Instruction Manual
SERVICE MANUAL
SERVICE MANUAL
DVD CHANGER
DV-CP500
MODEL
Black model
BMDD
120V AC, 60Hz
SAFETY-RELATED COMPONENT
WARNING!!
THE MARK
FOUND ON SOME COMPONENT
PARTS INDICATES THE CRITICAL FOR RISK OF
FIRE AND ELECTRIC SHOCK.
WHEN REPLACING, BE SURE TO USE PARTS OF
IDENTICAL DESIGNATION.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
DV-CP500
Ref. No. 3734
072002
Advertisement
Table of Contents
Related Manuals for Onkyo DV-CP500
Summary of Contents for Onkyo DV-CP500
- Page 1 DV-CP500 Ref. No. 3734 072002 SERVICE MANUAL SERVICE MANUAL DVD CHANGER DV-CP500 MODEL Black model BMDD 120V AC, 60Hz SAFETY-RELATED COMPONENT WARNING!! THE MARK FOUND ON SOME COMPONENT PARTS INDICATES THE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. WHEN REPLACING, BE SURE TO USE PARTS OF IDENTICAL DESIGNATION.
-
Page 2: Specifications
DV-CP500 SPECIFICATIONS DVD Changer Power supply AC 120 V, 60 Hz Power consumption 20 W Weight 15.4 lbs External dimensions " x 5 " x 16 " (W/H/D) Signal system NTSC Frequency range (digital audio) 48 kHz sampling 4 Hz to 22 kHz... -
Page 3: Service Procedure
DV-CP500 SERVICE PROCEDURE PRECAUTIONS 1. Ground for the work-desk. Place a conductive sheet such as a sheet of copper (with impedance lower than 10M ohm) on the work-desk and place the set on the conductive sheet so that the chassis. - Page 4 DV-CP500 EXPLODED VIEW Chassis (19)
-
Page 5: Exploded View
DV-CP500 EXPLODED VIEW-2 CLAMPER DVD ASS'Y DVD Mechanism Part No. 55542660 BASE ASS'Y - CDM5G Part No.55542650 160 150 280 * 2 300 * 2 450 * 4 460 * 4 270 * 2 Assy Part No. 55542660 5000 300 P406... - Page 6 DV-CP500 BLOCK DIAGRAM-0 OVERALL...
-
Page 7: Block Diagram
DV-CP500 BLOCK DIAGRAM - 1 MAIN CIRCUIT BOARD IC61 IC-CONV WN8728 D/A IC-OPEAMP To OUT BA4560F CP25:04PIN CP25:06PIN To OUT CN27:SPDIF IC-LOGIC 74HC74 IC-LOGIC 74HC86 FLIF/FLOP CMOS GATE HCMOS To Mechanism control INVERTER HCT IC-LOGIC M74HCU04M1R To OUT CP25:08PIN CP25:10PIN... -
Page 8: Display Section
DV-CP500 BLOCK DIAGRAM - 2 DISPLAY SECTION From Power supply unit To Main PC board Key matrix... - Page 9 DV-CP500 BLOCK DIAGRAM - 3 DVD MECHANISM & OUTPUT CIRCUIT AUDIO/VIDEO JACK MECHANISM CONTROL PC BOARD AUDIO/VIDEO JACK PICK UP Flat cable...
-
Page 10: Power Supply Unit
DV-CP500 BLOCK DIAGRAM - 4 POWER SUPPLY UNIT FL OUTPUT RECTIFIER & SMOOTHING CIRCUIT HOT > SNUBBER RECTIFIER & AC INPUT LINE FILTER SMOOTHING CIRCUIT CIRCUIT -27V OUTPUT NUT > RECTIFIER & SMOOTHING CIRCUIT -9V OUTPUT RECTIFIER & SMOOTHING CIRCUIT... - Page 11 DV-CP500 SCHEMATIC DIAGRAM +3V3 +5VA +5VD +3V3 R219 JTAG TEST CONNECTION 10P-03 0R-03 MAIN CIRCUIT PC BOARD C613 R220 10P-03 0R-03 R612 4K7-03 C612 10P-03 10/50 47/16 IC61 C611 C603 C601 WM8728(SSOP) 10P-03 FPC_ST_15P LRCIN LAT125 100R-03 CP23 C604 C602...
