UG_201602_PL30_xxx
XMC4800 Automation Board-V3
For XMC4000 Family
About this document
Scope and purpose
This document provides a hardware description of the XMC4800 Automation Board-V3 including schematics
and list of material. For fast software development you can find the mapping of XMC4800 functions to the on-
board components in various tables.
Intended audience
This document is intended for anyone who wants to develop software on the XMC4800 Automation Board-V3 or
wants to use this kit for evaluating and demonstrating the capabilities of the XMC4800 microcontroller in
combination with other Infineon Technologies products.
User guide
Please read the sections "Important notice" and "Warnings" at the end of this document
Rev. 1.2
www.infineon.com
2025-02-19
Advertisement
Table of Contents
Related Manuals for Infineon XMC4800 Automation Board-V3
Summary of Contents for Infineon XMC4800 Automation Board-V3
-
Page 1: About This Document
Intended audience This document is intended for anyone who wants to develop software on the XMC4800 Automation Board-V3 or wants to use this kit for evaluating and demonstrating the capabilities of the XMC4800 microcontroller in combination with other Infineon Technologies products. -
Page 2: Table Of Contents
XMC4800 Automation Board-V3 Table of contents Table of contents About this document ..............1 Table of contents . -
Page 3: Introduction
Microcontroller from Infineon Technologies AG. ™ It can be used with a wide range of development tools including Infineon’s free of charge Eclipse based IDE DAVE. The XMC4800 Automation Board-V2 is designed to evaluate the capabilities of the XMC4800 Microcontroller especially in EtherCAT slave applications in combination with other products of Infineon Technologies. -
Page 4: Key Features
XMC4800 Automation Board-V3 1 Introduction Key features The XMC4800 Automation Board-V2 has the following key features and components: ® ® • XMC4800 Microcontroller (ARM Cortex -M4 based), 144 MHz, 2048 kB Flash, 352 kB SRAM, LFBGA196 package • EtherCAT slave components: 2 EtherCAT PHYs, Magnetics and 2 RJ45 jacks •... -
Page 5: Block Diagram
8 x IN and 8 x OUT ™ • RGB LED, CAN RG LED, Reset Push-Button • Micro-AB USB Plug • CAN Transceiver with SUB 9 connector Figure 1 Block diagram of the XMC4800 Automation Board-V3 User guide Rev. 1.2 2025-02-19... -
Page 6: Hardware Description
XMC4800 Automation Board-V3 2 Hardware description Hardware description The following chapters provide a detailed description of the hardware and how it can be used. The hardware is depicted in Figure Figure 2 PCB of the Automation Board-V3 User guide Rev. 1.2... -
Page 7: Power Supply
The two PHY’s for the EtherCAT slave connection additionally require a 1,8V supply. This voltage is generated by an adjustable LDO from Infineon Technologies (IFX54441LDV). For the CAN transceiver 5V is generated by a step-up converter out of the 3,3V. Both, 5V and 3,3V availability are signalize with a second green LED, named VDD1.8V. - Page 8 XMC4800 Automation Board-V3 2 Hardware description Figure 4 RTC and Battery XMC pin functions ™ Note: In Board delivery no battery is included. A standard 1.6 to 2.5 m m thick by 12mm maximum 3,3V lithium coin cell shell be used.
-
Page 9: Ethercat Slave Interface
XMC4800 Automation Board-V3 2 Hardware description ® EtherCAT Slave interface ® ® ® XMC4800 offers the EtherCAT node integrated on an ARM Cortex -M controller. The XMC4800 Automation ® Board-V3 provides a full EtherCAT compliant slave node. In combination with the additional components like the ISOFACE standard industrial components like 24V I/O’s can be realized. -
Page 10: Ethernet Interface
™ CAN interface The XMC4800 Automation Board-V3 provides a CAN interface via a D-Sub DE-9 connector. Infineon’s high speed CAN transceiver IFX1051LE for industrial application supports 3.3V I/O logic and is suitable for 12V and 24V bus systems with an excellent EMC performance. The CAN bus (signals CANH, CANL) are terminated by a 120 Ohm. -
Page 11: Isoface ™ Interfaces
ICs with integrated isolation that improve reliability 5-times & cuts product ™ launch time by 50%. To minimize unscheduled down-times, ISOFACE sets a new standard in diagnostic ™ capabilities. For detailed information about Infineon ISOFACE devices please visit: www.infineon.com/isoface ™ 2.5.1 ISOFACE ™... -
Page 12: Optiga Trust ™ E Device
XMC4800 Automation Board-V3 2 Hardware description Figure 8 Mapping of ISOFACE In functions to XMC pin functions ™ ™ OPTIGA Trust E device ™ OPTIGA Trust E is a high-security solution for industrial automation systems, smart homes, consumer or ™... -
Page 13: External Memory's Devices
2 Hardware description External Memory’s devices The XMC4800 Automation Board-V3 supports two kind of external memory. An SDRAM is connected to the board to allow Applications which requires more than the available RAM memory on the XMC to store data or execute code out of this memory. -
Page 14: Pin User Header
6 Pin user header The XMC4800 Automation Board-V3 provides a 6 pin header with a USIC channel to extend the functionality in Application. For example a display could be connected. This USIC channel is shared with the SPI USIC channel of the FRAM. -
Page 15: User Rgb And Can Leds
XMC pin LED red P6.2 LED green P6.3 2.10 Debugging The XMC4800 Automation Board-V3 supports debugging via a 10-pin Cortex Debug Connector. To program and ™ debug the chip every standard ARM debugger can be used. 2.10.1 Cortex debug connector (10-pin) ™... -
Page 16: Reset
XMC4800 Automation Board-V3 2 Hardware description 2.11 Reset The reset pin (PORST#) of the XMC4800 is a bi-directional pin in open drain mode. An internal pull-up resistor keeps the PORST# pin high during normal operation. A low level at this pin will force a hardware reset. In case of a MCU internal reset the PORST# pin will drive a low signal. -
Page 17: Production Data
XMC4800 Automation Board-V3 3 Production data Production data This chapter covers schematics, board dimensions, component placement and the list of material. Schematics Figure 13 shows the schematics of XMC4800 Automation Board hardware version 2.1. User guide Rev. 1.2 2025-02-19... - Page 18 XMC4800 Automation Board-V3 3 Production data Figure 13 Schematic of the XMC4800 Automation Board-V3 User guide Rev. 1.2 2025-02-19...
