DVD Changer
DV-CP706
Instruction Manual
Thank you for purchasing an Onkyo DV-CP706
DVD Changer. Read this manual carefully
before using your new DVD Changer. A good
understanding of its features and operation will
allow you to achieve optimum performance and
enjoyment.
Keep this manual for future reference.
Contents
Overview ..............................................2
Connections ......................................18
Getting Started and Setting up ........23
Basic Playback ..................................25
Playback Techniques ........................36
Detailed Settings ...............................43
Miscellaneous information ...............51
E
n

Advertisement

Table of Contents
loading

Related Manuals for Onkyo DV-CP706S

Summary of Contents for Onkyo DV-CP706S

  • Page 1 Instruction Manual Connections ........18 Getting Started and Setting up ..23 Basic Playback ........25 Thank you for purchasing an Onkyo DV-CP706 Playback Techniques ......36 DVD Changer. Read this manual carefully before using your new DVD Changer. A good understanding of its features and operation will allow you to achieve optimum performance and enjoyment.

  • Page 2: Important Safety Instructions

    WARNING: AVIS WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC RISK OF ELECTRIC SHOCK RISQUE DE CHOC ELECTRIQUE DO NOT OPEN NE PAS OUVRIR SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the CAUTION: presence of uninsulated “dangerous voltage”...

  • Page 3: Precautions

    – The unit is used in a humid place. are wet or damp. If water or any other liquid gets inside this unit, have it checked by your Onkyo • Do not use this unit when there’s the possibility dealer.
  • Page 4 Precautions—Continued For Canadian Models This unit contains a semiconductor laser system and is classified as a “CLASS 1 LASER PRODUCT”. So, to NOTE: THIS CLASS B DIGITAL APPARATUS use this model properly, read this Instruction Manual COMPLIES WITH CANADIAN ICES-003. carefully.

  • Page 5: Table Of Contents

    Contents Important Safety Instructions ....2 Advanced Playback.........36 Repeat Playback ......... 36 Precautions..........3 A–B Repeat Playback ......... 37 Random Playback ........37 Introduction ..........6 Memory Playback........38 Supplied Accessories........6 Using Last Memory ........39 DV-CP706 Features ........7 Selecting Camera Angles......40 Disc Notes .............8 Selecting Languages &...

  • Page 6: Introduction

    To use , in addition to an connection, you must make an analog audio connection (RCA) between the DV-CP706 and your Onkyo AV receiver. Coaxial digital cable (1.0 m) Power cord (Power cord varies from country to country.) In catalogs and on packaging, the letter at the end of the product name indicates the color.

  • Page 7: Dv-Cp706 Features

    • Title, chapter, track, or time search • Last Memory function allows you to resume playback from a specific point on a DVD-Video disc, even if VLSC and the VLSC logo are registered trademarks of Onkyo that disc has been removed from the DV-CP706 Corporation.

  • Page 8: Disc Notes

    Introduction—Continued • Don’t use discs with an unusual shape, such as those Disc Notes shown below, because you may damage the DV-CP706. Supported Discs The DV-CP706 supports the following discs. Disc Logo Format or file type DVD-Video • Don’t use discs that have residue from adhesive tape, rental discs with peeling labels, or discs with custom- DVD-Video, MP3, DVD-R...

  • Page 9: About Wma

    Introduction—Continued Disc Content Organization MP3/WMA/JPEG Compatibility • The DV-CP706 can play/display MP3, WMA, and ■ DVD-Video Format JPEG files recorded on CD-R, CD-RW, DVD-R, DVD-Video discs contain titles, which are usually subdi- DVD-RW, DVD+R and DVD+RW discs. vided into chapters. •...
  • Page 10 Introduction—Continued Handling Discs Copyright • Never touch the underside of a disc. Always hold discs It is forbidden by law to copy, broadcast, show, broadcast by the edge, as shown. on cable, play in public, or rent copyrighted material without permission. DVD-Video discs are copy-protected, and any record- ings made from these discs will be distorted.

