SERVICE MANUAL
SERVICE MANUAL
DVD CHANGER
DV-CP706
MODEL
CHAIN MODE DISC
TITLE
CHP
TRACK
PRGV
LAST
TOTAL REMAIN
ALL
DVD
CD
Black and Silver models
BMDD, SMDD
120V AC, 60Hz
BMUA, SMUA
100-240V AC, 50Hz
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
1
2
3
4
5
6
CDVD
ON THE
DV-CP706
Ref. No. 4098
072008
RC-655DV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV-CP706 and is the answer not in the manual?

Questions and answers

Related Manuals for Onkyo DV-CP706

Summary of Contents for Onkyo DV-CP706

  • Page 1 COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE THESE COMPONENTS WITH ONKYO PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL. MAKE LEAKAGE-CURRENT OR RESISTANCE...
  • Page 2 DV-CP706 EXPLODED VIEW U002-3 A215 CHANGER CSHASSIS x 8 pcs. A033 A057 M030 M032 P1901B P1401 M031 A214 Z001 P1703 A216 M012 M010 A018 M008 A019 A019 x 4 pcs. M010 x 10 pcs. A025 P1002 M009 x 2 pcs.

  • Page 3: Exploded View

    DV-CP706 EXPLODED VIEW TRAVERSE MECHANISM TRAVERSE MECHANISM ASSY TDT-2100SF-02 PART Number: 24801035 PARTS LIST PART CODE PART CODE PART NAME PART NAME C2G083 C2G083 DAMPER-IDLE DAMPER-IDLE C1H012 C1H012 SCREW-DAMPER-CR3 SCREW-DAMPER-CR3 A7P085 A7P085 CLAMP-T-M12H CLAMP-T-M12H A7G202 A7G202 CLAMPER-H CLAMPER-H CLAMPER-L CLAMPER-L...

  • Page 4: Block Diagram

    DV-CP706 Q1002 BLOCK DIAGRAM Q1851,X1851 Q1501 DVD LD LevelDetect Clock Genelator TC7SHU04FU Q1802 SDRAM HTPLGDET K4S281632I-UC60 REF_CLK (27MHz) or IS42S16800-6TG SYSCOM 27MHz HotPlugDetect or NT5SV8M16DS-6K TC7WU04FU ZR36722 TX0+,TX0-,TX1+,TX1-,TX2+,TX2-,TXC+,TXC- CD LD VID0 VID7, H SYNC, V SYNC Q1001 DDC_SCL DVD_LD DDC_SDA...
  • Page 5 DV-CP706 SHEMATIC DIAGRAM-1 DVD MAIN GND_PW1 GNDA5 VCC_A5 GNDD CIRCUIT PC BOARD-1 3.3V L1001 VDD_SW3.3 TP1002 LBC2518T220M 3.3V 105Z FOR HDMI TRANSMITTER C1020 NADG-9634 AnalogVideo Signals MPG_27MHz TP1004 TP1003 HN1A01F-GR Q1001 100/16 R1005 CD_LD C1021 TP1048 R1171 105Z C1022 XRST...
  • Page 6 DV-CP706 SCHEMATIC DIAGRAM-2 HDMI signals P1501 P1502 4.7K CEC_CONT R1541 DVD MAIN 3.3V R1588 FROM_ZR36886 I79_DUPTD1 R1539 R1592 TP1566 R1562 R1538 CEC_1 R1589 L1507 FOR_ZORAN CHIP BLM21PG221SN1 HD3.3V R1537 CIRCUIT PC BOARD-2 TP1505 HDVCC3.3 HDVCC3.3V 105Z CPU signals C1560 R1551...

  • Page 7: Schematic Diagram

    D7001 ROTL IRIN 2.2K LOADING_L P1351 EV5_GND Q7013 KRC107S LOADING_R +3.3VCPU ROULETTE MOTOR Z7001 DISC_SENS DV-CP706 INLET MINI POS_SENS R7068 R232TX ROULETTE MOTOR to MAIN BOARD(DPC7.9) LOARDING MOTOR DRIVE LD_CURRENT 3.3K RS232STBY DPC-7.9 INLET BIG PC BOARD Q7014 TA7291S LOADING_SW3 R232RX 1.0Pitch 9Pin 300mm AD...
  • Page 8 DV-CP706 SHEMATIC DIAGRAM-4 U02 : DISPLAY Q8001 HNV-12SM34 CIRCUIT PC BOARD DISPLAY CIRCUIT NADIS-9648 PC BOARD NADIS-9648 C8001 10/50 KEY01 R8061 R8062 R8063 R8064 R8065 1.8K -32V P4 FIP19 P46/FIP38 P23 P3 FIP18 P47/FIP39 P24 P2 FIP17 P50/FIP40 P25 DISC6...
  • Page 9 DV-CP706 SCHEMATIC DIAGRAM-5 POWER SUPPLY UNIT U20 : NGPS-0074-100-120V (MUD) NGPS-0075-100-240V (MUA) W102 MCN2.0MM (15P) Q101 D107 L102 T101 2SA673 SWA+12V 4.5uH F101 HER103 L101 + C112 2A125V R103 R105 R107 R108 ET-20 D102 100u/25V T2AL/250V C103 47K/1206 47R/1206 C108...