- Page 12 SCHEMATIC DIAGRAM 1 MAIN CIRCUIT PC BOARD IC51 L501 FCM2012H-102T04 74HCU04 D3V3 100R-03 R504 100R-03 1M-03 R501 R503 X501 X-TAL +3.3VM R404 R403 R402 R415 R401 FCM2012H-102T04 F_DATA00 RA41 47R F_DATA01 F_DATA02 47K-03 F_DATA03 R413 F_DATA04 RA42 47R F_DATA05 F_DATA06 +3V3 F_DATA07 F_ADDR17...
- Page 13 DV-CP500 +3V3 +5VA +5VD +3V3 R219 JTAG TEST CONNECTION 10P-03 0R-03 C613 R220 10P-03 R612 0R-03 4K7-03 C612 10P-03 10/50 47/16 IC61 C611 C603 C601 WM8728(SSOP) 10P-03 FPC_ST_15P LRCIN LAT125 100R-03 CP23 C604 C602 C610 47/16 R65L 1: TRIGOUT 560P-03...
- Page 14 DV-CP500 SCHEMATIC DIAGRAM 2 OUTPUT TERMINAL PC BOARD From Main PC Board Filter circuit...
-
Page 15: Schematic Diagram
SCHEMATIC DIAGRAM 2 OUTPUT TERMINAL PC BOARD From Main PC Board... - Page 16 DV-CP500 Filter circuit...
- Page 17 DV-CP500 SCHEMATIC DIAGRAM 3 DISPLAY CIRCUIT PC BOARD From Power supply unit FL Tube FL91 STANDBY LED PC BOARD To Standby LED To Front OPEN/ CLOSE SWITCH PC BOARD...
- Page 18 SCHEMATIC DIAGRAM 3 DISPLAY CIRCUIT PC BOARD STANDBY LED PC BOARD To Standby LED To Front OPEN/ CLOSE SWITCH PC BOARD...
- Page 19 DV-CP500 From Power supply unit FL Tube FL91...
-
Page 20: Mechanism Section
DV-CP500 SCHEMATIC DIAGRAM 4 MECHANISM SECTION CAROUSEL MOTOR PC BOARD... - Page 21 DV-CP500 SCHEMATIC DIAGRAM 5 POWER SUPPLY UNIT 1N5819 10V470 D1-D4 EER2828 10D-9 1N4007 3.3V 250V2A UF4003 POWER +5.65 50V100 TNR1 4.7K 10471K 1/4W 2W47K 200V100 630V472 20MH UF4003 50V100 SR206 4.7uH KA7809 1KV102 1KV101 330K UF4007 25V470 25V470 50V22 -12V...
-
Page 22: Signal Waveform
DV-CP500 SIGNAL WAVEFORM-1 IC21 PIN 16 (EXT_DATA) IC21 PIN 17 (EXT_BCLK) IC21 PIN 18 (DATA_VALID) IC21 PIN 19 (SECTOR_START) - Page 23 DV-CP500 SIGNAL WAVEFORM-2 IC21 PIN 51 (PCM_CLK) IC21 PIN 55 (PCM_MCLK) IC21 PIN 56 (PCM_LRCLK) IC21 PIN 57 (SPDIF)
- Page 24 DV-CP500 SIGNAL WAVEFORM-3 IC21 PIN 82 (SMI_CLK) IC21 PIN (PIX_CLK) IC22 PIN 5 (IIC_DATA) IC22 PIN 6 (IIC_CLK)
- Page 25 DV-CP500 SIGNAL WAVEFORM-4 IC11 PIN 23 (DAO_Y) IC11 PIN 25 (DAO_B) IC11 PIN 27 (DAO_R)
- Page 26 DV-CP500 SIGNAL WAVEFORM-5 IC11 PIN 58 (PIX_CLK) IC11 PIN 78 (V_SYNC) Signal: 100% Color Bar (Interlace Mode) IC11 PIN79 (H_SYNC) IC12 PIN 19 (Cr)
- Page 27 DV-CP500 SIGNAL WAVEFORM-6 IC12 PIN 22 (Cb) IC12 PIN 25 (CY) IC12 PIN 28 (Y_OUT) IC12 PIN 31 (CVBS)
- Page 28 DV-CP500 SIGNAL WAVEFORM-7 Signal 100% Color bar (Progressive Model) IC12 PIN 33 (CHROMA) IC12 PIN 19 (Cr) IC12 PIN 22 (Cb) IC12 PIN 25 (CY)
- Page 29 DV-CP500 PC BOARD CONNECTION DIAGRAM CP25 CN25 OUTPUT TERMINAL PC BOARD MAIN CIRCUIT PC BOARD CN27 P406 MECHANISM CONTROL CP22 CN21 PC BOARD CN26 P003 CP94 CP95 To Roulette Roulette motor motor PC board STANDBY LED DISPLAY CIRCUIT PC BOARD...
