DVD Changer
DV-CP704
Instruction Manual
Thank you for purchasing an Onkyo DV-CP704
DVD Changer. Read this manual carefully
before using your new DVD Changer. A good
understanding of its features and operation will
allow you to achieve optimum performance and
enjoyment.
Keep this manual for future reference.
Contents
Overview ..............................................2
Connections ......................................17
Getting Started and Setting up ........22
Basic Playback ..................................23
Playback Techniques ........................34
Detailed Settings ...............................42
Miscellaneous information ...............49
E
n

Advertisement

Table of Contents
loading

Related Manuals for Onkyo DV CP704

Summary of Contents for Onkyo DV CP704

  • Page 1 DVD Changer DV-CP704 Instruction Manual Thank you for purchasing an Onkyo DV-CP704 DVD Changer. Read this manual carefully before using your new DVD Changer. A good understanding of its features and operation will allow you to achieve optimum performance and enjoyment.

  • Page 2: Important Safety Instructions

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING QUALIFIED PERSONNEL.

  • Page 3: Precautions

    5. Never Touch this Unit with Wet Hands—Never handle this unit or its power cord while your hands are wet or damp. If water or any other liquid gets inside this unit, have it checked by your Onkyo dealer. 6. Handling Notes •...
  • Page 4 Precautions—Continued This unit contains a semiconductor laser system and is classified as a “CLASS 1 LASER PRODUCT”. So, to use this model properly, read this Instruction Manual carefully. In case of any trouble, please contact the store where you purchased the unit. To prevent being exposed to the laser beam, do not try to open the enclosure.

  • Page 5: Table Of Contents

    Contents Important Safety Instructions ... 2 Precautions... 3 Contents... 5 Introduction ... 6 Supplied Accessories...6 DV-CP704 Features ...6 Disc Notes ...7 DV-CP704-related Terminology...10 Controls & Connectors... 11 Front Panel ...11 Display ...12 Rear Panel ...13 Remote Controller ...14 Before Using the DV-CP704 ... 16 Installing the Remote Controller’s Batteries ...16 Using the Remote Controller...16...

  • Page 6: Introduction

    Microsoft Corporation in the United States and/or other coun- tries. *4. VLSC and the VLSC logo are registered trademarks of Onkyo Corporation. *5. HDMI, the HDMI logo and High-Definition Multimedia Inter- face are trademarks or registered trademarks of HDMI licens- ing LLC.

  • Page 7: Disc Notes

    JPEG JPEG file About this Manual This manual explains how to use all of the DVD player’s functions. Although the DVD standard offers many spe- cial features, not all discs use them all, so depending on the disc being played, the DVD player may not respond to certain functions.

  • Page 8: About Wma

    Introduction —Continued Disc Content Organization ■ DVD-Video Format DVD-Video discs contain titles, which are usually subdi- vided into chapters. Title 1 Chapter 1 Chapter 2 DVD-Video ■ Audio CD Format Audio CDs contain tracks. Track 1 Track 2 Track 3 Audio CD ■...
  • Page 9 Introduction —Continued Handling Discs • Never touch the underside of a disc. Always hold discs by the edge, as shown. Underside • Never attach adhesive tape or sticky labels to discs. Cleaning Discs • For best results, keep your discs clean. Fingerprints and dust can affect the sound and picture quality and should be removed as follows.

  • Page 10: Dv-Cp704-Related Terminology

    Introduction —Continued DV-CP704-related Terminology ■ CD-R (compact disc recordable): A type of CD that can be recorded only once. Can be used to make audio CDs, or MP3/WMA/JPEG discs. ■ CD-RW (compact disc rewritable): A type of CD that can be recorded many times. Can be used to make audio CDs, MP3/WMA/JPEG discs.

  • Page 11: Controls & Connectors

    Controls & Connectors Front Panel H I J K The page numbers in parentheses show where you can find the main explanation for each item. STANDBY/ON button (22, 45) This button is used to set the DV-CP704 to On or Standby.

  • Page 12: Display

    Controls & Connectors—Continued Display CHAIN MODE DISC The page numbers in parentheses show where you can find the main explanation for each item. CHAIN MODE, ALL, DVD & CD indicators (33) The CHAIN MODE indicator appears when the Chain mode function is on. The ALL, DVD, and CD indicators show the type or Chain mode selected.

