StarTech.com P2CDD143-KVM-SWITCH Quick Start Manual

2-Port Dual Monitor KVM Switch - DisplayPort - 8K 60Hz – USB-C 10Gbps
Product ID
P2CDD143-KVM-SWITCH
Front
1 2
Rear
5
8 1
9
Component
1
USB HID Ports
2
USB Hub Ports
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
3 3 4
6 7
10 11 12 13
Function
Connect a Human Interface Device (HID) (e.g.
•
Keyboard, Mouse, Trackpad, Number Keypad, or
Drawing Tablet)
Connect a SuperSpeed USB 10Gbps Device
•
3 LED Indicators
4 Push Button Selector
5
Console DisplayPort Ports
6 PC 2 DisplayPort Inputs
7 PC1 DisplayPort Inputs
8
DC Power Input Port
9 Console Audio Port
PC2 USB-C Host
10
Connection
11 PC2 Audio Port
PC1 USB-C Host
12
Connection
13 PC1 Audio Port
Product Information
2
For the latest manuals, product information, technical specifications, and declarations of
conformance, please visit:
Package Contents
KVM Switch x 1
•
USB-C to USB-A 10Gbps Cable x 2
•
Universal Power Adapter (NA/EU/UK/ANZ) x 1
•
Set of Rubber Feet x 1
•
Quick-Start Guide x 1
•
PC LED: Solid Green when a Host Connection is
•
detected
PC LED: Blinking Green when a Host Connection
•
is not detected
Hub LED: Solid Red when the PC Port selected
•
Press the Button to switch between PC Ports
•
Connect to DisplayPort Inputs on two
•
DisplayPort Displays
Connect to two DisplayPort Output Ports on
•
PC2
Connect to two DisplayPort Output Ports on
•
PC1
Connect the supplied Universal Power Adapter
•
to power the KVM Switch
Green: Connect an Audio Device (e.g. Speakers
•
or Headset)
Provides pass-through and switching of PC
•
Audio Ports 1 - 2
Connect to a Computer with a USB-C 10Gbps
•
Port
Connect to an Audio Port on PC2
•
Connect to a Computer with a USB-C 10Gbps
•
Port
Connect to an Audio Port on PC1
•
www.StarTech.com/P2CDD143-KVM-SWITCH
Quick-Start Guide
Manual Revision: February 23, 2024