  • Page 10: Packing Procedure

    DV-CP706 Accessories bag PACKING PROCEDURE E816 Until #3800 A652 E801 E812 E802 E805 E803 E814 A608 E804 A701 P901 A611 A603 Front side marking A608 A605 A603 A604 FRONT SIDE A606 Front side marking A655 A610 A651 A610 FRONT SIDE...
  • Page 11 DV-CP706 PRINTED CIRCUIT BOARD VIEW-1a A-Side view U01 : DVD MAIN CIRCUIT PC BOARD (NADG-9634-1A/1B) P1551 P1781 U1402 P1411 R2017 R1560 R1564 R1587 R1557 P2001 R1559 Q1505 R1530 R1536 R1555 R1528 C1412 R1526 R1532 C2016 C2014 C2012 C2010 C2018 R1525...
  • Page 12 DV-CP706 PRINTED CIRCUIT BOARD VIEW-1b U01 : DVD MAIN CIRCUIT PC BOARD B-Side view (NADG-9634-1A/1B) C1408 R1410 Q2005 R2021 L1402 R1556 C2021 R2010 R1404 R1561 R2011 R1403 C1404 R2014 R2051 C2013 C2015 C2017 C2019 C1406 L1501 L1403 R1408 C1407 C2027...
  • Page 13 R8019 R8018 D8002 C8009 Q8003 C8006 R8009 C8008 R8032 R8502 R8031 R8503 R8028 C8029 R8501 R8001 Soldering side view DV-CP706 RIGHT ANGLE J8023 DPC-7.9 TOP J8019 J8021 J8003 STBYLED P7019A KEY2 P7018A J8008 J8002 J8007 EV5VGND GNDA5 GNDA5 C8034 C8033...
  • Page 14 DV-CP706 PRINTED CIRCUIT BOARD VIEW-3 U03 : MECHA. CONTROL PC BOARD (NADG-9649-1A/1C) R7052 C7026 Soldering side view R7051 C7027 D7002 R7006 D7001 R7022 D7004 C7025 R7053 C7013 Q7002 Q7001 R7503 C7009 R7024 R7509 R7014 R7504 R7506 R7019 Q7007 R7507 R7023...
  • Page 15 DV-CP706 PRINTED CIRCUIT BOARD VIEW-4 U04 : AUDIO OUTPUT PC BOARD (NAAF-9650-1A/1C) Soldering side view R4087 R4085 R4011 R4043 R4029 R4019 R4037 R4048 R4025 Q4003 R4084 C4015 R4047 Q4001 Q4009 R4015 R4023 R4058 R4027 Q4017 R4028 R4090 R4024 Q4010 R4101...
  • Page 16 DV-CP706 PRINTED CIRCUIT BOARD VIEW-5 U05 : STANDBY SWITCH PC BOARD (NASW-9652-1A/1C) Soldering side view C8043 C8042 PARTY ASPECT R8050 R8051 R8052 STBY DIMMER PARTY_MODE ASPECT DISPLAY Component side view S8031 S8030 P8013 NCSW-9652 25139652 ASPECT PARTY GNDA5 KEY2 S8036...
  • Page 17 DV-CP706 PRINTED CIRCUIT BOARD VIEW-6 U06 : KEY OPERATION PC BOARD (NASW-9653-1A/1C) Soldering side view PLAY STOP PAUSE DOWN R8046 PARTY_MODE C8016 R8039 R8036 R8037 R8058 R8038 C8032 Component side view S8023 SW5V S8019 P8005A PLAY STOP KEY01 PARTY_MODE PAUSE...
  • Page 18 DV-CP706 PRINTED CIRCUIT BOARD VIEW-7 U07 : DISC OPERATION PC BOARD (NASW-9654-1A/-1C) Soldering side view C8011 C8010 R8023 R8026 R8027 R8022 DISC5 DISC4 DISC3 DISC_SKIP OPEN/CLOSE DISC6 R8024 R8025 DISC2 DISC1 Component side view NCSW-9654 SW5V 25139654 DISC_SKIP DISC1 DISC2...
  • Page 19 DV-CP706 PRINTED CIRCUIT BOARD VIEW-8 U08 : ILLUMINATION PC BOARD (NADIS-9656-1A/1C) Soldering side view NCDIS-9656 25139656 SW5V P8002A Component side view...

