Summary of Contents for Gorenje GGI6C21XA
- Page 1 INSTRUCTIONS FOR USE FREE STANDING COOKER...
- Page 2 The appliance has to be connected in compliance with the effective regulations, and it may only be used in well ventilated areas. Read the instructions before connecting or using the appliance. For more detailed instructions and tips, please visit http://www.gorenje.com or scan the QR code on the rating plate.
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Carefully read the instructions and save them for future reference. This appliance may only be used by children aged 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if supervision or instructions are provided to them concerning use of the appliance in a safe way and if they understand the hazards involved. - Page 4 Make sure the lid is clean and that there is no liquid spilt on it before raising it. The lid may be lacquer-coated or glass. It may only be closed when the cooking zones have completely cooled down. CAUTION: This appliance is for cooking purposes only. It must not be used for other purposes, for example room heating.
- Page 5 Prolonged intensive use of the appliance may call for additional ventilation, for example opening of a window, or more effective ventilation, for example increasing the level of mechanical ventilation where present. This is a class 1 and 2/1 appliance. The appliance may touch the adjacent cabinets on both sides when placed in a row.
-
Page 6: Before Connecting The Appliance
BEFORE CONNECTING THE APPLIANCE Carefully read the instructions for use before connecting the appliance. Repair or any warranty claim resulting from incorrect connection or use of the appliance shall not be covered by the warranty. -
Page 7: Free Standing Cooker
FREE STANDING COOKER Appliance description INFORMATION! Appliance functions and equipment depend on the model. 1 lid 2 cooking hob 3 control unit 4 lighting 5 guides – cooking levels 6 rating plate 7 oven door 8 door handle 9 drawer/flip down 10 plinth 11 adjustable feets Electrical parameters (depending on the model, see appliance data plate) -
Page 8: Before Using The Appliance For The First Time
WIRE GUIDES The wire guides allow preparation of the food on four levels (please note that the levels/ guides are counted from the bottom up). Guides 3 and 4 are intended for grilling. Appliance operation is safe with and without tray guides. TELESCOPIC PULL-OUT GUIDES Telescopic pull-out guides may be fitted for the 2nd, 3rd, and 4th level. -
Page 9: Control Unit
CONTROL UNIT 1. Cooking zone knob front left 2. Cooking zone knob rear left 3. Cooking zone knob rear right 4. Cooking zone knob front right 5. Oven lighting knob 6. Cooking system selector knob 7. Electronic program timer ELECTRONIC PROGRAM TIMER SWITCHING ON AND SETTINGS After connecting your appliance to the power mains or after an extended power outage, 0.00 will appear on the display. -
Page 10: Selecting Additional Functions/Extras
Cancelling a timer setting Use the key to select the burner. Then, use the key to set the time to 0.00. In this case, the burner will continue to operate without any timer setting. Setting the oven gas burner timer Use this function to set the duration of cooking only for the lower oven burner. - Page 11 Using the timer in combination with oven or burners When using the timer in combination with the oven, first turn on the oven and set the desired cooking system and temperature. Then, set the timer functions. When the food is done, turn off the oven and the cooking zones. COOKING HOB (depending on the model) 1 cooking zone rear left...
-
Page 12: Energy Saving Tips
Burner type Container diameter Large (3,0 kW) 220-260 mm Normal (1,9 kW) 180-220 mm Auxiliary (1,0 kW) 120-180 mm Multi-ring burner (3,6 kW) 220-260 mm ENERGY SAVING TIPS • If the cooking process allows, use a lid. • Cookware should be suitably sized given the amount of food. When you cook a small amount of food in a large pot or pan, more energy is lost. -
Page 13: Choosing The Cooking System
OVEN (depending on the model) CHOOSING THE COOKING SYSTEM Rotate the knob (left and right) to select the cooking system Settings can also be changed during the operation. The gas supply to the oven burner is controlled by a tap protected with a thermoelectric flame sensor. IGNITION OF THE OVEN BURNER Press the knob and rotate it to the left to the maximum power position. - Page 14 After ignition, keep the knob depressed for 5 more seconds until the flame is stabilized. During operation, the infrared oven heater is not temperature-controlled and it operates with full power. When ignited grill burner oven door should be open. After 2 minutes, the oven door is closed. Grill baking then continues behind closed doors.
