StarTech.com HB31C5A2CME Quick Start Manual

7-Port Industrial USB-C Hub - USB 3.2 10Gbps, ESD Protection
Product ID (HB31C5A2CME)
Product Diagram
Rear Side
1 2
4
Front Side
6
Component
1
DC Power Input
•
DC 2-Wire Terminal Block
2
•
Power Input
•
Screw Locking USB-C Host
3
Port
•
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
3
5
7
Function
Connect a +7~24 V DC Power Source
Connect a +7~24 V DC Power Source
Connect to a USB-C or USB-A Port on a Host
Computer
USB 3.2 Gen 2 (10 Gbps)
•
4 Power LED
•
5 Mounting Brackets
•
•
•
7x Screw Locking USB
6 Data/Charge Ports
(5x USB-A / 2x USB-C)
•
7
7x USB Port Status LEDs
Requirements
Host Computer
USB-C or USB-A Port
•
Mounting Tools (Optional)
Mounting Screws x 2
•
Phillips or Flat Head Screwdriver
•
Writing Utensil
•
Level
•
For the latest drivers, manuals, product information, technical specifications, and
declarations of conformance, please visit:
Package Contents
USB Hub x 1
•
3.3 ft [1 m] USB-C to USB-C Locking Cable x 1
•
3.3 ft [1 m] USB-A to USB-C Locking Cable x 1
•
Terminal Block Connector (Attached to the terminal block power adapter)
•
Terminal block Power Adapter (NA, JP, UK, EU, ANZ) x 1
•
Quick-Start Guide x 1
•
Quick-Start Guide
Indicates if the USB hub is receiving power
from either a USB Host or a DC Power Source
Solid Green - Receiving Power
•
Off - Not Receiving Power
•
Wall mount the USB Hub
Mount the USB Hub to the side/underside of
a Desk
Connect to USB-A and USB-C Peripherals
USB 3.2 Gen 2 (10 Gbps)
USB-A Ports Support BC 1.2 for up to 5
•
V/1.5 A (7.5 W) Charging
USB-C Ports Support up to 5 V/3 A (15 W)
•
Charging
Indicates if a USB Peripheral is Connected to
the Corresponding Port
Solid Green - USB Peripheral is Connected
•
Off - USB Peripheral is Not Connected
•
www.StarTech.com/HB31C5A2CME
Manual Revision: December 5, 2024
