DVD Changer
DV-CP500
Instruction Manual
Thank you for purchasing the Onkyo DVD Changer.
Please read this manual thoroughly before making
connections and turning on the power.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new DVD Changer.
Please retain this manual for future reference.
Contents
Before Using Your DVD Changer
Getting Started
Facilities and Connections
Basic Operation
Advanced Operation
Function Setup
Others
2
6
10
17
20
30
37

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV-CP500 and is the answer not in the manual?

Questions and answers

Related Manuals for Onkyo DV-CP500

Summary of Contents for Onkyo DV-CP500

  • Page 1 DVD Changer DV-CP500 Instruction Manual Thank you for purchasing the Onkyo DVD Changer. Please read this manual thoroughly before making connections and turning on the power. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new DVD Changer.

  • Page 2: Important Safeguards

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
  • Page 3 Precautions This unit contains a semiconductor laser system and is classified as a “CLASS 1 LASER PRODUCT”. So, to use this model properly, read this Instruction Manual carefully. In case of any trouble, please contact the store where you purchased the unit. To prevent being exposed to the laser beam, do not try to open the enclosure.
  • Page 4 Precautions 1. Regional Restriction Codes (Region Number) Regional restriction codes are built into DVD Changers and DVD-Video media for each sales region. If the regional code of the DVD Changer does not match one of the regional codes on the DVD-Video, playback is not possible. The regional number can be found on the rear panel of the DVD Changer.

  • Page 5: Table Of Contents

    Table of Contents Important Safeguards / Precautions / Table of Contents ... 2 - 5 Getting Started Notes on Discs ... 6 Playable Discs / The Structure of the Disc Content / About Video CDs / MP3 Compatibility Information / Handling Discs / Cleaning Discs / Storing Discs / Notes on Copyright Features/Supplied Accessories ...

  • Page 6: Mp3 Compatibility Information

    Notes on Discs This section shows you how to handle, clean, and store discs. Playable Discs This DVD Changer can playback the following discs. Disc mark Contents Audio DVD- Video Video (moving pictures) Audio + Video Video (moving pictures) CD-R* Audio CD-RW* * The DVD Changer can play CD-R/RW discs recorded in...

  • Page 7: Notes On Copyright

    Handling Discs • Do not touch the playback side of the disc. Playback side • Do not attach paper or tape to discs. Cleaning Discs • Fingerprints and dust on the disc cause picture and sound deterioration. Wipe the disc from the center outwards with a soft cloth.

  • Page 8: Features/Supplied Accessories

    G Pass 96 kHz PCM digital stream Supplied Accessories Make sure your box contains everything listed below. If any pieces are missing, contact your nearest Onkyo dealer. The number of accessories is indicated in brackets [ ]. Remote controller (RC-502DV) [1]...

  • Page 9: Inserting The Batteries

    Preparing the Remote Controller Inserting the Batteries 1 Remove the battery compartment cover by pressing the tab and lifting up the cover. 2 Insert the two batteries (size AAA/R3). Be sure to match the + and – ends of the batteries with the diagram inside the battery compartment.

  • Page 10: Control Position And Names

    Control Position and Names Front Panel For operational instructions, see the page indicated in brackets [ ]. 1 POWER button [17] Turns on the main power supply. 2 STANDBY indicator [17] Lights in the standby mode. STANDBY/ON button [17] Toggle for standby on and off. 4 CD PLAY button [25] Press to use the DVD Changer as CD player.

  • Page 11: Rear Panel

    Control Position and Names Rear Panel For operational instructions, see the page indicated in brackets [ ]. VIDEO OUTPUT COMPONENT 1 2 3 4 5 6 1 VIDEO OUTPUT COMPONENT (P If your TV has component inputs, you can connect a component video cable to your TV and to your DVD Changer for ideal video quality.

  • Page 12: Display Examples

    Control Position and Names Display 1 Inserted disc indicators Indicate the type of disc that is currently loaded. 2 PROGRESSIVE indicator Illuminates when the DVD changer is set to progressive mode. 3 Parental Lock indicator Illuminates in parental lock mode. 4 TITLE indicator Illuminates to indicate the current title number.

