous Substances Directive: 2011/65/EU(EU) and 2015/863 (RoHS) You can download the Declaration of Conformity at https://en.growatt.com/upload/file/EU_Conformity_Declaration_NEO_1600_250 0M_X2.pdf Shenzhen Growatt New Energy Co., Ltd. 4-13/F, Building A, Sino-German (Europe) Industrial Park, Hangcheng Blvd, Bao'an District, Shenzhen, China +86 755 2747 1942 service@ginverter.com...