-
Page 30: Printed Circuit Board View
DV-CP500 PRINTED CIRCUIT BOARD VIEW 1 MAIN CIRCUIT PC BOARD Top pattern and Top component... - Page 31 DV-CP500 PRINTED CIRCUIT BOARD VIEW 1 MAIN CIRCUIT PC BOARD Bottom pattern and Bottom component...
- Page 32 DV-CP500 PRINTED CIRCUIT BOARD FROM SOLDERING SIDE VIEW 2 Display circuit PC board FL91 J901 S903 S901 STOP PLAY/PAUSE S905 S907 C909 DISC SKIP CN93 RM91 S927 S924 S915 S911 S921 S917 S913 J920 C901 Component side FL91 S905 S907...
- Page 33 PRINTED CIRCUIT BOARD FROM SOLDERING SIDE VIEW 2 Display circuit PC board S903 S901 STOP PLAY/PAUSE S905 S907 DISC SKIP CN93 S911 S927 S924 S915 S921 S917 S905 S907 S915 S924 S917 S927 S921...
- Page 34 DV-CP500 PRINTED CIRCUIT BOARD FROM SOLDERING SIDE VIEW 3 Output terminal PC board JK82 JK83 JK81 IC85 C802 Component side Soldering side...
- Page 35 DV-CP500 FL91 J901 C909 RM91 S913 J920 C901 Component side FL91 IC91 S913 Soldering side...
- Page 36 DV-CP500 PRINTED CIRCUIT BOARD FROM SOLDERING SIDE VIEW 3 Output terminal PC board JK82 JK83 JK81 IC85 C802 Component side Soldering side...
- Page 37 PRINTED CIRCUIT BOARD FROM SOLDERING SIDE VIEW 3 Output terminal PC board...
- Page 38 DV-CP500 JK82 JK83 JK81 IC85 C802 Component side Soldering side...
- Page 39 DV-CP500 PRINTED CIRCUIT BOARD VIEW 4 Roulette motor PC board P1004 D-PHOTO RP1574/GP1S58V D-PHOTO GP2S28 WCL 060-05 UL24 P1003 Component side view Mechanism control PC board C002 JW18 IC001 R003 R004 D002 IC002 C004 Component side view Soldering side view...
- Page 40 PRINTED CIRCUIT BOARD VIEW 4 Roulette motor PC board P1004 D-PHOTO RP1574/GP1S58V D-PHOTO GP2S28 WCL 060-05 UL24 P1003 Component side view Mechanism control PC board...
- Page 41 DV-CP500 C002 JW18 IC001 R003 R004 D002 IC002 C004 Component side view Soldering side view...
- Page 42 DV-CP500 PRINTED CIRCUIT BOARD FROM SOLDERING SIDE VIEW 5 Standby LED PC board Connection PC board CP94 S931 D905 Component side CP95 Soldering side Soldering side DPC-5.3 OPEN/CLOSE Switch PC board CP93 OPEN/CLOSE S930 Soldering side Soldering side...
- Page 43 DV-CP500 MICROPROCESSOR TERMINAL DESCRIPTION IC91: CXP82532 -1 (Key, Display, remote controller) IN/OU PIN NAME MAIN FUNCTION REMARK NUMBER PE3/INT3 INPUT FOR EXTERNAL INTERRUPT REQUEST. PE4/RMC INPUT FOR REMOTE CONTROL RECEIVING CIRCUIT. PE7/TO OUTPUT PIN FOR 16-BIT TIME/COUNTER RECTANGULAR WAVEFORM. PBO/CINT EXTERNAL CAPTURE INPUT FOR 16-BIT TIME/COUNTER.