  • Page 20: Printed Circuit Board View

    DV-CP706 PRINTED CIRCUIT BOARD VIEW-9 U10 : ROULETTE MOTOR PC BOARD (NAETC-9659-1A/1C) Z7001 ETC-9659 25139659 P7005A Soldering side view Component side view U09 : LOADING MOTOR PC BOARD (NAETC-9657-1A/1C) C7023 Z7002 NCETC-9657 P7009 25139657 Soldering side view Component side view...
  • Page 21 DV-CP706 PRINTED CIRCUIT BOARD VIEW-11 U11 : AC INLET PC BOARD (NAETC-9661-1A/1C) P901A P905A P905B NCETC-9661 25139661 Soldering side view...
  • Page 22 DV-CP706 PRINTED CIRCUIT BOARD VIEW-12 U12 : DISC SENSOR PC BOARD NAETC-9662-1A/1C C7011 R7021 R7017 Soldering side view NCETC-9662 25139662 P7002B Q7009 Component side view...

  • Page 23: Laser Warning

    DV-CP706 SERVICE PROCEDURES-1 PROTECTION OF EYES FROM LASER BEAM DURING SERVICING This set employs a laser. Therefore, be sure to follow carefully the instructions below when servicing. WARNING!! Laser Diode Properties Wavelength: 650/780nm (DVD/CD) SERVICE WARNING : DO NOT APPROACH THE LASER EXIT WITH THE EYE TOO CLOSELY.

  • Page 24: Service Procedures

    DV-CP706 SERVICE PROCEDURES-2 2. Safety-check out (Only U.S.A. model) After correcting the original service problem perform the following safety check before releasing the set to the customer Connect the insulating-resistance tester between the plug of power supply cord and terminal GND on the back panel.
  • Page 25 DV-CP706 UPGRADE FW (1) Prepare a FW disc The files necessary for DV-CP706 are as follows. changer08_o.ver obsidian.f16 Store these 2 and also about 70MB of files (total, WAVE, MP3 etc.) in a CD-R in "Disc-at-once" mode. (2) Check Version in advance Hold down [Display] and then press [Stop] to display Version of System Microprocessor.
  • Page 26 DV-CP706 OPERATION GUIDE Initialization 1. Press the "STOP" & "STANDBY" at the same with NO DISC condition. 2. Will display "COMPLETE" on FL tube after initializing for setting & mechanism. The unit will be going to "STANDBY" after display "COMPLETE".

