1. DESCRIPTION
TIC18Ri
The is a digital thermostat for easy installation and implementation. It can be configured for
both heating and cooling. It has a internal rechargeable battery, buzzer (audible alarm) and a output for
dialer to indicate lack of energy, temperature outside the range or sensor not working. Allows
configuring two setpoints (primary and secondary) and recording the maximum and minimum
TIC18Ri
temperatures registered. allows deactivating the outputs manually using the key.
2. APPLICATION
• Boilers
• Ovens
• Heaters
• Freezers
• Counters
• Refrigerated balconies
3. TECHNICAL SPECIFICATIONS
- Power supply: TIC-18Ri -115 or 230 Vac (50/ 60 Hz)
TIC-18RiL -12 or 24Vac/dc
- Control temperature: -50 to 105 °C / -58 to 221°F
-50 to 200°C / -58 to 392°F (*)
- Buzzer run time when the power source is absent:
- Resolution: 0.1ºC (between -10 and 100 ºC) and 1 ºC in the rest of the range /1°F in all range
- Load current: THERM: 16(8)A/ 250Vac 1HP
ALARM: 3Aresistive
- Dimensions: 71 x 28 x 71 mm
- Operation temperature: 0 to 50 ºC / 32 to 122°F
- Operation humidity: 10 to 90% RH (without condensation)
This instrument can measure and control up to 200ºC temperatures, since used with silicone cable
sensor (ex.: SB59).
4. CONFIGURATIONS
4.1 - Control temperature adjust (SETPOINT):
1 Setpoint ( disabled)
- Press SET for 2 seconds and will appear.
- Wait 2 seconds and the adjusted control temperature will appear.
- Use SET to change the value.
- Wait 4 seconds to record and return to the normal operation.
2 Setpoints ( enabled)
Adjust the setpoints primary and secondary in the advanced menu.
4.2 - Setpoint exchange
- With enabled, press SET for 2 seconds and it will appears the current setpoint (
when the key is released the setpoint is changed.
4.3 - Acces code
To enter the access code:
- Press SET or 4 seconds to appear
- Wait 2 seconds and it will appear .
- Use the SET key to insert the code .This operation must be performed within 4 seconds,
otherwise the ambient temperature indication automatically returns.
After entering the access code:
- Press SET as many times as necessary until you reach the desired parameter.
- Wait 2 seconds and then appears the adjusted value.
- Use the SET key to modify the value.
- Wait 4 seconds until the new value is recorded and the instrument returns to normal operation
(temperature display).
Note: After entering the access code, be careful not to leave the
between parameter changes for more than 15 seconds.
If this happens, the message will be displayed and the access to the adjust mode is automatically
blocked, requiring entering the code again to make any changes.
4.4 - Unit selection (°C/°F)
To define the unit that the instrument will operate,
- Press for 4 seconds, it will appear
SET
- Wait 2 seconds and will appear .
- Use the SET key to insert the code
otherwise the ambient temperature indication automatically returns.
After entering the access code:
- It will apperas the indication followed by the atual unit (
- Use the key to change the unit. This operation must be performed within 4 seconds After
SET
configuring the unit, appears and the ambient temperature indication automatically returns.
Every time that the unit is changed, the parameters should be reconfigured, since they assume the
"standard" values.
4.5 - Manual outputs disable
Press SET for 10 seconds, then appears the current status(
SET
the status exchange occurs.
In the Off state, the display shows and the temperature alternately.
Note: The is not counted when the device returns from the
- Instrument working normally
- THERM andALARM outputs OFF
TIC-18Ri
DIGITAL THERMOSTAT WITH
LACK ENERGY ALARM AND
OUTPUT FOR DIALER
Ver.02 Ver.02
Approximately 10 hours
.
SET SET key idle (without being pressed)
.
. This operation must be performed within 4 seconds,
or )
ou ), when you release the key
state.
4.6 - ALARM output inhibition
Press for 12 seconds it will appears
SET
inhibition occurs.
TheALARM output returns to normal operation after leaving the alarm condition or instrument restart.
