Rehau NEA SMART 2.0 End User Manual page 21

05 Operation via integrated web pages
05.01 General
The integrated web pages can be used as an alterna-
tive to the NEA SMART 2.0 App via the browser of a
smartphone, tablet or PC.
The IP address of the device is 192.168.0.2.
Via the web pages, you can:
▪ Assign names to the rooms and set the desired
temperatures
▪ Create timer programmes for the desired tempera-
tures and assign them to the rooms
▪ Select the operating modes "normal mode"' and
"reduced mode" for all rooms or individual rooms
▪ Use the holiday function
▪ Switch between operating mode heating and
cooling
▪ Operate fan coils
To use the web pages, a direct connection must be
established between the device (smartphone, tablet,
PC) and the NEA SMART 2.0 Base by activating an
Access Point (AP) at the base. The web pages can
only be accessed with one device at a time.
It is not possible to use the App and the integrated
web pages at the same time.
05.02.01 Step 1: Activate Access Point (AP) at master base
< OK
1
> 3 sec
RZ11 RZ12 COOL
DI3 DI4 WIFI/LAN
2
Press both arrow buttons < > at the same time for > 3 seconds
1
>
The WIFI / LAN LED and / or the AP LED will begin to flash.
2
ZBUS1
AP
05.02 Setting up the base for using the web
pages
For systems in which there is more than one base,
communication always takes place via the "master"
base. Ask your installer which base has been
established as the master.
When the system is delivered, the communication
functions of the base station via WIFI / LAN and
Access Point (AP) are switched off.
The NEA SMART 2.0 Base may only be handled if the
cover is in place on the NEA SMART 2.0 Base. If this is
not the case, the installer has to be called.
21