  • Page 13: Remote Controller

    Control Position and Names Remote Controller For operational instructions, see the page indicated in brackets [ ]. 1 STANDBY ON button [17] Toggle for standby on and off. 2 DISC SKIP button [18] Press to skip a disc. 3 RANDOM button [25] Press to do random playback.

  • Page 14: Making Connections

    Making Connections To accommodate a wide range of home entertainment systems, this player features numerous connection types for both audio and video. Please refer to the instructions on this and the following pages to determine the best possible type of connections for your system. Before Connecting •...

  • Page 15: Optional Video Connections

    Making Connections Optional Video Connections Visible improvements in DVD-Video quality can be achieved by making either S-video or component video connections to a TV or monitor compatible with these types of connections. Note When either an S-video or component video connection is made, it is not necessary to make composite video connections using the yellow cord of the audio-video cable.

  • Page 16: Optional Audio Connections

    Making Connections Optional Audio Connections This DVD Changer provides numerous ways to take full advantage of the digital multi-channel sound recorded on DVD and some CD media. Be sure to set Digital Audio Out after connection using the setup menu explained in “Customizing the Settings” starting on page 30.

  • Page 17: Turning On

    Turning on Connecting the POWER The DV-CP500 is shipped with the main power (POWER) switch in the on position ( ON). When the power cord is plugged in for the first time, the DV-CP500 will automatically enter the standby mode and the STANDBY indicator will blink for about 10 seconds, then light (same condition after step 2 below).

  • Page 18: Starting Playback

    Basic Playback Before playing • DVD-Video, Video CD, CD can be played with the DVD Changer (see “Playable Discs” on page 6). Do not play anything else. • When playing DVD-Video or Video CD with video features, turn on the TV and set the TV to the DVD Changer's input.

  • Page 19: Various Playback

    Basic Playback Various Playback I To remove the disc Press 0 to open the disc tray. Remove the disc after the disc tray opens completely. After removing the disc, be sure to press the button again to close the tray. Press DISC SKIP to rotate the disc tray while the tray open.

  • Page 20: Using Banner Display

    Using Banner Display Using the On-screen Banner Display The on-screen Banner Display contains many playback features. To see the Banner Display, press ON SCREEN on the remote controller while a disc is playing. Use 2/3 to move through the different features in the Banner Display. Each feature is illustrated with an icon.

  • Page 21: Selecting A Chapter Or Track

    Using Banner Display Selecting a Title DVD-Video Title 1 Title 2 Some discs contain more than one title. For example, there might be four movies on one disc (each movie might be considered a title). Press ON SCREEN. Press 2/3 until the TITLE icon is highlighted.

  • Page 22: Changing The Subtitle Language

    Using Banner Display Selecting a Playback Audio Setting Good morning! Bon jour! You can select the preferred audio language and sound system as a set from those included on the disc. This function lets you temporarily change the audio language which you selected as the automatic setting in the setting menu (see pages 30 and 31), and choose the sound system if the disc is recorded in more than one sound format.

  • Page 23: Changing The Camera Angle

    Using Banner Display Changing the Camera Angle Angle : 1 Angle : 2 Angle : 3 If the scene was recorded from multiple angles, you can easily change the camera angle of the scene you are watching. Press On SCREEN during playback. Press 2/3 until the Angle icon is highlighted.

  • Page 24: Using A Bookmark

    Using Banner Display Using a Bookmark The bookmark feature lets you mark a point on the disc that you can go to quickly. You can store up to 9 bookmarks. Marking a scene Press ON SCREEN during playback. Press 2/3 until the bookmark icon is highlighted and press ENTER.

  • Page 25: Other Operations

    Other Operations CD PLAY Function Since the DVD Changer allows you to insert up to five discs in any combination, there may be times when you only want to listen to music. In that case, proceed as follows: Press CD PLAY on the unit. CD indicator illuminates on the display.

  • Page 26: Repeat Play

    Other operations Repeat Play Desired disc or title can be played back repeatedly. There are five repeat options: • All Discs Repeat all discs. • 1 Disc Repeat the disc that is playing. • Title Repeat the title that is playing. •...