-
Page 15: Maintenance And Cleaning
When grilling in a baking tray, make sure there is enough liquid in the tray to prevent burning. Turn the meat during cooking. Grilling with the oven door shut. After grilling, clean the oven, the accessories, and the utensils. Cooking with the rotisserie (depending on the model) Insert the skewer support into the 3rd guide from the bottom and place the shallow baking sheet into the bottom... -
Page 16: Gas Burner
Enamel surfaces (oven, cooking hob) Use a damp sponge with detergent for cleaning. Fatty stains can be removed with warm water and special detergent for enamel. Never clean enamelled surfaces with abrasive means producing irremovable damage to the appliance surface. Glass surfaces Do not use rough abrasive cleaning agents or sharp metal scrapes for cleaning of oven door glass, as they could crack the surface and causing the breaking of glass. -
Page 17: Replacing The Bulb
REPLACING THE BULB The bulb is a consumable and therefore not covered by warranty. Before changing the bulb, remove the trays, the grid, and the guides. Disconnect the appliance from the power mains! Undo the bulb cover and pull out or undo the bulb. Halogen lamp: G9, 230 V, 25 W. (regular bulb E14, 230 V, 25 W - depending on the model) Use protection to avoid burns COMFORT DOOR CLOSING... -
Page 18: Removing And Inserting The Oven Door Glass Pane
REMOVING AND REPLACING THE OVEN DOOR (depending on the model) • Open the oven door (up to end position). • Raise up and turn the flaps. • Slowly close the oven door, lift it slightly and pull it out from the both hinges of the appliance. Provide these steps in reverse order at returning the door back. - Page 19 Provide these steps in reverse order at returning the glass pane back. Repair or any warranty claim resulting from incorrect connection or use of the appliance shall not be covered by the warranty. In this case, the user will cover the cost of repair. INSTALLATION AND CONNECTION INSTRUCTIONS APPLIANCE PLACEMENT (mm) (depending on the model)
- Page 20 C) Ajusting the height of the cooker (depending on the model) The height of the cooker is 900 mm. You can adjust the height of the appliance from 850 to 940 mm. Torx T20 • Put the cooker on the floor with back side. •...
-
Page 21: Connecting To The Power Mains
INSTALLATION OF THE LID (depending on the model) INSTALLATION OF THE DOOR LOCK (depending on the model) CONNECTING TO THE POWER MAINS Make sure the power cord is not located near hot parts and sharp edges. If the power cord is damaged, it should be replaced by the manufacturer or an authorized service technician, in order to avoid hazard. -
Page 22: Connecting To Gas Supply
GAS CONNECTIONS FACTORY DEFAULT SETTINGS • Gas appliances are tested and fitted with the sign. • Has appliances are supplied sealed with burners adjusted to natural gas type H or E (20 or 25 mbar), or to liquefied natural gas (50 or 30 mbar). •... - Page 23 After connection, check the operation of the burners. The flames have to burn with clearly visible blue and green core. If the flame is unstable, increase the minimum power as necessary. Explain to the user how the burners operate and review the instruction manual together.
- Page 24 Gas valve with a safety device B Minimum heat input regulation screw Copreci Sabaf Oven burner 1 Nozzle 2 Injector holder 3 Oven burner To access the parts required to adjust the oven burner to another type of gas, the oven knob, bottom panel, and oven burner have to be disassembled (undo the screws in the front part of the burner and pull out the burner).
- Page 25 Grill burner 1 Nozzle 2 Injector holder 3 Grill burner To access the parts required to adjust the oven burner to another type of gas, the control panel, bottom insert and oven burner have to be disassembled (undo the screws in the front part of the heater, remove the flame control device (thermo element) and pull out the heater).
- Page 26 DISPOSAL Packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. To this end, packaging materials are labelled appropriately. The symbol on the product or its packaging indicates that the product should not be treated as normal household waste.
-
Page 27: Nozzle Table
NOZZLE TABLE Gas type, pressure Auxiliary burner Normal burner Wobbe number Standard Natural gas H Nominal heat load (kW) 0,48 0,48 Wo=45,7÷54,7 MJ/m Consumption (l/h) Natural gas E, E+ Nozzle type (1/100 mm) 72 X / 35 103 Z / 35 Wo=40,9÷54,7 MJ/m Nozzle ID 690771... - Page 28 GORENJE gospodinjski aparati, d.o.o Partizanska cesta 12, SI-3320 Velenje, SLOVENIA info@gorenje.com Made in Czech Republic...