  • Page 27: Parts List

    1/40 PAGE PARTS LIST DV-CP706 : Safety parts (S) : Silver model (B) : Black model <MDD> : North American model <MUA> : Australian model EXPLODED VIEW PARTS LIST NSP: Not service parts PART NAME DESCRIPTION PART NUMBER REMARKS Q'TY...
  • Page 28 82143006GR PWBx2 A120 BOTTOM LEG .DV-SP504 27175433 A121 CUSHION 28141664 LEGx2 A122 SCREW 3TTB+8B(3CM) 838130088GR LEGx2 A214 COVER DV-CP706(B) 28184966-1AZ (B) Not bent A214 COVER DV-CP706(B) 28184966-1A (B) Bent A214 COVER DV-CP706(S) 28184967-1AZ (S) Not bent A214 COVER DV-CP706(S) 28184967-1A...
  • Page 29 1H554562-1C <MUA> Power supply unit NGPS-0075-100-240V 24150075A <MDD> Power supply unit NGPS-0074-100-120V 24150074B <MUA> F102 Quick action micro fuse MQ2A/125V OP66 F105 Quick action micro fuse MQ3A/125V OP67 DV-CP706 PACKING VIEW PARTS LIST PART NAME DESCRIPTION PART NUMBER REMARKS Q'TY...
  • Page 30 (SEROHAN)NITTO NO.29 29110149 0.3:MT A610 PP TAPE W50 SBT-70 29110200 :1.5:MT A611 SHEET (PAD) 29096050-1 A651 UPC LABEL DV-CP706(B) 29390563 { 1} <B MDD> A651 UPC LABEL DV-CP706(S) 29390564 <S MDD> { 1} A651 EAN LABEL DV-CP706(B)MUA 29390579 { 1} <B MUA>...
  • Page 31 5/40 PAGE M001 RAIL 24840172B MECHA M002 Loading motor assy M002+M003 1H498602A MECHA M002 MOTOR CCM07B-045R1-1A 24804046A M003 PULLEY 24810084-1 M003 or PULLEY 24810084 ( 1) MECHA M004 SCREW 2.6P+4FN 82112604 MP003:M001*2 M005 RBR BELT DVCP701 24816039 MECHA MECHA M006 GEAR (PULLEY) 24810085...
  • Page 32 DVCP701 24840162 M050*4 M061 ROULETTE 24840173 MECHA MECHA M062 SCREW 3*8*w11 801633 M061*1 DV-CP706 PRINTED CIRCUIT BOARD PARTS LIST DVD Main circuit PC board assy NADG-9634-1A/-1B 1H554534-1A/-1B PART NAME DESCRIPTION PART NUMBER REMARKS Q'TY C1001 CHIP ELECT C CEWX4V-220M 3981G2217R2...
  • Page 33 7/40 PAGE C1013 C-CERA C CC725CH1H-102J1 342101024R1 DG9634-1 DG9634-1 C1014 C-CERA C CC725CH1H-102J1 342101024R1 C1015 C-CERA C CC725CH1H-330J1 342103304R1 DG9634-1 DG9634-1 C1016 C-CERA C CC725CH1H-330J1 342103304R1 C1017 C-CERA C CK725B1C-104K1 332121045R1 DG9634-1 C1018 C-CERA C CC725CH1H-330J1 342103304R1 DG9634-1 DG9634-1 C1019 C-CERA C CC725CH1H-330J1 342103304R1...
  • Page 34 8/40 PAGE C1115 C-CERA C CK725F1A-105Z1 332181050R1 DG9634-1 DG9634-1 C1116 C-CERA C CK725F1A-105Z1 332181050R1 C1117 C-CERA C CK725F1A-105Z1 332181050R1 DG9634-1 DG9634-1 C1118 C-CERA C CK725F1A-105Z1 332181050R1 C1119 C-CERA C CK725F1A-105Z1 332181050R1 DG9634-1 C1120 C-CERA C CK725F1A-105Z1 332181050R1 DG9634-1 DG9634-1 C1121 C-CERA C CK725F1A-105Z1 332181050R1...
  • Page 35 9/40 PAGE C1155 C-CERA C CK725F1A-105Z1 332181050R1 DG9634-1 DG9634-1 C1156 CHIP ELECT C CEWX4V-220M 3981G2217R2 C1161 C-CERA C CK725F1A-105Z1 332181050R1 DG9634-1 DG9634-1 C1162 CHIP ELECT C CEWX6.3V-330M 398123317R2 C1165 C-CERA C CK725F1A-105Z1 332181050R1 DG9634-1 C1201 C-CERA C CK725F1E-104Z1 332161040R1 DG9634-1 DG9634-1 C1202 C-CERA C...
