UG141448
BGT60LTR11SAIP EBG shield
XENSIV™ 60 GHz radar system platform
Board version V3.1
About this document
Scope and purpose
This user guide describes the function, circuitry, and performance of the XENSIV™ BGT60LTRS11AIP 60 GHz
radar electromagnetic band gap (EBG) shield. The shield provides the supporting circuitry to the onboard
BGT60LTR11SAIP
monolithic microwave-integrated circuit (MMIC), Infineon's 60 GHz radar chipset with
antenna-in-package (AIP). An EBG structure is added to reduce the impact of neighboring components,
resulting in a homogeneous field of view (FoV). This makes BGT60LTR11SAIP the appropriate choice for ceiling-
mounted applications. In addition to the autonomous mode configuration, the shield offers a digital interface
for configuration and transfer of the acquired radar data to a microcontroller board such as Radar Baseboard
MCU7.
Note:
The BGT60LTR11SAIP is a down-specified version of our
operating temperature range is reduced from -20 to +85°C towards -10 to +70°C.
Intended audience
The intended audiences for this document are design engineers, technicians, and developers of electronic
systems, working with Infineon's XENSIV™ 60 GHz radar sensors.
Reference Board/Kit
Product(s) embedded on a PCB with a focus on specific applications and defined use cases that may include
software. PCB and auxiliary circuits are optimized for the requirements of the target application.
Note:
Boards do not necessarily meet safety, EMI, quality standards (for example UL, CE) requirements.
User guide
www.infineon.com
Please read the sections "Important notice" and "Warnings" at the end of this document
BGT60LTR11AIP
radar sensor. The
Revision 1.00
2024-11-21