  • Page 13: Rear Panel

    These (Remote Interactive) connectors can be connected to the connectors on your other Onkyo AV components for interactive control. ANALOG AUDIO OUTPUT These RCA/phono connectors can be connected to analog audio inputs on a hi-fi amp, or AV receiver. COAXIAL AUDIO OUTPUT This coaxial digital audio output can be connected to a coaxial digital audio input on a hi-fi...

  • Page 14: Remote Controller

    Controls & Connectors—Continued Remote Controller The page numbers in parentheses show where you can find the main explanation for each item. ON button (22) This button is used to turn on the DV-CP704. Don’t turn on the DV-CP704 until you’ve com- pleted, and double checked all connections (page 17).
  • Page 15 Controls & Connectors—Continued ASPECT/ZOOM button (41, 44) This button is used to change the view mode. Press- ing and holding it for a few seconds selects Zoom mode. RESOLUTION button (39) This button is used to set the video resolution of the HDMI OUT, and to turn the HDMI OUT on or off.

  • Page 16: Before Using The Dv-Cp704

    Before Using the DV-CP704 Installing the Remote Controller’s Batteries Open the battery compartment, as shown. Insert the two supplied batteries (AA/ R6) in accordance with the polarity dia- gram inside the battery compartment. Close the battery compartment. Notes: • If the remote controller doesn’t work reliably, try replacing both batteries.

  • Page 17: Connecting The Dv-Cp704

    Connecting the DV-CP704 This chapter explains how to connect the DV-CP704 to your other AV components. Before Making Any Connections • Read the manuals supplied with your AV components. • Don’t connect the power cord until you’ve completed all audio and video connections. Optical Digital Jack The DV-CP704’s optical digital jack has shutter-type cover that open when an optical plug is inserted and...

  • Page 18: Connecting Your Tv Or Projector

    MENDED THAT THE USER SWITCH THE CON- NECTION TO THE “STANDARD DEFINITION” OUTPUT. IF THERE ARE QUESTIONS REGARD- ING OUR TV SET COMPATIBILITY WITH THIS MODEL 525p AND 625p DVD PLAYER, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER. Component video cable...

  • Page 19: Connecting An Av Receiver

    Connecting the DV-CP704—Continued Connecting an AV receiver To enjoy Dolby Digital or DTS surround sound, you need to connect one of the DV-CP704 digital audio out- puts to the digital input on a Dolby Digital or DTS decoder or an AV receiver with built-in decoders. Analog Connection Use an RCA/phono audio cable to connect the DV-CP704’s ANALOG AUDIO OUTPUTs to a pair of...

  • Page 20: Connecting A Component With An Hdmi Input

    Connecting the DV-CP704—Continued Digital Connection Use an optical (or coaxial) digital audio cable to connect the DV-CP704’s COAXIAL (or OPTICAL) DIGITAL AUDIO OUTPUT to an optical (or coaxial) input on your stereo amp, as shown. XIAL Connect one or the other COAXIAL OPTICAL Coaxial...

  • Page 21: Connecting -Compatible Components

    -compatible Components AV receiver REMOTE CONTROL • The remote controller supplied with Onkyo AV receiver or amplifiers can be used to control the DV-CP704. • The function of the upper and lower the same. Connect to either one. • Connecting an cable only does not make the sys- tem operational.

  • Page 22: Dv-Cp704

    Powering Up & Setting Up the DV-CP704 STANDBY/ON STANDBY indicator Powering Up the DV-CP704 Before connecting the power cord, connect all your AV components (see page 17 to page 21). Don’t forget to turn on your TV or projector and select the video input to which the DV-CP704 is connected.

  • Page 23: Basic Playback

    Basic Playback DISC DISC SKIP SELECT OPEN/CLOSE PLAY Loading & Removing Discs JPEG This section explains how to load and remove discs. Press the OPEN/CLOSE [ button. The disc tray opens and the six disc number indicators appear on the dis- Remote controller play.

  • Page 24: Loading Discs During Playback

    Basic Playback—Continued DISC DISC SKIP SELECT Loading Discs During Playback This section explains how to load and remove discs with- out stopping playback. Press the OPEN/CLOSE [ button. The disc tray opens. The disc that’s currently playing remains inside the DV-CP704 and its Remote controller disc bay is empty and won’t come to the front.

  • Page 25: Starting, Pausing & Stopping Playback

    Basic Playback—Continued PAUSE STOP PLAY ENTER Starting, Pausing & Stopping Playback This section explains how to start, pause, and stop play- back. ■ Start To start playback, press the Play [ ] button. Playback starts and the Play tor appears on the display. If the disc is a DVD-Video, you may need to start playback from a menu (see Remote controller...