  • Page 36 10/40 PAGE C1401 CHIP ELECT C CEWX10V-220M 398132217R2 DG9634-1 DG9634-1 C1402 C-CERA C CK725F1E-104Z1 332161040R1 C1405 C-CERA C CK725F1E-104Z1 332161040R1 DG9634-1 DG9634-1 C1406 CHIP ELECT C CEWX16V-22M 398142207R2 C1407 C-CERA C CC725CH1H-220J1 342102204R1 DG9634-1 C1408 C-CERA C CK725F1E-104Z1 332161040R1 DG9634-1 DG9634-1 C1410 C-CERA C...
  • Page 37 11/40 PAGE C1559 C-CERA C CK725F1A-105Z1 332181050R1 DG9634-1 DG9634-1 C1560 C-CERA C CK725F1A-105Z1 332181050R1 C1561 C-CERA C CK725F1A-105Z1 332181050R1 DG9634-1 DG9634-1 C1563 CHIP ELECT C CEWX6.3V-22M 398122207R2 C1564 C-CERA C CK725F1A-105Z1 332181050R1 DG9634-1 C1565 CHIP ELECT C CEWX4V-100M 3981G1017R2 DG9634-1 DG9634-1 C1566 C-CERA C...
  • Page 38 12/40 PAGE C1851 C-CERA C CK725F1A-105Z1 332181050R1 DG9634-1 DG9634-1 C1852 CHIP ELECT C CEWX4V-220M 3981G2217R2 C1853 C-CERA C CK725F1A-105Z1 332181050R1 DG9634-1 DG9634-1 C1854 C-CERA C CK725F1A-105Z1 332181050R1 C1855 CHIP ELECT C CEWX4V-220M 3981G2217R2 DG9634-1 C1856 C-CERA C CK725F1A-105Z1 332181050R1 DG9634-1 DG9634-1 C1857 C-CERA C...
  • Page 39 13/40 PAGE C2006 CHIP ELECT C CEWX50V-1M 398180107R2 DG9634-1 DG9634-1 C2007 C-CERA C CK725F1A-105Z1 332181050R1 C2008 CHIP ELECT C CEWX6.3V-22M 398122207R2 DG9634-1 DG9634-1 C2009 C-CERA C CK725F1A-105Z1 332181050R1 C2010 CHIP ELECT C CEWX16V-100M 398141017R2 DG9634-1 C2011 CHIP ELECT C CEWX6.3V-22M 398122207R2 DG9634-1 DG9634-1...
  • Page 40 14/40 PAGE D1908 or C-DIODE MA2J1110GL 223302R2 ( 1) DG9634-1 DG9634-1 D1909 C-DIODE 1SS352 223234R2 D1909 C-DIODE 1SS355 223269R2 DG9634-1 DG9634-1 F1501 RESISTOR nanoSMDC016F 4000239R2 L1001 CHOKE COIL LBC2518T220M 231364M220R2 DG9634-1 L1002 CHOKE COIL LBC2518T220M 231364M220R2 DG9634-1 DG9634-1 L1003 CHOKE COIL LBC2518T220M 231364M220R2 L1004...
  • Page 41 15/40 PAGE L1581 CHOKE COIL BLM21PG221SN1 230949R2 DG9634-1 DG9634-1 L1582 EMIFIL BK1608LL241-T 230959R1 L1583 EMIFIL BK1608LL241-T 230959R1 DG9634-1 DG9634-1 L1851 CHOKE COIL BLM21PG221SN1 230949R2 L1852 CHOKE COIL BLM21PG221SN1 230949R2 DG9634-1 L1903 CHOKE COIL NCH-2541 231363K470 DG9634-1 DG9634-1 L1904 CHOKE COIL BLM21PG221SN1 230949R2 L2001...
  • Page 42 16/40 PAGE Q1205 BA4510FV 22241907R2 DG9634-1 DG9634-1 Q1206 TC74AC00FT 22242244R2 SPINDLE DETECT Q1401 TC74VHCU04FT 22274004HR2TO DG9634-1 DG9634-1 Q1501 ZR36722PQCG 22242538R3 Q1502 SN74CB3Q3305PWR 22242258R2 DG9634-1 Q1503 TC7SZ125FU(TE85L_F) 22241895R2 DG9634-1 DG9634-1 Q1504 XC6213B332MR 22242277R2 Q1505 TR ARRAY UM6K1N 226066R2 DG9634-1 DG9634-1 Q1581 TC7WZU04FU(TE12L_F) 22242078R2TO Q1582...
  • Page 43 17/40 PAGE R1001 C-CARBON R RN72K1J-047JE 435030474R1 DG9634-1 DG9634-1 R1003 C-CARBON R RN72K1J-047JE 435030474R1 R1005 C-CARBON R RN72K1J-221JE 435032214R1 DG9634-1 DG9634-1 R1006 C-CARBON R RN72K1J-332JE 435033324R1 R1007 C-CARBON R RN72K1J-047JE 435030474R1 DG9634-1 R1009 C-CARBON R RN72K1J-047JE 435030474R1 DG9634-1 DG9634-1 R1011 C-CARBON R RN72K1J-221JE 435032214R1...