- Page 44 Microprocessor terminal description FRONT IC91 CXP82532 PIN LIST IN/OU PIN NAME MAIN FUNCTION REMARK NUMBER PE3/INT3 INPUT FOR EXTERNAL INTERRUPT REQUEST. PE4/RMC INPUT FOR REMOTE CONTROL RECEIVING CIRCUIT. PE7/TO OUTPUT PIN FOR 16-BIT TIME/COUNTER RECTANGULAR WAVEFORM. PBO/CINT EXTERNAL CAPTURE INPUT FOR 16-BIT TIME/COUNTER. PBI/'CSO CHIP SELLECT INPUT FOR SERIAL INTERFACE(CH0).
- Page 45 IN/OU PIN NAME MAIN FUNCTION REMARK NUMBER T11/S25 DUAL PURPOSE OUTPUT FOR FDP TIMING AND SEGMENT SIGNAL. T10/S26 DUAL PURPOSE OUTPUT FOR FDP TIMING AND SEGMENT SIGNAL. T9/S27 DUAL PURPOSE OUTPUT FOR FDP TIMING AND SEGMENT SIGNAL. T8/S28 DUAL PURPOSE OUTPUT FOR FDP TIMING AND SEGMENT SIGNAL. TIMING SIGNAL OUTPUT FOR FDP TIMING SIGNAL OUTPUT FOR FDP TIMING SIGNAL OUTPUT FOR FDP...
- Page 46 DV-CP500 MICROPROCESSOR TERMINAL DESCRIPTION IC21: STI5519 MPEG VIDEO DECODER-1 ALTERNATE FUNCTION PIN NUMBER DESCRIPTION PIN NAME MAIN FUNCTION TYPE REMARK INPUT OUTPUT PIOs and communication PIO2[5] PIO2[5] PIOs and communication PIO2[6] PIO2[6] PIOs and communication PIO2[7] PIO2[7] VDD3_3 3.3V POWER SUPPLY...
- Page 47 DV-CP500 MICROPROCESSOR TERMINAL DESCRIPTION IC21: STI5519 MPEG VIDEO DECODER-2 ALTERNATE FUNCTION PIN NUMBER DESCRIPTION PIN NAME MAIN FUNCTION TYPE REMARK INPUT OUTPUT Video DAC I_REF_YCC I_REF_DAC_YCC VDD2_5 2.5V POWER SUPPLY POWER GROUND POWER PIOs and communication PIO4[0] PIO4[0] YC[0] PIOs and communication...
- Page 48 DV-CP500 MICROPROCESSOR TERMINAL DESCRIPTION IC21: STI5519 MPEG VIDEO DECODER-3 ALTERNATE FUNCTION PIN NUMBER DESCRIPTION PIN NAME MAIN FUNCTION TYPE REMARK INPUT OUTPUT Share memory interface SMI_CS[0] CHIP SELECT BANK0 Share memory interface SMI_CS[1] CHIP SELECT BANK1 Share memory interface SMI_RAS...
- Page 49 DV-CP500 MICROPROCESSOR TERMINAL DESCRIPTION IC21: STI5519 MPEG VIDEO DECODER-4 ALTERNATE FUNCTION PIN NUMBER DESCRIPTION PIN NAME MAIN FUNCTION TYPE REMARK INPUT OUTPUT JTAG TEST DATA IN JTAG TEST CLOCK TIMER PWM2 PULSE WITDH MODULA2 VSYNC TIMER PWM1 PULSE WITDH MODULA1...
- Page 50 DV-CP500 MICROPROCESSOR TERMINAL DESCRIPTION IC21: STI5519 MPEG VIDEO DECODER-5 ALTERNATE FUNCTION PIN NUMBER DESCRIPTION PIN NAME MAIN FUNCTION TYPE REMARK INPUT OUTPUT GROUND POWER EMI Interface CPU_DATA[8] DATA[8] EMI Interface CPU_DATA[9] DATA[9] EMI Interface CPU_DATA[10] DATA[10] EMI Interface CPU_DATA[11] DATA[11]...
