3.2 Operating Elements

On/Off Switch
Figure 1
USB Connector
DC Input (Charger)
Figure 2
Mounting Thread 1/4"-20
Figure 3
Front Panel
Sensor Connector
Analog Output (SMA)
Side Panel
SD Card Slot
Bottom View
Function Keys:
Navigation: 
Enter/Edit:
Wavelength:
Relative Measure: ∆
Backlight:
(DB9 female)