  • Page 44 18/40 PAGE R1105 C-CARBON R RN72K1J-470JE 435034704R1 DG9634-1 DG9634-1 R1107 C-CARBON R RN72K1J-470JE 435034704R1 R1108 C-CARBON R RN72K1J-470JE 435034704R1 DG9634-1 DG9634-1 R1109 C-CARBON R RN72K1J-472JE 435034724R1 R1110 C-CARBON R RN72K1J-470JE 435034704R1 DG9634-1 R1111 C-CARBON R RN72K1J-470JE 435034704R1 DG9634-1 DG9634-1 R1112 C-CARBON R RN72K1J-470JE 435034704R1...
  • Page 45 19/40 PAGE R1159 C-CARBON R RN72K1J-102JE 435031024R1 DG9634-1 DG9634-1 R1161 C-CARBON R RN72K1J-220JE 435032204R1 R1165 C-CARBON R RN72K1J-101JE 435031014R1 DAC CONTOROL DATA DG9634-1 DG9634-1 R1166 C-CARBON R RN72K1J-101JE 435031014R1 DAC CONTOROL CLK R1168 C-CARBON R RN72K1J-221FE 435032212R1 DG9634-1 R1169 C-CARBON R RN72K1J-151FE 435031512R1 DG9634-1...
  • Page 46 20/40 PAGE R1198 C-R NET RM7LJ470X04 43484747004R2 DG9634-1 DG9634-1 R1199 C-R NET RM7LJ470X04 43484747004R2 R1201 C-CARBON R RN72K1J-102JE 435031024R1 DG9634-1 DG9634-1 R1202 C-CARBON R RN72K1J-473JE 435034734R1 R1203 C-CARBON R RN72K1J-473JE 435034734R1 DG9634-1 R1204 C-CARBON R RN72K1J-047JE 435030474R1 DG9634-1 DG9634-1 R1205 C-CARBON R RN72K1J-047JE 435030474R1...
  • Page 47 21/40 PAGE R1246 C-CARBON R RN72K1J-103JE 435031034R1 DG9634-1 DG9634-1 R1247 C-CARBON R RN72K1J-153JE 435031534R1 R1248 C-CARBON R RN72K1J-183JE 435031834R1 DG9634-1 DG9634-1 R1249 C-CARBON R RN72K1J-273JE 435032734R1 R1250 C-CARBON R RN72K1J-101JE 435031014R1 DG9634-1 R1251 C-CARBON R RN72K1J-101JE 435031014R1 DG9634-1 DG9634-1 R1252 C-CARBON R RN72K1J-101JE 435031014R1...
  • Page 48 22/40 PAGE R1406 C-CARBON R RN72K1J-121JE 435031214R1 DG9634-1 DG9634-1 R1407 C-CARBON R RN72K1J-182JE 435031824R1 R1409 C-CARBON R RN72K1J-122JE 435031224R1 DG9634-1 DG9634-1 R1410 C-CARBON R RN72K1J-221JE 435032214R1 R1411 C-CARBON R RN72K1J-000JE 435030004R1 DG9634-1 R1501 C-R NET RM7LJ470X04 43484747004R2 DG9634-1 DG9634-1 R1502 C-R NET RM7LJ470X04 43484747004R2...
  • Page 49 23/40 PAGE R1536 C-CARBON R RN72K1J-101FE 435031012R1 DG9634-1 DG9634-1 R1537 C-CARBON R RN72K1J-750JE 435037504R1 R1538 C-CARBON R RN72K1J-750JE 435037504R1 DG9634-1 DG9634-1 R1539 C-CARBON R RN72K1J-750JE 435037504R1 R1540 C-CARBON R RN72K1J-331JE 435033314R1 DG9634-1 R1541 C-CARBON R RN72K1J-472JE 435034724R1 DG9634-1 DG9634-1 R1542 C-CARBON R RN72K1J-000JE 435030004R1...
  • Page 50 24/40 PAGE R1704 C-CARBON R RN72K1J-473JE 435034734R1 DG9634-1 DG9634-1 R1705 C-CARBON R RN72K1J-470JE 435034704R1 R1708 C-CARBON R RN72K1J-221JE 435032214R1 DG9634-1 DG9634-1 R1709 C-CARBON R RN72K1J-103JE 435031034R1 R1712 C-CARBON R RN72K1J-103JE 435031034R1 DG9634-1 R1713 C-CARBON R RN72K1J-224JE 435032244R1 DG9634-1 DG9634-1 R1714 C-CARBON R RN72K1J-470JE 435034704R1...
  • Page 51 25/40 PAGE R1748 C-CARBON R RN72K1J-000JE 435030004R1 POS_SENS DG9634-1 DG9634-1 R1750 C-CARBON R RN72K1J-000JE 435030004R1 DISC_SENS R1752 C-CARBON R RN72K1J-470JE 435034704R1 DG9634-1 DG9634-1 R1753 C-CARBON R RN72K1J-221JE 435032214R1 R1755 C-CARBON R RN72K1J-470JE 435034704R1 DG9634-1 R1756 C-CARBON R RN72K1J-470JE 435034704R1 DG9634-1 DG9634-1 R1757 C-CARBON R...