4.7 - Maximum and minimum temperatures register
Press SET quickly, it will appears the minimum followed by the maximum temperature value
registered. If you hold the key
it will appears
4.8 - Parameters table
The parameters are protected by an access code (except the setpoint), which must be entered for that
can make changes.
Configuration parameters protected by access code:
Fun Description
Temperature Setpoint (main)
Control differential (main)
Operation mode
Minimum delay to turn on the THERM output
Offset (local calibration)
Minimum adjustment of temperature setpoint
Maximum adjustment of temperature setpoint
Enable buzzer (audible alarm)
Minimum differential to activate alarm
Maximum differential to activate alarm
Alarm inhibition time in the energization
ALARM output pulse time
Time between each ALARM output activation.
State of THERM output with sensor not working
Enables secondary setpoint and differential
Temperature Setpoint (secondary)
Control differential (secondary)
With disabled, the parameters
menu. In this case, only the main setpoint and differential will be used and the setpoint adjustment is
made through the facilitated menu.
With disabled, the parameters
menu an the facilitated menu allows selecting the primary and secondary setpoints.
ou ),
4.8.1 - Parameters description
Value of main setpoint for temperature control
It is the difference of principal temperature (hysteresis) between turn on and turn off the THERM
control output.
This function allows to configure the operation mode of the instrument (heating or refrigerating).
It is the minimum time that the controller output will keep turned off. This delay starts when the
output is turned off and also when the instrument is powered on.
Indication displacement. It allows compensate eventual shunt in the temperature reading.
Allowed range to the final user to adjust setpoint (minimum locking).
Allowed range to the final user to adjust setpoint (maximum locking).
This function allows enabling or disabling the buzzer.
When the temperature reaches the setpoint minus this value the alarm goes on.
When the temperature reaches the setpoint plus this value the alarm goes on.
Inhibition time for the buzzer and ALARM output when the controller is powered on.
ALARM output pulse time. If set to zero the output keeps continually ON.
Time between eachALARM output activation.
State of THERM output with sensor not working. The output inhibition takes priority over this
parameter.
This function allows to enable the secondary setpoint.
Value of secondary setpoint for temperature control.
Difference of secondary temperature (hysteresis) between ON and OFF the THERM control
output.
5. SIGNALLING
THERM - Turned on NO contact
- Sensor disconnected or temperature out of range;
- Outputs manually disabled
.
Buzzer - Lack of energy, temperature out of operating range or sensor error;
Buzzer activation type and time interval indicate the following situations:
- Device not powered: 2 beeps every 3 seconds;
- Sensor not working or temperature out of range: 1 beep per second;
. when the key
pressed when the maximum and minimum values being displayed,
SET
and the values are restarted.
CELSIUS
Min Max
-50 200
0.1 20
0-refrig. 1-heat.
0 999
-5.0 5.0
-50 200
-50 200
0-disab. 1-enab.
0.1 20
0.1 20
0 999
0 999
1 999
0-disab. 1-enab.
0-disab. 1-enab.
-50 200
0.1 20
, and are not shown in the advanced navigation
, and are not shown in the advanced navigation
is released the output ALARM
SET
FAHRENHEIT
Unit Default Min Max Unit Default
-4
°F
°C -20 -58 392
4
ºC 2.0 1 36 ºF
0-refrig.
- 0-refrig. 0-refrig. 1-heat. -
0
sec. 0 0 999 sec.
0
ºC 0 -9 9 ºF
-58
ºC -50 -58 392 ºF
221
ºC 105 -58 392 ºF
0-disab.
- 0-disab. 0-disab. 1-enab. -
9
°C 5 1 36 °F
9
ºC 5 1 36 ºF
120
min. 120 0 999 min.
60
sec. 60 0 999 sec.
60
sec. 60 1 999 sec.
0-disab.
- 0-disab. 0-disab. 1-enab. -
0-disab.
- 0-disab. 0-disab. 1-enab. -
°F 50
°C 10 -58 392
4
°C 2.0 1 36 °F