  • Page 27: Memory Play

    Other operations Memory Play Title : 2 Title : 2 Title : 2 Title : 2 Title : 1 Title : 1 Chapter : 25 Chapter : 25 Chapter : 12 Chapter : 12 Chapter : 1 Chapter : 1 The DVD Changer automatically plays discs, titles, chapters, or tracks in the order you program.

  • Page 28: Selecting Mp3 Files

    MP3 Function Playing Back MP3 The DVD Changer can play back MP3 files recorded on CD-R or CD-RW. Press £. When you insert MP3 media, playback will start automatically. MP3 On-screen display appears. To stop playback Press 7. To skip files Press 4/¢.
  • Page 29 MP3 Function To move to the upper layer Press ENTER on return folder icon. To select the folders to be played directly 1 During stop mode, press 5/∞ to select the folder, then press ENTER. 2 Press 5/∞ to select the upper folder icon, then press £. Playback will start from selected folder.

  • Page 30: Customizing The Settings

    Customizing the Settings When you insert a DVD-Video, Video CD, or CD, the various functions of the DVD Changer will be set (reset) according to the setting menu. You can customize this setting menu according to your preferences. Making Adjustments to Setting Press MENU during stop mode.

  • Page 31: Language Setting

    Customizing the Settings Language-related settings Language Setting Audio Language This sets the language to be used when playing a disc. If a disc does not contain the selected language, it is played in the priority language set for each disc. English: To play sound tracks in English.

  • Page 32: Operation Setting

    Customizing the Settings General utility settings Operation Setting Rating/Parental lock This can restrict playback of adult-oriented DVD discs that you do not want to be seen by children. However, even when a DVD disc is marked “Adult-oriented” or otherwise on the label, its viewing cannot be restricted unless the restriction level is recorded in the disc itself.
  • Page 33 Customizing the Settings Operation Setting (continued) To change password Press the numeric buttons to enter password. Select OK button and press ENTER. Password setup menu appears. Select “Change Password”. Enter Password menu appears. Press the numeric buttons to enter new password. Select OK button and press ENTER.

  • Page 34: Picture Setting

    Customizing the Settings Picture-related setting Picture Setting TV Aspect This sets the screen size (4:3 or 16:9 aspect ratio) according to the connected TV. 4 x 3 Letterbox: Choose this setting if you would prefer to see movies in their original aspect ratio.

  • Page 35: Digital Audio Out

    Customizing the Settings Audio Setting (continued) Digital Audio Out This sets the type of audio output from the digital audio output jack. PCM: Select when connected to a 2 channel digital stereo amplifier (see page 16). The DVD Changer outputs sounds in the PCM format when you play a DVD-Video disc recorded on the Dolby Digital.

  • Page 36: Table Of Languages

    Table of Languages Table of Languages and Their Code No. Code No. Language Abkhazian 6566 Afar 6565 Afrikaans 6570 Albanian 8381 Ameharic 6577 Arabic 6582 Armenian 7289 Assamese 6583 Aymara 6588 Azerbaijani 6590 Bashkir 6665 Basque 6985 Bengali; Bangla 6678 Bhutani 6890 Bihari...

  • Page 37: Troubleshooting

    • Switch off the main power, then switch it on again. If not recovered, disconnect the power cord, then connect it again. • Contact your nearest Onkyo service center. • Insert a disc. (Check that “DVD,” “VCD,” or “CD” is lit in the DVD Changer’s display).

  • Page 38: Specifications

    Specifications DVD Changer Power supply Power consumption Weight External dimensions Signal system Frequency range (digital audio) Signal-to-noise ratio (digital audio) Audio dynamic range (digital audio) Harmonic distortion (digital audio) Wow and flutter Operating conditions Outputs Video output S-video output Component video output Audio output (digital output Optical) Audio output (digital output Coaxial) Audio output (analog output)
  • Page 39 Memo...
  • Page 40 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.onkyousa.com ONKYO EUROPE ELECTRONICS GmbH Industriestrasse 20, 82110 Germering, GERMANY Tel: 089-849-320 Fax: 089-849-3265 E-mail: info@onkyo.de ONKYO CHINA LIMITED Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung, HOMEPAGE N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039...