  • Page 52 26/40 PAGE R1798 C-CARBON R RN72K1J-473JE 435034734R1 DG9634-1 DG9634-1 R1799 C-CARBON R RN72K1J-473JE 435034734R1 R1800 C-CARBON R RN72K1J-473JE 435034734R1 DG9634-1 DG9634-1 R1801 C-CARBON R RN72K1J-221JE 435032214R1 R1803 C-CARBON R RN72K1J-333JE 435033334R1 DG9634-1 R1804 C-CARBON R RN72K1J-472JE 435034724R1 DG9634-1 DG9634-1 R1805 C-CARBON R RN72K1J-272JE 435032724R1...
  • Page 53 27/40 PAGE R1840 C-CARBON R RN72K1J-000JE 435030004R1 DG9634-1 DG9634-1 R1843 C-CARBON R RN72K1J-104JE 435031044R1 R1844 C-CARBON R DG9634-1 RN72K1J-104JE 435031044R1 DG9634-1 R1851 C-CARBON R RN72K1J-103JE 435031034R1 R1852 C-CARBON R RN72K1J-102JE 435031024R1 DG9634-1 R1853 C-CARBON R RN72K1J-102JE 435031024R1 DG9634-1 DG9634-1 R1854 C-CARBON R RN72K1J-102JE 435031024R1...
  • Page 54 28/40 PAGE R2008 C-CARBON R RN72K1J-750JE 435037504R1 DG9634-1 DG9634-1 R2009 C-CARBON R RN72K1J-750JE 435037504R1 R2010 C-CARBON R RN72K1J-750JE 435037504R1 DG9634-1 DG9634-1 R2011 C-CARBON R RN72K1J-103JE 435031034R1 R2012 C-CARBON R RN72K1J-750JE 435037504R1 DG9634-1 R2013 C-CARBON R RN72K1J-750JE 435037504R1 DG9634-1 DG9634-1 R2014 C-CARBON R RN72K1J-750JE 435037504R1...
  • Page 55 29/40 PAGE AC Inlet terminal PC board NAETC-9661-1A/-1C 1H554561-1A/-1C DISC Sensor PC board assy NAETC-9662-1A/-1C 1H554562-1A/-1C PART NAME DESCRIPTION PART NUMBER REMARKS Q'TY C4001 TF C ECQ-B50V-331K 374723315T DIS9648-1 C4002 TF C ECQ-B50V-331K 374723315T DIS9648-1 DIS9648-1 C4003 TF C ECQ-B50V-221K 374722215T C4004 TF C...
  • Page 56 30/40 PAGE C4034 C-CERA C CK725F1E-104Z1 332161040R1 DIS9648-1 DIS9648-1 C4036 TF C ECQ-B50V-102J 374721024T C4037 TF C ECQ-B50V-102J 374721024T DIS9648-1 C4038 TF C ECQ-B50V-102J 374721024T DIS9648-1 C4039 TF C ECQ-B50V-102J 374721024T DIS9648-1 C4040 TF C ECQ-V50V-104J 374721044T DIS9648-1 DIS9648-1 C4046 C-CERA C CK725F1A-105Z1 332181050R1...
  • Page 57 31/40 PAGE C8016 C-CERA C CK725F1E-104Z1 332161040R1 DIS9648-1 DIS9648-1 C8017 C-CERA C CK725F1E-104Z1 332161040R1 C8018 C-CERA C CK725F1E-104Z1 332161040R1 DIS9648-1 C8021 C-CERA C CC725CH1H-102J1 342101024R1 DIS9648-1 C8023 C-CERA C CK725F1E-104Z1 332161040R1 DIS9648-1 C8025 C-CERA C CK725F1E-104Z1 332161040R1 DIS9648-1 DIS9648-1 C8026 C-CERA C CK725F1E-104Z1 332161040R1...
  • Page 58 32/40 PAGE D7005 C-DIODE 1SS352 223234R2 DIS9648-1 DIS9648-1 D7005 or C-DIODE 1SS355 223269R2 ( 1) D7005 or C-DIODE KDS4148U 223283R2 ( 1) DIS9648-1 D7005 or C-DIODE MA2J111 223279R2 ( 1) DIS9648-1 D7005 or C-DIODE MA2J1110GL 223302R2 ( 1) DIS9648-1 D8001 SCB3318E-D 225481 DIS9648-1...
  • Page 59 33/40 PAGE P7019 SOCKET AS NSAS-14P0954 2002E391415UL DIS9648-1 DIS9648-1 P7019A PLUG NPLG-7P354 25055371 P8002 SOCKET AS NSAS-4P1767 200EE390415UL DIS9648-1 P8005 SOCKET AS NSAS-10P1438 200EE391006UL DIS9648-1 P8008 PLUG NPLG-9P137 25055153 ph top DIS9648-1 P8008A SOCKET AS NSAS-18P1768 2002E391805UL DIS9648-1 DIS9648-1 P8012 SOCKET AS NSAS-8P1012 2009990721UL...
