Summary of Contents for Fenix GS
- Page 12 RF SENSOR WIFI BOX RF sensor...
- Page 17 Graphic instructions for mounting on the wall Graphic instructions for mounting on the ceiling Connecting to home Wi-Fi network Wifi Box control elements Using GS Wifi heating panels Modes for heating RF sensor (temperature sensor Description of RF sensor Reset of RF pairing...
- Page 18 switch this appliance on/off if it was placed or Glass is a fragile material, be careful during installed in its intended normal operating transportation, handling and assembly! position and if the children are supervised or Installation/removal of the panel may only be were instructed about safe use of the appli- performed by a qualified person.
- Page 19 Place the enclosed frame on the wall/ceiling, mark and drill the holes for the fixings Insert the fixings and fix the frame with the appropriate number of flat head screws Slide the panel onto the frame and unscrew the plastic rollers on the rear side of the panel so that it is firmly backed up against the wall/ ceiling If the panel has to be connected to the electri-...
- Page 22 The GS radiant panel falls into the category of controlled heaters. According to Commission Regulation (EU) 2015/1188, the controlled heaters must be controlled by external elec- tronic temperature regulation in the room with a weekly programme, which additionally con- tains at least one of the following functions...
- Page 23 Switching the panel on or off (see sec. 2.7 Starts RF pairing mode (see sec. 4.3)
- Page 24 Switching the panel on/off has a sound signal Two short tones when ON One long tone when OFF Not lit: the panel is switched off Red: the panel is on and heats Green: heated - the panel is on, but does not Wifi LED starts flashing red and blue alternate- heat ly, after releasing the button it starts flashing...
- Page 25 Start and end of the Holiday mode is set in the format: day:year + hour:min (step 15 min) When opening the menu for the Holiday mode, start on the current day and time, end +1 day +1 hour is offered automatically In the set time interval, the connected devices are assigned one of four modes Connected devices will switch to the OFF status...
- Page 26 If more heating panels should be in a single room, use only one panel with Wifi box and RF sensor. Choose the other panels (max. 3) with the V26 wireless receiver, they will be connected to the Wifi box as subordinate heaters Process of pairing the Wifi box with V26 receiv- ers is the same as pairing with the RF sensor Green: RF pairing mode...
- Page 29 LED indication of Wifi status Check your Wifi router. If it is OK, switch the Wifi box on the panel to the local mode, connect to the mobile The time period of lost connection application and check network with the Wifi router is 6 hours or settings more LED indication of Wifi status...
- Page 30 All products containing hydrofluoric acid or fluorine derivatives are prohibited, as they can destroy the coating and surface of the glass Clin - spray window cleaner (contains alcohol, Highly acidic and alkaline products are prohibit- manufactured by Henkel) ed, abrasive products are prohibited as well Vitro - industrial window and mirror cleaner (contains 2-butoxyethanol, manufacturer Am- stutz produkte AG)
- Page 40 RF SENSOR WIFI BOX RF sensor...
