A1.10 - Cyclic timer off time/interval between scans:
If A1.01 = ON (on/cyclic): Time that the auxiliary output will be off;
If A1.01 = HOT (heating thermostat): It is the time interval between the temperature scan
triggers.
Note: This function can be turned off by setting it to the minimum value OFF.
A1.11 - Maximum time for auxiliary 1 output on without reaching the setpoint (A1AL):
It is the time that the auxiliary output can remain on without reaching the auxiliary 1
temperature setpoint. If this time is exceeded, alarm A1AL is activated and the output is
turned off, turning on again after the time in A1.12 has elapsed.
Note: This function can be turned off by setting it to the minimum value OFF.
Note: This function is active if A1.01 = HOT (heating thermostat).
A1.12 - Auxiliary 1 output time off by alarm A1AL:
Time that the controller will remain with the auxiliary output off while in the A1AL alarm state.
After this time has elapsed, new checks are carried out and the auxiliary output is activated
again.
Note: This function is active if A1.01 = HOT (heating thermostat).
A1.13 - Auxiliary 1 connection type:
It allows turning off auxiliary output 1 according to the status of the other outputs:
OFF = coupling disabled, auxiliary output 1 operates independently of other outputs;
1 = Turns off auxiliary 1 output when the pump is on;
2 = Turn off auxiliary 1 output when auxiliary 2 is on;
3 = Turns off auxiliary 1 output when pump or auxiliary 2 is on.
A2.01 - Auxiliary 2 operating mode:
Sets auxiliary 2 operating mode:
OFF = off; HOT = heating thermostat;
ON = on / cyclic; REF = refrigeration thermostat.
A2.02 - Auxiliary 2 reference temperature sensor:
Choose the temperature sensor that will be used to control auxiliary 2.
A2.03 - Manimum temperature setpoint for auxiliary 2 allowed to the user:
A2.04 - Maximum temperature setpoint for auxiliary 2 allowed to the user:
These parameters serve as lower and upper setting limits for parameter A2.SP. They are
used to lock the temperature setting to the end user to restrict an inappropriate setting. For
example, a high value can keep the auxiliary output on for a long time, resulting in high energy
consumption.
A2.05 - Auxiliary 2 temperature setpoint:
Sets the desired control temperature for auxiliary 2.
A2.06 - Auxiliary 2 temperature setpoint Economic:
Sets the desired temperature for auxiliary 2 when economizer mode is activated. One
possible application for economy mode is use on underfloor heating, in order to keep the floor
preheated and allow for rapid heating of the space when necessary.
Note: Eco mode is activated by configuring the event schedule.
A2.07 - Auxiliary 2 operating hysteresis:
Temperature difference to turn on the auxiliary output. Through this function it is possible to
define a temperature range within which the output will remain off.
For example: If A2.SP = 45 and A2.07 = 1, are set, the auxiliary output will turn off when
the temperature reaches 45°C and turn on again when it drops below 44ºC.
A2.08 - Auxiliary 2 manual activation time:
Used when the user wants to eventually activate the auxiliary output outside the scheduled
times in the event schedule. During this time, the auxiliary output is controlled according to its
operating mode, for example, linked to the temperature if A2.01 = HOT (heating
thermostat) or REF (cooling thermostat). From manual activation, after the time
programmed in this parameter has elapsed, the auxiliary mode returns to AUT (automatic)
mode.
Note: This function can be turned off by setting it to the minimum value OFF.
A2.09 - Cyclic timer on time / scan time (recirculation):
If A2.01 = ON (on / cyclic): Time that auxiliary output 1 will be on.
If A2.01 = HOT (heating thermostat: Time in which the controller will keep the water
circulation activated to equalize the water temperature in the barrel.
Note: This function can be turned off by setting it to the minimum value OFF.
A2.10 - Cyclic time off time / interval between scans:
If A2.01 = ON (on / cyclic): Time the auxiliary output will be off.
If A2.01 = HOT (heating thermostat): It is the time interval between the temperature scan
triggers.