  • Page 11: Dv-Cp706-Related Terminology

    ■ RIHD (Remote Interactive over HDMI): ■ Field: In interlaced scanning, a field is a single scan Onkyo’s implementation of CEC (Consumer Elec- of the screen. There are two fields per frame. tronics Control), which allows integrated system ■...

  • Page 12: Controls & Connectors

    Controls & Connectors Front Panel H I J K N O P Q R S The page numbers in parentheses show where you can find the main explanation for each item. ON/STANDBY button (23) REPEAT button (36) This button is used to set the DV-CP706 to On or This button is used with the Repeat function.

  • Page 13: Display

    Controls & Connectors—Continued Display 4 5 6 7 8 9 0 A B CHAIN MODE DISC TITLE TRACK PRGV LAST TOTAL REMAIN CDVD The page numbers in parentheses show where you can find the main explanation for each item. CHAIN MODE, ALL, DVD & CD indicators REMAIN indicator (35) This indicator appears while the remaining time is...

  • Page 14: Rear Panel

    These (Remote Interactive) connectors can be connected to the connectors on your other Onkyo AV components for interactive control. If you’re using RIHD, do not connect anything to these connectors. OPTICAL AUDIO OUTPUT This optical digital audio output can be connected to an optical digital audio input on a hi-fi...

  • Page 15: Remote Controller

    Controls & Connectors—Continued Remote Controller The page numbers in parentheses show where you can find the main explanation for each item. ON button (23) This button is used to turn on the DV-CP706. Don’t turn on the DV-CP706 until you’ve com- pleted, and double checked all connections.
  • Page 16 Controls & Connectors—Continued ASPECT/ZOOM button (41, 45) RETURN button (44) This button is used to change the view mode. Press- This button is used to return to the previous screen. ing and holding it for a few seconds selects Zoom CHAIN MODE button (35) mode.

  • Page 17: Before Using The Dv-Cp706

    Before Using the DV-CP706 Installing the Remote Controller’s Using the Remote Controller Batteries To use the remote controller, point it at the DV-CP706’s remote control sensor, as shown below. Open the battery compartment, as shown. Remote control sensor DV-CP706 30˚ 30˚...

  • Page 18: Connecting The Dv-Cp706

    Connecting the DV-CP706 This chapter explains how to connect the DV-CP706 to RCA/phono AV Connection Color Coding your other AV components. RCA/phono AV connections are usually color coded: red, white, and yellow. Use red plugs to connect right- Before Making Any Connections channel audio inputs and outputs (typically labeled “R”).

  • Page 19: Connecting Your Tv Or Projector

    Connecting the DV-CP706—Continued Connecting Your TV or Projector This section explains how to connect the DV-CP706 to Compatibility of this unit with progressive-scan TVs. your TV or projector. See page 21 for connecting a TV This player is compatible with progressive video Macro or projector that supports HDMI.

  • Page 20: Digital Connection

    Connecting the DV-CP706—Continued Digital Connection • When the HDMI Output setting is set to On (see To enjoy Dolby Digital or DTS surround sound, you page 45), the DV-CP706 cannot output progres- need to connect one of the DV-CP706 digital audio out- sive video.

  • Page 21: Connecting A Component With An Hdmi Input

    Connecting the DV-CP706—Continued Analog Connection converted and output as PCM. DTS signals will not be output at all. Use an RCA/phono audio cable to connect the • Never connect the DV-CP706 to the AC-3RF input on DV-CP706’s ANALOG AUDIO OUTPUTs to a pair of a Dolby Digital receiver.

  • Page 22: Connecting -Compatible Components

    HDMI), which is Onkyo’s implementation of CEC (Consumer Electronics Control), which allows inte- grated system control over HDMI and is part of the HDMI standard. In addition to Onkyo AV components, it allows interoperability with CEC-compatible AV com- ponents and TVs made by other manufacturers.

