Operating Guide | TechCase iC7
Operation
5
Operation Considerations
5.1
Consider these before operating the TechCase iC7:
1. Before powering up and operating the case, read the safety instructions and follow them.
2.
Before use, check visually that the case and its contents are not broken in any way.
3.
Make sure that the ambient conditions agree to the ones defined in
4. Place the case on a level and even surface, so that it cannot fall down during operation.
5. Remove the main cover of the case, but do not remove any other covers or dismantle the case.
6.
Do not power up the case if the cover of the case is on.
7.
During operation, the case can be horizontal (interface pointing upwards) or vertical (interface pointing to one side).
8. Make sure that the cabling of the case is routed so that there is no risk of tripping on them.
9.
Only keep the case powered up when using the case. Do not leave the case powered and unattended.
10.
After use, replace the cover on the case and make sure it is fastened properly.
Starting Up
5.2
1. Finish the cabling to TechCase iC7. See the instructions in chapter 4 Installation.
2. Switch the EMERGENCY STOP button to the OFF position (pulled up).
3.
Check that the selection switch for internal/external motor is in the correct position.
4.
If the drive in the case has been reset to factory default settings, follow the instructions in
5. To switch on the mains supply, push the ON button.
6.
Wait for the drive to start up.

When the drive is started, it takes a moment for the drive to be in Ready state, and for the control panel display to
change to the Home screen. The device is ready to use when the drive is in Ready state.
When the drive starts, an STO fault can be active. To disable the fault, switch down the SAFETY I/O switches INA+ and INB+ on
the I/O panel.
7.
Set the motor parameters for the internal or external motor.
If an external motor is used, check the motor parameter values from the motor nameplate.
Table 3: Motor Parameters for the Internal Motor
Index
4.2.2.1
4.2.2.2
4.2.2.3
4.2.2.4
4.2.2.5
Danfoss Drives Oy © 2024.09
Parameter name
Nominal power
Nominal current
Nominal speed
Nominal frequency
Nominal voltage
7.2 Technical Data.
5.4 Reset to Factory Default
Value
0.10
1.0000
2800
50.0
230.0
AQ433140445569en-000201 / 172K0364B |
Operation
Settings.
Unit
kW
A
RPM
Hz
V