Note: This function can be turned off by setting it to the minimum value OFF.
A2.11 - Maximum time for auxiliary 2 output on without reaching the setpoint (A2AL):
It is time that auxiliary output can remain on without reaching the auxiliary 2 temperature
setpoint. If this time is exceeded, the A2AL alarm is activated and the output is turned off,
turning on aganin after the time in A2.12 has elapsed.
Note: This function can be turned off by setting it to the minimum value OFF.
Note: This function is active if A2.01 = HOT (heating thermostat).
A2.12 - Auxiliary 2 output time off by alarm A2AL:
Time the controller will remain with the auxiliary output off while in the A2AL alarm state.
After this time has elapsed, new checks are carried out and the auxiliary output is activated
again.
Note: This function is active if A2.01 = HOT (heating thermostat).
A2.13 - Auxiliary 2 connection type:
It allows turning off auxiliary output 2 according to the status of the other outputs:
OFF = coupling disabled, auxiliary output 1 operates independently of other outputs;
1 = Turns off auxiliary 2 output when the pump is on;
2 = Turns off auxiliary 2 output when auxiliary 1 is on;
3 = Turns off auxiliary 2 output when pump or auxiliary is on.
IN.01 - Digital input signal type:
Defines the type of digital input signal:
0 = pulse - NO contact; 2 = switch - NO contact;
1 = pulse - NC contact; 3 = switch - NC contact.
IN.02 - Digital input operating mode:
Defines the digital input operating mode:
OFF = Digital input disable;
1 = Toggles between Pump OFF (off) and AUT (automatic);
2 = Toggles between Pump OFF (off) and MAN (manual);
3 = Enable/disable auxiliary 1 MAN (manual) mode;
4 = Enable/disable auxiliary 2 MAN (manual) mode;
5 = Enable/disable auxiliary 1 and auxiliary 2 MAN (manual) mode;
6 = Enable/disable Holidays mode;
7 = External alarm.
SE.01 - T1 sensor indication Offset:
SE.02 - T2 sensor indication Offset:
SE.03 - T3 sensor indication Offset:
SE.04 - T4 sensor indication Offset:
Allows you to compensate for possible deviations in the reading of the T1, T2, T3 or T4
sensors resulting from change of the sensor or the change in the cable length.
Note: Sensors T3 and T4 can be disabled by setting this function to the value
OFF.
GE.01 - Controller power-on delay (initial delay):
Initial delay time to activate the control outputs. By programming a delay time in this
parameter, it is possible to avoid high demand peaks in the electrical energy return, causing
the output to be activated a few seconds after the energy is restored.
GE.02 - Buzzer mode:
Choose when the controller will make sounds:
OFF = buzzer disabled;
1 = when pressing keys;
2 = when pressing keys and when alarms occur.
GE.03 - Preferred indication:
Allows you to choose the information that will normally be shown on the display:
TIME = clock;
T1 = collector temperature (T1);
T2 = temperatura of the thermal reservoir (T2);
DIF = temperature differential (T1 - T2);
T3 = support temperature (T3)(if enabled SE.03);
T4 = support temperature (T4)(if enabled SE.04).
GE.04 - Display brightness intensity:
Sets the display brightness intensity operating mode:
ON = display always on at maximum intensity;
ECO = output indication off and low brightness display after 5 minutes idle.
GE.05 - Function lock mode:
Enables partial or total locking of functions adjustment:
OFF = Blocking disabled: access to parameters released for adjustment;
1 = Controller: partial locking / APP: lock disabled;
2 = Controller: full lock / APP: lock disabled;
3 = Controller: lock disabled / APP: partial locking;
4 = Controller: lock disabled / APP: full lock;
5 = Controller: partial locking / APP: partial locking;
6 = Controller: full lock / APP: full lock.
Full lock: all parameters locked.
Partial locking: controller allows changing user parameters.
GE.06 - Time for function lock:
Defines the time that the key must be pressed to lock/unlock parameter changes.