  • Page 60 34/40 PAGE Q4019 or RN1407 2216260R2 ( 1) DIS9648-1 DIS9648-1 Q4020 2SC2712-GR 2213145R2 Q7001 KRC107S 2216340R2 DIS9648-1 Q7001 or RN1407 2216260R2 ( 1) DIS9648-1 Q7002 KRC107S 2216340R2 DIS9648-1 Q7002 or RN1407 2216260R2 ( 1) DIS9648-1 DIS9648-1 Q7003 PHT INT GP2S28 24190046 Q7007 KRC107S...
  • Page 61 35/40 PAGE Q8007 KRC107S 2216340R2 DIS9648-1 DIS9648-1 Q8007 or RN1407 2216260R2 ( 1) Q8051 MPC29M33AT-E1-A 22278033EAR2NE DIS9648-1 R4001 C-CARBON R RN72K1J-122JE 435031224R1 DIS9648-1 R4002 C-CARBON R RN72K1J-122JE 435031224R1 DIS9648-1 R4003 C-CARBON R RN72K1J-122JE 435031224R1 DIS9648-1 DIS9648-1 R4004 C-CARBON R RN72K1J-122JE 435031224R1 R4005 C-CARBON R...
  • Page 62 36/40 PAGE R4033 C-CARBON R RN72K1J-103JE 435031034R1 DIS9648-1 DIS9648-1 R4034 C-CARBON R RN72K1J-103JE 435031034R1 R4035 C-CARBON R RN72K1J-224JE 435032244R1 DIS9648-1 R4036 C-CARBON R RN72K1J-224JE 435032244R1 DIS9648-1 R4037 C-CARBON R RN72K1J-221JE 435032214R1 DIS9648-1 R4038 C-CARBON R RN72K1J-221JE 435032214R1 DIS9648-1 DIS9648-1 R4039 C-CARBON R RN72K1J-222JE 435032224R1...
  • Page 63 37/40 PAGE R4101 C-CARBON R RN72K1J-470JE 435034704R1 DIS9648-1 DIS9648-1 R4102 C-CARBON R RN72K1J-470JE 435034704R1 R4103 C-CARBON R RN72K1J-470JE 435034704R1 DIS9648-1 R4104 C-CARBON R RN72K1J-470JE 435034704R1 DIS9648-1 R4105 C-CARBON R RN72K1J-470JE 435034704R1 DIS9648-1 R4106 C-CARBON R RN72K1J-470JE 435034704R1 DIS9648-1 DIS9648-1 R4113 METAL O R RS1/2WBJ-100 443521014T...
  • Page 64 38/40 PAGE R7047 C-CARBON R RN72K1J-472JE 435034724R1 DIS9648-1 DIS9648-1 R7048 C-CARBON R RN72K1J-000JE 435030004R1 R7050 C-CARBON R RN72K1J-392JE 435033924R1 DIS9648-1 R7055 C-CARBON R RN72K1J-104JE 435031044R1 DIS9648-1 R7056 C-CARBON R RN72K1J-223JE 435032234R1 DIS9648-1 R7057 C-CARBON R RN72K1J-223JE 435032234R1 DIS9648-1 DIS9648-1 R7104 METAL R RNU1/2WCJ-4.7 453530474T...
  • Page 65 39/40 PAGE R8031 C-CARBON R RN72K1J-222JE 435032224R1 DIS9648-1 DIS9648-1 R8032 C-CARBON R RN72K1J-222JE 435032224R1 R8033 C-CARBON R RN72K1J-103JE 435031034R1 DIS9648-1 R8034 C-CARBON R RN72K1J-333JE 435033334R1 DIS9648-1 R8035 C-CARBON R RN72K1J-821JE 435038214R1 DIS9648-1 R8036 C-CARBON R RN72K1J-391JE 435033914R1 DIS9648-1 DIS9648-1 R8037 C-CARBON R RN72K1J-471JE 435034714R1...
  • Page 66 40/40 PAGE R8506 C-CARBON R RN72K1J-000JE 435030004R1 DIS9648-1 DIS9648-1 R8507 C-CARBON R RN72K1J-000JE 435030004R1 S7001 PUSH SW NPS-111-S679 25035716 DIS9648-1 S7002 PUSH SW NPS-111-S679 25035716 DIS9648-1 S7003 PUSH SW NPS-111-S679 25035716 DIS9648-1 S8010 PUSH SW NPS-111-S681 25035718T DIS9648-1 DIS9648-1 S8011 PUSH SW NPS-111-S681 25035718T...
  • Page 67 Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8163 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/ ONKYO EUROPE ELECTRONICS GmbH Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.com/...
