Growatt NEO 600M-X Quick Installation Manual

1 Overview
.
1.1
Microinverter Overview
B
A
Note:
1.This document is intended for use as a quick installation guide. For details, please refer to the Installation and Operation Manual.
2.Growatt shall not be liable for any damage caused by improper operations.
1.2
System Overview
Application Scenario 1: Multi-Microinverter system
(rooftop solar)
Solar Panel
Micro Inverter
Datalogger
Cloud Server
WiFi Router
Note:
1. Up to five microinverters can be connected to the ShineWeLink.
2. Position the ShineWeLink next to the router, but maintain a minimum distance of 0.5m to avoid distortion resulting from the
excessively strong signal.
3. Do not place the inverter, the router and the ShineWeLink on the same vertical line to avoid affecting the signal strength.
1.3
Accessories
Packing list
Microinverter
Note:
Please select the appropriate
accessories and tools based on the on-
site conditions.
C D E
AC Breaker
Distribution Panel
ShineServer Web
ShinePhone APP
Application Scenario 1: Multi-Microinverter system (rooftop solar)
Mounting
screw (M6/M8)
AC Trunk
End Cap
Quick Installation
Application Scenario 2: Single-Microinverter system (balcony solar)
Guide & Warranty
Card
Mounting
screw (M6/M8)
Male AC Sub
Connector
F G H
Application scenario 2: Single-Microinverter system
(balcony solar)
Solar Panel
Datalogger
Grounding PV Extension
screw (M4) Cable
AC Trunk AC Trunk
Port Cap Connector
PV Extension
Grounding
screw (M4) Cable
or
AC Cable
AC Adapter
(AWG 16/14)
Cable(EU）
NEO 600-1000M-X Microinverter
Quick installation Guide (LoRa)
Position
A
B
C
D
E
F
G
H
Micro Inverter
Cloud Server
WiFi Router
PV Connector
PV Terminal AC Sub Connector
Dust Plug Unlock Tool Removal Tool
or
AC Cable AC Bus Cable
(AWG 12/10) (AWG 12/10)
PV Connector
PV Terminal AC Sub Connector
Unlock Tool
Dust Plug Removal Tool
Description
AC drop cable
Heat sink
Antenna
PV terminal
LED
Back plate
Handle
Grounding hole
Power Grid
ShineServer Web
ShinePhone APP
AC Trunk Connector
Unlock Tool