  • Page 23: Dv-Cp706

    Powering Up & Setting Up the DV-CP706 To turn on the DV-CP706, press ON/STANDBY the [ON/STANDBY] button (or the remote controller’s [ON] button). The DV-CP706 comes on, the display lights up, and the STANDBY indicator goes off. To turn off the DV-CP706, press the Remote controller [ON/STANDBY] button (or the remote controller’s [STANDBY] button).

  • Page 24: Setting The Hdmi

    Powering Up & Setting Up the DV-CP706—Continued Your DV-CP706 is now ready for use. See page 25 for While “HDMI ON” is displayed, information on loading discs, and page 26 for informa- press the [RESOLUTION] button tion on selecting and playing discs. Remote controller on the remote controller repeat- Notes:...

  • Page 25: Basic Playback

    Basic Playback When you’ve finished, press the DISC OPEN/CLOSE [ ] button again. DISC SKIP SELECT The disc tray closes. See page 26 for information on select- ing and playing discs. Remote controller PLAY Tip: If you press the Play [ ] button, the disc tray will close and playback of the disc in the right bay will start auto- matically.

  • Page 26: Loading Discs During Playback

    Basic Playback—Continued Selecting Discs DISC DISC SKIP SELECT JPEG The section explains how to select loaded discs. Use the DISC SELECT buttons to select loaded discs. On the display, the number of the cur- rent disc has a circle around it. What happens next depends on the type of disc you selected, as follows: DVD-Video:...

  • Page 27: Starting, Pausing & Stopping Playback

    Basic Playback—Continued ■ Pause To pause playback, press the Pause [ ] button. STOP Playback pauses and the Pause indi- cator appears on the display. To resume playback, press the Play [ ] button. Remote controller Playback resumes and the Pause indicator disappears.

  • Page 28: Navigating Disc Menus

    Basic Playback—Continued Notes: • Not all DVD-Video discs have menus. • Menu operation varies from disc-to-disc. See the disc’s sleeve notes for details. • On some DVD-Video discs, options such as foreign language soundtracks, subtitles, and audio formats appear on a separate menu called the disc menu, and titles and chapters appear on what’s called the title menu.

  • Page 29: Using The Disc Navigation Window

    004. Track04 are played. Name: Onkyo Title Artist Name: Onkyo Artist If the disc contains MP3/WMA files Folder number and file number. and JPEG files, they are played/dis- played in order. JPEG files will be dis- Elapsed time, remaining time, and played in a slideshow.

  • Page 30: Selecting Titles, Chapters & Tracks By Number

    Basic Playback—Continued Use the number buttons to spec- PLAY ify a chapter or title. Remote controller To enter, for example, “2,” press the [2] button. Step Disc 1: DVD Search Disc Title Chapter 1:DVD-VIDEO Current/Total Current/Total To enter, for example, “12,” press the [1] button, followed by the [2] button.

  • Page 31: Locating Specific Points In Time

    Basic Playback—Continued Use the number buttons to enter PLAY a time. Remote controller To enter, for example, 1 hour, 25 min- utes, 30 seconds, press the [1], [2], [5], [3], and [0] buttons. Search Disc Title 1: DVD-VIDEO 1 : 25 : 30 To enter, for example, 2 minutes, 15 seconds, press the [2], [1], and [5] but- tons.

  • Page 32: Fast Forward & Reverse

    Basic Playback—Continued ■ Fast During playback, press the Fast PLAY reverse Reverse [ ] button to start fast reverse. Remote controller Playback reverses and “x 2” appears on-screen. To change the fast-reverse speed, press the Fast Reverse [ ] button repeat- edly to select: x 2, x 4, x 8, or x 16.

  • Page 33: Slow-Motion Playback

    Play [ ] button. Notes: Remote controller • When the display brightness on another Onkyo AV component connected via is changed, the “disc tray light off” option might not work. • Even if you selected the “disc tray light off” option,...

