- Page 1 M2401G 24 Port 20Gb/s InfiniBand Switch for the Dell M1000e Chassis User Manual Rev 1.0 Mellanox Technologies...
- Page 2 Copyright 2008. Mellanox Technologies, Inc. All Rights Reserved. Mellanox Technologies, InfiniScale other marks and names mentioned herein may be trademarks of their respective companies. M2401G 24 Port 20Gb/s InfiniBand Switch Document Number: 2948 Mellanox Technologies, Inc. 2900 Stender Way Santa Clara, CA 95054 U.S.A.
-
Page 3: Table Of Contents
M2401G 24 Port 20Gb/s InfiniBand Switch for the Dell M1000e Chassis User Manual Contents Contents About this Manual Revision History Chapter 1 Overview Chapter 2 Installation and Basic Operation 2.1 Switch Platform Hardware Overview 2.1.1 InfiniBand Connectors 2.1.2 Switch Status Lights 2.2 Switch Platform Installation and Operation... -
Page 4: About This Manual
• Mellanox Technologies Web pages: • Dell Support Web pages: Conventions Throughout this manual, the name M2401G and the term switch are used to describe the 24-port 20Gb/s InfiniBand switch for the Dell M1000e, unless explicitly indicated otherwise. Trademarks and Service Marks The following are Mellanox Technologies registered trademarks: ®... - Page 5 Table 2 - Switch Products Covered in this User’s Manual Product Number Description M2401G 24 Port 20 Gb/s unmanaged switch including 8 external ports for the Dell M1000e chassis. This product does not require Advanced Management. Mellanox Technologies Rev 1.0...
-
Page 6: Revision History
Revision History Table 3 - Revision History Table Date Revision Description June 2008 Rev 1.0 First Draft Rev 1.0 Mellanox Technologies... -
Page 7: Chapter 1 Overview
M2401G 24 Port 20Gb/s InfiniBand Switch for the Dell M1000e Chassis User Manual 1 Overview This User’s Manual provides an overview of the M2401G 24-port 20Gb/s InfiniBand switch for the Dell M1000e. The switch supports 16 switch ports towards the midplane and 8 external ports. In addition to supporting passive copper InfiniBand cables, the external ports can provide power for supporting active cables and optical cables through the use of media adapters. -
Page 8: Chapter 2 Installation And Basic Operation
2.1.1 InfiniBand Connectors InfiniBand connectivity has 8 CX4 microGiGa connectors through the front panel. The remaining 16 interfaces are through the AirMax Midplane Connector out the back of the switch. Figure 1 shows the front 8 ports. Each of the front panel connectors has two LEDs located next to the connector. The green LED, when lit, indicates that the InfiniBand driver is running and a valid physical connection between nodes exists. -
Page 9: Switch Status Lights
M2401G 24 Port 20Gb/s InfiniBand Switch for the Dell M1000e Chassis User Manual 2.1.2 Switch Status Lights The switch Status lights indicate whether the switch is receiving power from the chassis. This LED can be Blue or Amber. If it is blinking Amber it indicates a Fault. -
Page 10: Switch Platform Installation And Operation
The switch platform does not require any programming or configuration to operate as a basic Infini- Band switch and includes all of the necessary functionality to operate with external standard Infini- Band Subnet Management software. -
Page 11: Mechanical Installation
This equipment should be installed in compliance with local and national electrical codes. 2.2.2 Mechanical Installation These switches are hot pluggable. It is not necessary to power down the Dell Chassis to install a new switch or to replace and old switch with a new one. Mellanox Technologies... -
Page 12: Removing An Old Switch From The Chassis
This will keep the center of gravity as low as possible reducing risk of tipping. Note: IOMs are to be installed from right to left. 1. Follow the instructions in Section 5.2.2.1 or Section 5.2.2.2 to remove an old switch or a Blank cover plate. -
Page 13: Power Connections And Initial Power On
2.2.5 InfiniBand Optical Cable Installation M2401G switches will work with optical cables and media adapters. Insert the media adapter into the connector and then connect the optical cable to the media adapter. Make sure to close any locks on the cables and media adapters. -
Page 14: Chapter 3 Management Tools Overview
Note: Don’t forget to set the flag for IBspark when you install the MFT kit. Firmware for this switch can be updated by going to the site below and following the directions for burning new firmware. The latest firmware can be found at: http://www.mellanox.com/support/firmware_download.php... -
Page 15: Chapter 4 Troubleshooting
M2401G 24 Port 20Gb/s InfiniBand Switch for the Dell M1000e Chassis User Manual 4 Troubleshooting As soon as a switch is plugged in make sure that the power LED is on. The power LED for the switch does not come on: If the green Power LED is not on;... -
Page 16: Appendix A Specification
Appendix A: Specification Table 5 - M2401G Specification Data Physical Size: 1.16” H x 10.04” D x 10.73” W 29.45 mm X255.20 mm X 272.50 mm Weight: 1.5 Kg fully configured Mounting: Vertically mounted rack Power through: 1W per port... -
Page 17: Appendix B Mechanical Drawing
M2401G 24 Port 20Gb/s InfiniBand Switch for the Dell M1000e Chassis User Manual Appendix B: Mechanical Drawing Figure 4 Mechanical Drawing of the Switch Mellanox Technologies Rev 1.0... -
Page 18: Appendix C Emc Certification Statements
Appendix C: EMC Certification Statements C.1: FCC Statements (USA) Class A Statements: § 15.21 Statement Warning! Changes or modifications to this equipment not expressly approved by the party responsi- ble for compliance (Mellanox Technologies) could void the user's authority to operate the equipment. §15.105(a) Statement NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,... - Page 19 M2401G 24 Port 20Gb/s InfiniBand Switch for the Dell M1000e Chassis User Manual C.1.3 VCCI Statements (Japan) Class A Statement: (Translation - "This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio interference may occur, in which case the user may be required to take corrective actions.")
-
Page 20: Appendix D Infiniband Connector Pinout
Appendix D: InfiniBand Connector Pinout IBtxOp(3) IBtxOn(3) IBtxOp(2) IBtxOn(2) IBtxOp(1) IBtxOn(1) IBtxOp(0) IBtxOn(0) Rev 1.0 Figure 5: InfiniBand CX4 Connector Pinout IBtxIp(3) IBtxIn(3) IBtxIp(2) IBtxIn(2) IBtxIp(1) IBtxIn(1) IBtxIp(0) IBtxIn(0) Mellanox Technologies Table 6 - Connector Pin Name and Numbe Name Correspondence Connector Pin Connector Pin Number... -
Page 21: Appendix E Local Authorization Form
M2401G 24 Port 20Gb/s InfiniBand Switch for the Dell M1000e Chassis User Manual Appendix E: Local Authorization Form Mellanox Technologies Rev 1.0... - Page 22 Rev 1.0 Mellanox Technologies...