  • Page 26: Navigating Disc Menus

    Basic Playback—Continued AUDIO ENTER TOP MENU MENU Navigating Disc Menus DVD-Video discs usually have an onscreen menu from which you can select titles, chapters, and other options, including foreign language soundtracks, subtitles, and audio formats (e.g., Dolby Digital or DTS). Load and select a DVD-Video disc.

  • Page 27: Using The Disc Navigation Window

    00:05:06 00:05:30 Repeat : Off Ramdom : Off Artist Name: Onkyo Artist Folder number and file number. Elapsed time, remaining time, and total time of currently playing song. (Only elapsed time is shown for WMA files.) (See also page 41.) Repeat function and Random function status.

  • Page 28: Selecting Titles, Chapters & Tracks By Number

    Basic Playback—Continued If the disc contains MP3/WMA files and JPEG files, they are played/dis- played in order. JPEG files will be dis- played in a slideshow. Press the [TOP MENU] button to display the first nine pictures at thumbnail-size (see page 32). Depending on the disc, the first nine pictures may be displayed automatically.

  • Page 29: Locating Specific Points In Time

    Basic Playback—Continued Use the number buttons to spec- ify a chapter or title. Remote controller To enter, for example, “2,” press the [2] button. Step Disc 1: DVD Search Disc Title 1:DVD-VIDEO Current/Total To enter, for example, “12,” press the [1] button, followed by the [2] button.

  • Page 30: Fast Forward & Reverse

    Basic Playback—Continued PAUSE PLAY Fast Forward & Reverse The section explains how to fast forward and reverse. ■ Fast During playback, press the Fast forward Forward [ forward. Remote controller Playback fast forwards and “x 2” appears onscreen. To change the fast-forward speed, press the Fast Forward [ edly to select: x 2, x 4, x 8, or x 16.

  • Page 31: Slow-Motion Playback

    You can adjust the brightness of the display as follows. ] button repeat- Notes: • When the display brightness on another Onkyo AV component connected via tray light off” option might not work. • Even if you selected the “disc tray light off” option, the disc tray light will come on when the disc tray is opened.

  • Page 32: Using Jpeg Cds

    Basic Playback—Continued PAUSE STOP PLAY ENTER TOP MENU MENU Using JPEG CDs The DV-CP704 supports JPEG CDs, so you can view your photos on TV either individually or as a slideshow. Load and select a CD containing JPEG pictures. The slideshow starts automatically. See “Using the Disc Navigation Win- dow”...

  • Page 33: Using Chain Mode

    Basic Playback—Continued CHAIN MODE Using Chain Mode With the Chain mode function, you can play all discs, all DVD-Video discs, or all audio CDs and MP3/WMA discs consecutively as if they were one big disc. Press the [CHAIN MODE] button repeatedly to select CD, DVD, or Remote controller ALL.

  • Page 34: Advanced Playback

    Advanced Playback REPEAT RANDOM Repeat Playback JPEG With the Repeat Playback function you can play the cur- rent disc, title, chapter, track, or folder of MP3/WMA files over-and-over again. Press the [REPEAT] button repeatedly to select a repeat option. The currently selected repeat option appears onscreen and “REPEAT”...

  • Page 35: Random Playback

    Advanced Playback—Continued Random Playback With the Random Playback function you can enjoy a random selection of discs, titles, chapters, tracks, or MP3/WMA folders. Select a disc. See page 24. Press the [RANDOM] button repeatedly to select a random Remote controller option.

  • Page 36: Memory Playback

    Advanced Playback—Continued Number buttons ENTER Memory Playback With the Memory Playback function, you can create your own memory list of up to 32 titles, chapters, or tracks. Press the [MEMORY] button. The Memory List window appears Remote controller onscreen, as shown. No.

  • Page 37: Selecting Camera Angles

    Advanced Playback—Continued Deleting Items from the List To delete an item, use the Up/ Remote controller Down [ ]/[ ] buttons to select it, and then press the [CLR] button. The item is deleted and subsequent items move up the list. Editing Steps To edit a step, use the Up/Down [ ]/[ ] buttons to select it, edit...