  • Page 34: Using Jpeg Cds

    Basic Playback—Continued You can use the following func- STOP tions during the slideshow: To display the next or previous picture, use the Next [ ] and Previous [ buttons. To turn a picture upside down, use the Up/Down [ ]/[ ] buttons (not while zoomed in).

  • Page 35: Using Chain Mode

    Basic Playback—Continued CHAIN MODE PARTY MODE Using Chain Mode Using Party Mode With the Chain mode function, you can play all discs, all With the Party mode function, you can play all of the DVD-Video discs, or all audio CDs and MP3/WMA audio CDs and MP3/WMA discs in random order.

  • Page 36: Advanced Playback

    Advanced Playback Repeat Playback JPEG With the Repeat Playback function you can play the cur- rent disc, title, chapter, track, or folder of MP3/WMA files over-and-over again. Press the Play [ ] button to start repeat playback. REPEAT Remote controller Press the [REPEAT] button repeatedly to select a repeat option.

  • Page 37: A-B Repeat Playback

    Advanced Playback—Continued A–B Repeat Playback Audio CD: 1 Disc, All Discs. MP3/WMA: Folder (files in subfolders are not With the A–B Repeat Playback function you can play a played), 1 Disc, All Discs. specified section over-and-over again. With the “Title” option, chapters within During playback, press the [A–B] the current title are played at random.

  • Page 38: Memory Playback

    Advanced Playback—Continued Press the [ENTER] button. The new item is added to the memory Remote controller list as step 01. Memory List No. Disc Title/Folder Chapter/Track Chapter/Track 001 / 002 Current/Total --- / 008 Number 001 / 002 005 / 008 MEMORY buttons --- / ---...

  • Page 39: Using Last Memory

    Advanced Playback—Continued Deleting Items from the List During playback, press the [LAST MEMORY] button. Remote controller To delete an item, use the Up/ The last memory point for the disc is Remote controller Down [ ]/[ ] buttons to select it, stored, the LAST indicator appears, and then press the [CLR] button.

  • Page 40: Selecting Camera Angles

    Advanced Playback—Continued Selecting Languages & Audio Formats Some DVD-Video discs feature soundtracks in several languages and audio formats (e.g., Dolby Digital or DTS). Music DVD-Video discs sometimes feature soundtracks in several audio formats, such as PCM or Dolby Digital 5.1. See the disc’s sleeve notes for details. ANGLE During playback, press the Remote controller...

  • Page 41: Zooming

    Advanced Playback—Continued ENTER ZOOM Zooming DVD-V JPEG With the Zoom function you can enlarge any part of the picture. During playback or paused, press and hold the [ZOOM] but- Remote controller ton. “Zoom x 1.0” appears on-screen. Press the [ZOOM] again repeat- edly to Zoom in.

  • Page 42: Displaying Information

    Advanced Playback—Continued Displaying Information You can display various information about the current disc, title, chapter, or track as follows. During playback, press the [DIS- PLAY] button. Various information appears on-screen. The operating status (e.g., Stop, Play, DISPLAY Resume), disc number, and disc type information is displayed along the top Remote controller of the screen.

  • Page 43: Configuring The Dv-Cp706

    Configuring the DV-CP706 This chapter explains the various functions and settings of the on-screen setup menus. Functions and settings are arranged into six menus: Picture, Audio, Language, Display, Operation Setting, and Initial Setup. The following table lists all the functions and settings, with a brief description and page number where you can find full details.

  • Page 44: Using The On-Screen Setup Menus

    Configuring the DV-CP706—Continued When you’ve finished, press the [SETUP] button again. Remote controller The on-screen setup menu closes. ENTER SETUP Picture Menu TV Shape With this setting you can select a picture format to match the aspect ratio of your TV. Using the On-screen Setup Menus Choose this 4:3 Letter box:...

  • Page 45: View Mode

    Configuring the DV-CP706—Continued View Mode HD Resolution With this setting you can adjust the aspect of the picture With this setting you can set the video resolution for the so that it fits your TV screen. Due to your TV’s aspect HDMI OUT.

