Quick Installation Guide
EC70A-KU
Package Contents
Panel
Front View
Rear View
Antenna hole
Notes:
1.2.
This port can be in HDMI or DP++.
1.2. The HDMI is a DP++/HDMI combo port but can only transmit HDMI signals (unless wired as
a DP++ port). Please plug in an HDMI cable with the right orientation and alignment to avoid
damage to the connector. You should feel resistance (due to a pin on the right) if the cable is not
inserted correctly.
Aligning side
(left)
• EC70A-KU System Unit
• Mounting screws for SATA, Mini PCIe and M.2
• Extended power switch cable
Power Button (green)
Status LED (blue)
Reset Switch
COM 1
Remote Power Switch
Line-out
HDMI
COM 3
COM 5
Angled-corner
pin
COM 6
VGA
COM 2
USB 3.0
(2)
USB 2.0
Angled-corner
(up)
www.dfi.com
HDD LED
(blue)
COM 4
HDMI/DP
USB 2.0
15~36V
LAN 2
LAN 1
Align this edge with the
left side of the connector
(1)
SATA drive bay
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for DFI EC70A-KU6081-714
Summary of Contents for DFI EC70A-KU6081-714
- Page 1 Quick Installation Guide EC70A-KU www.dfi.com Package Contents • EC70A-KU System Unit • Mounting screws for SATA, Mini PCIe and M.2 • Extended power switch cable Power Button (green) Panel HDD LED Status LED (blue) (blue) COM 6 COM 4 Reset Switch...
- Page 2 Installing a SATA Drive The SATA drive bay can be easily accessed without opening the system. However, the system does not support hot-swapping hard drives; turn off the system first. Use the following procedure to install SATA HDD or SSD to the system: Locate the drive bay on the front panel and open it by uninstalling the screws.
- Page 3 Accessing the System Board The system board is equipped with 2 Mini PCIe slots: one full-size and one half-size slot. The full- size Mini PCIe slot supports PCIe and USB interfaces whereas the half-size Mini PCIe slot supports PCIe, USB and SATA interfaces (jumper switchable between PCIe and SATA). The PCIe sockets are located on the main board;...
- Page 4 11-12 On 11-12 On DFI reserves the right to change the specifications at any time prior to the product's release. This QIG may be based on editions that do not resemble your actual products. For the latest revision and more details of the installation procedure, please refer to https://go.dfi.com/EC70A-KU or scan the QR code on the right.