- Page 51 DV-CP500 MICROPROCESSOR TERMINAL DESCRIPTION IC21: STI5519 MPEG VIDEO DECODER-6 ALTERNATE FUNCTION PIN NUMBER DESCRIPTION PIN NAME MAIN FUNCTION TYPE REMARK INPUT OUTPUT PIOs and communication PIO0[2] PIO0[2] ATAPI_WR PIOs and communication PIO0[3] PIO0[3] PIOs and communication PIO0[4] PIO0[4] PIOs and communication...
-
Page 52: Parts Name
DV-CP500 EXPLODED VIEW PARTS LIST PARTS No PARTS NAME 55384980 XX BADGE DVD 55184480 XX DOOR TRAY 55221120 XX WINDOW DISPLAY 55186750 XX BADGE LOGO DV-C503 55186710 XX FACET ST/BY 55244650 XX BUTTON POWER 55244620 XX SHAFT KNOB POWER 55184600... - Page 53 DISPLAY PC BOARD (INCLUDED OPEN/CLOSE SW PCB+ POWER STANDBY SW PCB+ CONNECTION PCB) PACKING PARTS LIST PARTS No PARTS NAME 55383360 Carton box, DV-CP500 55184410 Pad Right, same as DPC503 55184420 Pad Left, same as DPC503 55176530 Audio connection cable...
- Page 54 55020130 METAL MAGNETIC HOLDER 55371790 MOLD BRACKET DVD 55371890 PLASTIC CLAMPER DVD 55438160 FREXIBLE FLAT CABLE, RIBBON 22 55371920 METAL YOKE PUCK 55472730 BRACKET BASE PICK-UP 55472540 RUBBER SUPPORT 15*30*3 55491450 RUBBER 16X8X2T CDM5G -- 55491580 RUBBER FELT YOKE 55178960 SPRING PLATE SPRING 5000 55183130...
-
Page 55: Printed Circuit Board Parts List
IC001 55183090 or MOTOR KA3082 SIP10 or IC001 20458950 MOTOR BA6209N IC002 20458950 or BA6209N MOTOR CONT or IC002 20656300 or LB1641 MOTOR CONT or IC002 55183090 KA3082 MOTOR DRIVER DIODE D001 20414280 D-ZENER 1N5232B 5.6V D002 20414280 D-ZENER 1N5232B 5.6V PI001 20586840 or DIODE PHOTO ITR9606/F2(T) or... - Page 56 CN92 55182990 5P 220MM UL1007 PVC DISCRETE 26 CN93 55199600 2P 40MM UL1007 RIBBON 26 CN96 55199610 4P 70MM UL1007 RIBBON 26 PLUG WAFER CN94 55123320 2.0MM 5 MA ST NAT LW2002P05 CN95 55123320 2.0MM 5 MA ST NAT LW2002P05 CP93 55090070 2.0MM 2 MA ST NAT LW2002P0200T...
- Page 57 S901 55145270 50MI0A 12.0V 500MI0OHM 1T 1P S903 55145270 50MI0A 12.0V 500MI0OHM 1T 1P S905 55145270 50MI0A 12.0V 500MI0OHM 1T 1P S907 55145270 50MI0A 12.0V 500MI0OHM 1T 1P S911 55145270 50MI0A 12.0V 500MI0OHM 1T 1P S913 55145270 50MI0A 12.0V 500MI0OHM 1T 1P S915 55145270 50MI0A 12.0V 500MI0OHM 1T 1P...
- Page 58 C12S 20288040 100N0F +80% -20% 16.0V Y5V, Chip C12Y 20288040 100N0F +80% -20% 16.0V Y5V, Chip C130 20269020 100U0F +20% 16.0V 85C, Elect C131 10138960 10N0F +10% -10% 50.0V X7R, Chip C132 20288040 100N0F +80% -20% 16.0V Y5V, Chip C133 20288040 100N0F +80% -20% 16.0V Y5V, Chip C134...
