Fenix GS Installation Instructions Manual page 26

Green: RF pairing mode
Green-flashing: check of pairing (sec. 4.4
Red/green flashing alternately: sensor reset
Red-flashing: no connection to Wifi box >2h
Short press: check of pairing (sec. 4.4
Longer press (3s): Timer mode control
Long press (5s): activation of RF pairing
Very long press (15s): reset of RF pairing (see
sec. 4.2)
Note: if the sensor is not paired with the Wifi box,
LED flashes red/green for 10s
Dead battery of the RF sensor is indicated by LED,
namely by slowly pulsating red light
Pairing is done by pressing the appropriate
button on the WiFi box of the panel, on the RF
sensor afterwards
On the Wifi box, press the ON/OFF button for
5s, the RF communication indicator goes green
Press the button on the RF sensor for 5s, the
LED turns green
After successful pairing, both LEDs will turn off
If more heating panels should be in a single
room, use only one panel with Wifi box and RF
sensor. Choose the other panels (max. 3) with
the V26 wireless receiver, they will be connected
to the Wifi box as subordinate heaters
Process of pairing the Wifi box with V26 receiv-
ers is the same as pairing with the RF sensor
By short pressing the button, the RF sensor
sends a signal, and the LED indicator flashes
green
The paired Wifi box responds with a short
green flash of the RF communication indicator
Note: if connection between the panel and the RF
sensor is lost for more than 2 hours in the MANU-
AL or PROGRAM mode , the controls have no
information about the current temperature in the
room. Wifi box is switched automatically to the
"protection mode", in which the panel delivers
only 20% of its power - heating for 2 minutes, off
for 8 minutes. The protection mode prevents
uncontrolled energy consumption, at the same
time the room is protected against frost
RF SENSOR
RF sensor
WIFI BOX