  • Page 38: Selecting Languages & Audio Formats

    Advanced Playback—Continued AUDIO Selecting Languages & Audio Formats Some DVD-Video discs feature soundtracks in several languages and audio formats (e.g., Dolby Digital or DTS). Music DVD-Video discs sometimes feature soundtracks in several audio formats, such as PCM or Dolby Digital 5.1. See the disc’s sleeve notes for details. During playback, press the Remote controller [AUDIO] button repeatedly to...

  • Page 39: Setting The Hdmi

    Advanced Playback—Continued RESOLUTION Setting the HDMI This section explains how to turn HDMI on and off and change the video resolution when your TV or projector is connected to the HDMI OUT. Press the [RESOLUTION] button to turn HDMI on or off. If HDMI is off, “HDMI OFF”...

  • Page 40: Using Last Memory

    Advanced Playback—Continued STOP PLAY Using Last Memory With the Last Memory function you can resume play- back from where you left off even if another disc has been selected or the disc has been removed. Last Mem- ory also remembers the soundtrack and subtitle lan- guages that you were using.

  • Page 41: Zooming

    Advanced Playback—Continued DISPLAY ZOOM Zooming JPEG DVD-V With the Zoom function you can enlarge any part of the picture. During playback or paused, press and hold the [ZOOM] but- Remote controller ton. The picture is enlarged. Press the [ZOOM] again repeat- edly to Zoom in.

  • Page 42: Configuring The Dv-Cp704

    Configuring the DV-CP704 This chapter explains the various functions and settings of the onscreen setup menus. Functions and settings are arranged into six menus: Picture, Audio, Language, Display, Operation Setting, and Initial. The following table lists all the functions and settings, with a brief description and page number where you can find full details.

  • Page 43: Using The Onscreen Setup Menus

    Configuring the DV-CP704—Continued ENTER SETUP Using the Onscreen Setup Menus This section explains how to use the onscreen setup menus. Turn on your DV-CP704 and TV. On your TV, select the video input to which the DV-CP704 is connected. Press the [SETUP] button. The onscreen setup menu appears, as Remote controller shown.

  • Page 44: View Mode

    Configuring the DV-CP704—Continued View Mode With this setting you can adjust the aspect of the picture so that it fits your TV screen. Due to your TV’s aspect ratio setting and the DVD’s aspect ratio, black bars may appear above and below the picture or at the sides and the aspect of the picture may be unsuitable.

  • Page 45: Audio Menu

    Configuring the DV-CP704—Continued Video Black Level With this setting you can adjust the picture blackness of analog video output. Blacks are lighter, and the entire picture Light: becomes lighter. Blacks are darker, and the entire picture Dark: becomes darker. Brightness With this setting you can adjust the picture brightness.

  • Page 46: Language Menu

    Configuring the DV-CP704—Continued Language Menu On-Screen Language With this setting you can select a language for the onscreen setup menus and messages. Select one of the displayed language. Disc Menu Language With this setting you can select your preferred language for disc menus.

  • Page 47: Operating Setting Menu

    Configuring the DV-CP704—Continued Operating Setting Menu Parental Lock With the Parental Lock function you can block access to certain scenes that the authors have flagged as being unsuitable for children. To use parental lock, you must set a security code. Select “Operation Setting”...

  • Page 48: Initial Setup Menu

    Configuring the DV-CP704—Continued Initial Setup Menu This menu appears automatically the very first time you turn on the DV-CP704. See “First Time Setup” on page 22 for more information. TV Shape—see page 43 HDMI Output Setting—see page 44 On-Screen Language—see page 46 Selecting Other Languages This section explains how to select other languages for disc menus, audio, and subtitles.

  • Page 49: Troubleshooting

    No Sound from the HDMI OUT? The Digital/HDMI Audio Out setting is set to Off. No sound? The DVD player is connected to the DVI jack on your TV or AV receiver. The HDMI setting on your TV or AV receiver is set to DVI.
  • Page 50 Troubleshooting—Continued Symptom No sound? The picture distorts occasionally? Picture instability or noise? Can’t start playback? Can’t play MP3/WMA/ JPEG discs? Can’t select MP3 files? Can’t play WMA files? Can’t view JPEG files? The message “BAD DISC” appears on the display? Buttons on the DV-CP704 and remote controller don’t work?
  • Page 51 ■ Restoring the Default Settings To reset the DV-CP704 to its factory defaults, turn it on, and when “ONKYO DVD” has disappeared from the display, while holding down the Stop [ ] button, press the [STANDBY/ON] button. “INITIALIZE” appears on the display.

  • Page 52: Specifications
