- Page 1 Quick Installation Guide EC700-ASL/EC710-ASL Fanless Embedded System www.dfi.com Package Contents 1 x System Unit © March 11, 2025 DFI Inc.
- Page 2 Product Overview X EC700-ASL Front View X EC710-ASL Front View COM3 ▲Storage LED ▼Reset Button COM2 Power Button COM1 Antenna Holes Quick Installation Guide | EC700-ASL / EC710-ASL...
- Page 3 X EC700-ASL Rear View X EC710-ASL Rear View DC In Line Out / Mic In LAN1/2 ( 2.5G ) COM4 / DIO LAN3 Grounding USB-C USB3.2 Type A COM3 Quick Installation Guide | EC700-ASL / EC710-ASL...
- Page 4 The 4 screws of the system are used to secure the cover to the chassis. Remove the screws and put them in a safe place for later use. Step 2: Lift up the cover to open the system. Quick Installation Guide | EC700-ASL / EC710-ASL...
- Page 5 The boards can be easily accessed after the chassis cover is removed. Installing an M.2 Card M.2 M Socket M.2 E Socket * Suggest PCIe Gen3 storage module with heatsink and thermal pad. M.2 B Socket Quick Installation Guide | EC700-ASL / EC710-ASL...
- Page 6 Screw tight the card onto the stand-off with a screw driver and a stand-off screw until the gap between the card and the stand-off closes up. The card should be lying parallel to the board when it’s correctly mounted. Quick Installation Guide | EC700-ASL / EC710-ASL...
- Page 7 2. Disconnect all power cords and cables. Step 1: There are antenna holes reserved on the front and back side of the system and covered by rubber plugs. Please remove the plug prior to installing an antenna. EC700-ASL EC710-ASL Quick Installation Guide | EC700-ASL / EC710-ASL...
- Page 8 Cable Antenna Connector Washer DFI reserves the right to change the specifications at any time prior to the product's release. This QR may be based on the product’s revision. For more documentation and drivers, please visit the download page at www.dfi.com/...