  • Page 46: Video Black Level

    Configuring the DV-CP706—Continued Video Black Level Audio Menu With this setting you can adjust the picture blackness of Digital/HDMI Audio Out analog video output. Blacks are lighter, and the entire picture Light: With this setting you can configure the optical, coaxial, becomes lighter.

  • Page 47: Language Menu

    Configuring the DV-CP706—Continued • With some DVD-Video discs you can select subtitles Language Menu from a menu. On-Screen Language Display Menu With this setting you can select a language for the on- screen setup menus and messages. On-Screen Display Select one of the displayed language. With this setting you can turn on or off on-screen mes- Disc Menu Language sages, such as “Play,”...

  • Page 48: Operating Setting Menu

    Configuring the DV-CP706—Continued • Not all discs use parental lock. See the disc’s sleeve Operating Setting Menu notes for details. • Discs with parental lock may cut certain scenes, Parental Lock replace certain scenes with children-friendly scenes, With the Parental Lock function you can block access to or prevent playback of the entire disc.

  • Page 49: Initial Setup Menu

    RIHD control off. Off: Notes: The Auto power off function automatically turns off the • RIHD (Remote Interactive over HDMI) is Onkyo’s DV-CP706 after 20 minutes of inactivity. implementation of CEC (Consumer Electronics Con- trol), which allows integrated system control over HDMI and is part of the HDMI standard.

  • Page 50: Language Code List

    Configuring the DV-CP706—Continued Language Code List Use this list when specifying other languages. Language Code Language Code Language Code Language Code Icelandic Tatar Japanese Kirghiz Hebrew English Latin Yiddish Ukrainian French Lingala Javanese Urdu German Laothian Georgian Uzbek Italian Lithuanian Kazakh Vietnamese Spanish...

  • Page 51: Troubleshooting

    Troubleshooting Symptom Possible cause Remedy The power cord is not connected. Connect the power cord to a suitable wall outlet. Can’t turn Turn off the DV-CP706, wait five seconds, then try turning it on on the External interference is affecting the DV-CP706’s again.
  • Page 52 Troubleshooting—Continued Symptom Possible cause Remedy No Digital Audio Output? The Digital/HDMI Audio Out setting is set to Change the Digital/HDMI Audio Out setting to Off. either All or PCM (page 46). Your TV or AV receiver doesn’t support Dolby Change the Digital/HDMI Audio Out setting to Digital.
  • Page 53 Troubleshooting—Continued There are no batteries in the remote controller. Install new batteries (page 17). The batteries are flat. Replace with new batteries (page 17). Check the batteries and correct as necessary The batteries are installed incorrectly. (page 17). You’re not pointing the remote controller at Point the remote controller at the DV-CP706’s the DV-CP706’s remote sensor.
  • Page 54 ■ Restoring the Default Settings To reset the DV-CP706 to its factory defaults, turn it on, and when “ONKYO DVD” has disappeared from the display, while holding down the Stop [ ] button, press the [ON/STANDBY] button. “INITIALIZE” appears on the display.

  • Page 55: Specifications

    Specifications NTSC (North American model), Signal System PAL/NTSC (Australian model) Composite Video Output/Impedance 1.0 V(p-p)/75Ω negative sync, RCA Y: 0.7 V(p-p)/75Ω negative sync, 4-pin mini DIN S-Video Output/Impedance C: 0.286 V(p-p)/75Ω Component Video Output/Impedance Y: 1.0 V(p-p)/75Ω, P : 0.7 V(p-p)/75Ω, RCA DVD Linear Audio 4 Hz–44 kHz(96 kHz), 4 Hz–22 kHz(48 kHz) Audio CD...
  • Page 56 Unit 1&12, 9/F, Ever Gain PlazaTower 1, 88, Container Port Road, Kwai Chung, N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039 http://www.ch.onkyo.com/ I0808-2 SN 29344788A (C) Copyright 2008 ONKYO CORPORATION Japan. All rights reserved. * 2 9 3 4 4 7 8 8 A *...