-
Page 59: Flexible Flat Cable
C604 10138390 560P0F +10% -10% 50.0V X7R, Chip C605 20506540 10P0F +0P5F -0P5F 50.0V NP0, Chip C606 15002130 10U0F +20% 16.0V 85C, Elect C607 10138390 560P0F +10% -10% 50.0V X7R, Chip C608 20268940 100U0F +20% 10.0V 85C, Elect C609 20506540 10P0F +0P5F -0P5F 50.0V NP0, Chip C610 20506540... - Page 60 IC21 55403940 STI5518MVB MPEG VIDEO DECODER IC22 20940740 EEPROM M24C02WMN6 IC31 55156290 DRAM 64M(1M*16*4) HY57V651620BTC-8 IC31 55156420 DRAM 100M0 HZ 8N0 64M(1M*16*4) K4S641632D IC31 55236130 DRAM 100M0 HZ 6N0 64M(1M*16*4) HY57V641620HGT-H IC41 55136720 IC-MEMORY FLASH M29W800AT90N1 IC41 55177660 MEMORY FLASH SST39VF800A-90-4C-EK IC41 55177670 MEMORY FLASH TMS29LF80...
- Page 61 R103 10134650 47R0 OHM +5% 62MI5W, Chip R104 10134650 47R0 OHM +5% 62MI5W, Chip R105 10134650 47R0 OHM +5% 62MI5W, Chip R106 10134650 47R0 OHM +5% 62MI5W, Chip R107 10134650 47R0 OHM +5% 62MI5W, Chip R108 10134650 47R0 OHM +5% 62MI5W, Chip R109 10134650 47R0 OHM +5% 62MI5W, Chip...
- Page 62 R15R 10134950 680R0 OHM +5% 62MI5W, Chip R16B 10135180 36K0 OHM +5% 62MI5W, Chip R16G 10135180 36K0 OHM +5% 62MI5W, Chip R16R 10135180 36K0 OHM +5% 62MI5W, Chip R17B 10135960 5K6 OHM +5% 62MI5W, Chip R17G 10135960 5K6 OHM +5% 62MI5W, Chip R17R 10135960 5K6 OHM +5% 62MI5W, Chip...
- Page 63 R247 10135840 1K8 OHM +5% 62MI5W, Chip R248 10134650 47R0 OHM +5% 62MI5W, Chip R249 10134650 47R0 OHM +5% 62MI5W, Chip R24B 21073400 13K7 OHM +1% 62MI5W, Chip R24G 21073400 13K7 OHM +1% 62MI5W, Chip R24R 21073400 13K7 OHM +1% 62MI5W, Chip R250 10328750 0 OHM +0% 62MI5W, Chip...
- Page 64 R315 10135220 47K0 OHM +5% 62MI5W, Chip R401 10134650 47R0 OHM +5% 62MI5W, Chip R402 10134650 47R0 OHM +5% 62MI5W, Chip R403 10134650 47R0 OHM +5% 62MI5W, Chip R404 10134650 47R0 OHM +5% 62MI5W, Chip R405 10135010 10K0 OHM +5% 62MI5W, Chip R406 10135010 10K0 OHM +5% 62MI5W, Chip...
- Page 65 RA43 55129820 47R0 OHM +5% 62MI5W 4 RA44 55129820 47R0 OHM +5% 62MI5W 4 RA45 55129820 47R0 OHM +5% 62MI5W 4 RA46 55129820 47R0 OHM +5% 62MI5W 4 RA47 55129820 47R0 OHM +5% 62MI5W 4 RA48 55129820 47R0 OHM +5% 62MI5W 4 VR11 55307870 PR 200R0 OHM +30% 100MI0W...
-
Page 66: Disassembly Procedure
DV-CP500 DISASSEMBLY PROCEDURE Replacement of DVD mechanism The laser diode in the optical pickup block so sensitive to static electricity, surge current and etc.. That the components are liable to be broken down or its reliability remarkable deteriorated. During repair, carefully take the following precautions. -
Page 67: Packing View
DV-CP500 PACKING VIEW RC-502DV... - Page 68 DV-CP500 FW DOWNLOAD Confirm the firmware "CD PLAY" button and "DISC 3" button on the front panel should be pressed at the same time. --------- Factory EEPROM reset. Wattching the version of firmware in the FL tube. When the name of the binaly file you wantto downloding is "dvcp5111.bin", you may type "ttcmake cp500fw1"...
- Page 69 Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8111 Fax: 072-833-5222 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 E-mail: onkyo@onkyousa.com ONKYO EUROPE ELECTRONICS GmbH Industriestrasse 20, 82110 Germering, GERMANY Tel: 089-849-320 Fax: 089-849-3265 E-mail: info@onkyo.de...
