1. DESCRIPTION
The Microsol BMP Advanced
solar heating with up to four sensors and four outputs, one of which is analog, that control the
water circulation pump and thermal supports. It features a clock and event scheduler for the
rational and economical use of thermal supports, as well as an exclusive Vacation function
that adds protection and energy savings to the (SHS) Solar Heating System during periods of
low hot water consumption. The controller has functions that prevent overheating and
freezing of water in the solar collector, in addition to protecting the access to settings.
A Microsol BMP Advanced
enabling data transfer for system configuration and diagnostics via the exclusive Microsol
. .
It is characterized by its distinctive design for residential environments, ease of operation
with touch keys for easy access to the controller's main features, and the use of a customized
display.
2. APPLICATION
- Solar heating with auxiliary heating system.
3. TECHNICAL SPECIFICATIONS
Power
Consumption
Operating temperature
Operating humidity
Sensors
Important notice: only the T1, T2 and T3 sensors come with
the product. The T4 sensor can be purchased separately.
Control Temperature
0,1ºC between -10 and 100ºC and 1ºC in the rest of the range
Resolution
0,1ºF between -10 and 100ºF and 1ºF in the rest of the range
PUMP -
Control output
Digital input
PWM / 0-10V output
Dimensions
Wi-Fi
Compatibility
Security protocols
Modes
PCB antenna
BMP Advanced
www.gov.br/anatel
AVAILABLE ON
WIFI is a differential thermostat for
WIFI line includes Wi-Fi technology,
100-240Vac (50/60Hz)
0 to 50°C (32 a 122°F)
10 to 90% UR (without condensation)
T1: Solar Collector – Sensor SB59, white cable, Silicone, 1m
T2: Thermal reservoir – Sensor SB19, 2,5m
T3: Support – Sensor SB19, 2,5m
T4: Support – Sensor SB19, 2,5m
Sensor T1: -20 to 200ºC / -4
Sensor T2: -20 to 105ºC / -4 to 221ºF
Sensor T3: -20 to 105ºC / -4 to 221ºF
Sensor T4: -20 to 105ºC / -4 to 221ºF
Relay output , m x . 1HP a at 220Vca (½ HP
AUX 1 - Relay output , m x . 16A, 3500W a resistor at 220Vca
(1750W at 127 Vca)
AUX 2 - Relay output, max . 5A, 1100W resistor at 220Vca
(630W at 127 Vca)
WARNING: The sum of the loads must not exceed 24A.
Configurable dry contact type
PWM: 20mA / 500Hz / 10V
AN: 0 - 10V / 10mA
Configurable PWM output for 0 - 10V
104 x 160 x 34mm
(4.09" x 6.30" x 1.34")
IEEE 802.11 b/g/n Single-band 2.4GHz
WPA / WPA2 / WPA3 Personal, TLS, SSL
Access Point Mode (AP), Station Mode (STA)
Operating Frequency: 2400~2500MHz
2,51dBi (2450MHz)
DIFFERENTIAL THERMOSTAT
WiFi
4. INDICATIONS
4.1 INTERFACE
1. Display
2. Pump Indication
3. Auxiliary 1 Indication
4. Auxiliary 2 Indication
5. Auxiliary 1 Key
6. Auxiliary 2 Key
7. Up Key
8. Down Key
9. PUMP Key
10. SET Key
4.2 OUTPUT STATUS INDICATION
Each controller output has a colored LED to indicate the state and mode of the output. The
LED color indicates the selected mode for the output. A flashing LED indicates that the output
is on.
5. WI-FI FUNCTIONALITY
5.1 OPERATION MODES
The Microsol BMP Advanced
Station Mode (STA) and Access Point Mode (AP).
Station Mode (STA): This is the default operation mode of the controller. It functions as a
Wi-Fi client, searching for and connecting to the previously configured local Wi-Fi network by
user.
Access Point Mode (AP): It functions as a Wi-Fi access point, allowing the user to connect
and enter local network settings into the controller via the Microsol
While the controller is in AP mode, the status indication LEDs will flash sequentially in blue.
The device will provide a Wi-Fi network with the following settings:
5VA
Note: XXXX are the last four digits of the controller ID.
The controller ID is a 20-character combination (letters and numbers) in the format
snXXXXXXXXXXXXXXXXXX.
or by pressing the
5.2 WI-FI STATUS INDICATION
By pressing the
to 392ºF
operation are displayed:
at 127 Vca)
FOR SOLAR HEATING
Ver. 01
1
2 3 4
5
Output status of LEDs:
• OFF = OFF
• Green = Automático (AUT)
• Yellow = Manual (MAN)
• Yellow/White = Manual in WEEKEND mode
WIFI, has two operation modes:
SSID: BMP_WIFI_XXXX
Password: fullgauge
The ID can be found on the label on the back of the controller
key, see item 6.5.
key até until the WiFi message appears, the status LEDs for Wi-Fi
All OFF = Controller cannot connect to the Wi-Fi network, or network not
configured in the controller;
Blue = connected to the Wi-Fi network;
Blue = connected to the internet;
Blue = sending and receiving data;
Blue = flashing sequentially, indicates AP mode;
7
5 9
6 10
8
Microsol BMP Advanced WiFi
app.
