- Page 1 Thermo Scientific Heracell VIOS 250i Heracell VIOS 250i LK Heracell Vios 250i CR Forma Steri-Cycle i250 Forma Steri-Cycle i250 LK Forma Steri-Cycle i250 CR Incubators Supplement to Operating Instructions 50144132 50162744, 50163129, 50144829, 50162762 and 50163206 50165514 A October 2021...
- Page 2 ® G-Rex is the Trademark of Wilson Wolf. Thermo Scientific is a brand of Thermo Fisher Scientific Inc. All other trademarks mentioned in the operating instructions are the exclusive property of the respective manufacturers. Thermo Electron LED GmbH Robert-Bosch-Straße 1...
-
Page 3: Table Of Contents
Design of the equipment ........................2 ................................2 Chapter 1 Scope of Delivery ....................... 1-1 Chapter 2 Installation .......................... 2-1 Chapter 3 Operation ..........................3-1 Chapter 4 Performance Hints ......................4-1 Chapter 5 Parts overview........................5-1 Chapter 6 Technical Data........................6-1 Thermo Scientific... -
Page 4: Preface
• Keep these supplement instructions and the related operating instructions close to the device so that safety instructions and important information are always accessible. Should you encounter problems that are not detailed adequately in these supplement instructions and the related operating instructions, please contact Thermo Scientific immediately for your own safety. Thermo Scientific... -
Page 5: Explanation Of Safety Information And Symbols
CAUTION Indicates a hazardous situation which, if not avoided, could result in minor or moderate injuries. CAUTION Indicates a situation which, if not avoided, could result in property damage. Note Is used for applicational hints and useful information. Design of the equipment container The shelves kit is designed for G-Rex 500 Thermo Scientific... -
Page 6: Chapter 1 Scope Of Delivery
Scope of Delivery 1 x 50166349 Bottom shelf 4 x 50166348 Split shelf 2 x 50166346 Guiding rail left 4 x 50166347 Guiding rail carrier 2 x 50166345 Guiding rail right 1 x 50166350 Reinforcement bottom shelf Thermo Scientific... -
Page 7: Chapter 2 Installation
Note The parts are delivered with a protective foil. To remove the protective foil more easily warm-up the parts slightly. Insert the guiding rail carriers • In the inner chamber there are intakes for 4 guiding rail carriers. Thermo Scientific... - Page 8 Installation • Place the guiding rail carrier in the lower intake. • Snap in or push in the guiding rail carrier in the upper intake. Thermo Scientific...
- Page 9 The longer end of the guiding rail should show to the rear side of the chamber. • Fit in the guiding rail in an angle, in the picture below a right side guiding rail is shown as an example. • Lift it upwards. • Press it downwards. Thermo Scientific...
- Page 10 Installation • The tongue/latch must snap in. • Repeat the above step for the other 3 guiding rails. The inner chamber with installed guiding rails. Thermo Scientific...
- Page 11 Installation Preparing the bottom shelf • The bottom shelf has a reinforcement. • Install the reinforcement into one slot. 50166350 50166349 • Press the reinforcement into the other slot, so it snaps in. Thermo Scientific...
- Page 12 • Insert the bottom shelf in an angle, so the shelf fits in. • Insert the split shelves in the middle guide rails, so the pin fits in the slot. slot • Insert the split shelves in the upper guiding rails. Thermo Scientific...
- Page 13 • Load the G-Rex container beginning at position 1 at the rear side of the inner chamber. • Then position G-Rex container number 2, so the flap is beside the air duct. • Load G-Rex container 3 and 4, so the flaps match as shown in the picture below. Thermo Scientific...
- Page 14 The containers should not touch the glass door. Please close the glass door in the first step very carefully to check if the arrangement fits and the glass door can be closed and secured by the glass door lock. Thermo Scientific...
-
Page 15: Chapter 3 Operation
Operation Note Shelves are not designed to be pulled out. Containers must be taken out individually. Thermo Scientific... -
Page 16: Chapter 4 Performance Hints
The temperature of the preheated container with medium must not be above the set incubator temperature, otherwise the usable space temperature may overshoot and a temperature alarm may occur. The customer must verify his application process himself. Thermo Scientific... -
Page 17: Chapter 5 Parts Overview
Part-No. Description 50166345 Support bar right VIOS 50166346 Support bar left VIOS 50166347 Supporting profile G-Rex VIOS 50166348 Small shelf G-Rex VIOS 50166349 Base shelf bottom G-Rex VIOS 50166350 Reinforcing strut VIOS 50166351 Spring for supporting profile VIOS Thermo Scientific... -
Page 18: Chapter 6 Technical Data
26 / 57.4 equal distribution on the shelf Maximum load capacity base shelf bottom G-Rex VIOS kg / lbs 13 / 28.7 Maximum overall device loading capacity, kg / lbs 65 / 143 equal distribution on the shelves Thermo Scientific... - Page 19 Thermo Scientific...
- Page 20 Thermo Scientific...
