Room with modulating RAUCLIMATE SILENT BREEZE fan coils also in combination with one switched fan coil
4b
▪ Switched fan coils and RAUCLIMATE SILENT BREEZE fan coils are permanently deactivated when the setting is OFF
▪ Switching is made by pressing + or –
▪ Changing the fan coil operating mode is done by pressing + or –
STANDBY
Switched fan coils and RAUCLIMATE SILENT BREEZE fan coils are with the setting
▪ OFF – permanently disabled
▪ STANDBY deactivated until the next switching point of a time program arrives or the energy level is
manually changed. In this case the default setting for energy level REDUCED / NORMAL is applied.
RAUCLIMATE SILENT BREEZE fan coils are in the setting
▪ MIN / MED / MAX operated in the selected mode until the next switching point of a time program arrives
or the energy level is manually changed. In this case the default setting for energy level REDUCED / NORMAL
is applied.
Without the use of timers, the fan coil remains in the selected energy level
▪ When RAUCLIMATE SILENT BREEZE fan coils with flap are used, the flap can be switched between oscillating (ON) and
directional (OFF) airflow by pressing + or –
MIN
Lowest speed stage Medium speed stage
5
When the fan coil is switched off, there is no selection option for
operating mode and fan coil flap.
MED
Highest speed stage
MAX