- Page 19 XMC4800 Automation Board-V3 3 Production data Figure 14 Schematic of the XMC4800 Automation Board-V3 User guide Rev. 1.2 2025-02-19...
- Page 20 XMC4800 Automation Board-V3 3 Production data Figure 15 Schematic of the XMC4800 Automation Board-V3 User guide Rev. 1.2 2025-02-19...
- Page 21 XMC4800 Automation Board-V3 3 Production data Figure 16 Schematic of the XMC4800 Automation Board-V3 User guide Rev. 1.2 2025-02-19...
- Page 22 XMC4800 Automation Board-V3 3 Production data Figure 17 Schematic of the XMC4800 Automation Board-V3 User guide Rev. 1.2 2025-02-19...
- Page 23 XMC4800 Automation Board-V3 3 Production data Figure 18 Schematic of the XMC4800 Automation Board-V3 User guide Rev. 1.2 2025-02-19...
- Page 24 XMC4800 Automation Board-V3 3 Production data Figure 19 Schematic of the XMC4800 Automation Board-V3 User guide Rev. 1.2 2025-02-19...
-
Page 25: Components Placement And Geometry
XMC4800 Automation Board-V3 3 Production data Components placement and geometry Figure 20 shows the board dimensions and the placement of components on the PCB. Figure 20 Components placement and geometry User guide Rev. 1.2 2025-02-19... -
Page 26: List Of Material
XMC4800 Automation Board-V3 3 Production data List of material The list of material is valid for the Automation Board-V3 hardware. Table 7 List of material Value Device Reference designator NC7SZ125 NC7SZ125 SC70-5L NC7SB3157 NC7SZ157 SC70-6L ESD8V0L2B-03L ESD8V0L2B-03L TSLP-3-1 ISO1I813T ISO1I811T... - Page 27 XMC4800 Automation Board-V3 3 Production data Table 7 (continued) List of material Value Device Reference designator 6k81 1% R-EU_R0805 R0805 1.5k/0603 R-EU_R0603 R0603 10k 1% R-EU_R0603 R0603 10k/0603 R-EU_R0603 R0603 22R/0603 R-EU_R0603 R0603 56K/0603 R-EU_R0603 R0603 100R/0603 R-EU_R0603 R0603 R-EU_R0603 R0603 4.7k/0603...
- Page 28 XMC4800 Automation Board-V3 3 Production data Table 7 (continued) List of material Value Device Reference designator 10uF/10V C-EUC0805K C0805K 100nF/0603 C-EUC0603 C0603 2n2F/0603 C-EUC0603 C0603 10uF/50V/1210 C-EUC1210K C1210K 1uF/0603/X7R/50V C-EUC0603 C0603 22uF C-EUC0603 C0603 4u7 50V C-EUC1206 C1206 10nF C_0805...
- Page 29 XMC4800 Automation Board-V3 3 Production data Table 7 (continued) List of material Value Device Reference designator FIDUCIAL FIDUCIAL FIDUCIAL C-EUC1812 C1812 C-EUC0402 C0402 L_EU_L0603 L1608 R-EU_R0402 R0402 R-EU_R0603 R0603 R-EU_R0805 R0805 R-EU_R0402 R0402 R-EU_R0603 R0603 TPB1,27 TPB1,27 B1,27 PINHD-1X1 1X01 ...
-
Page 30: Revision History
XMC4800 Automation Board-V3 Revision history Revision history Document Date Description of changes revision ® 2023-09-23 The XMC EtherCAT Phys have been redesigned due to replacement of ™ the BCM5241XA1KMLG PHY through the ADIN1200 PHY. The redesigned PCB has got a new marking: XMC EtherCAT PHY Board- ™... -
Page 31: Disclaimer
Infineon Technologies, All Rights Reserved. of any kind, including without limitation warranties of Infineon Technologies’ products may not be used in non-infringement of intellectual property rights of any any applications where a failure of the product or third party.
