DV-CP702 DVD Changer Page 1 Tuesday, February 10, 2004 10:12 AM
DVD Changer
DV-CP702
Instruction Manual
Thank you for purchasing an Onkyo DV-CP702 DVD
Changer. Read this manual carefully before using your
new DVD Changer. A good understanding of its features
and operation will allow you to achieve optimum perfor-
mance and enjoyment.
Keep this manual for future reference.
Contents
Precautions ....................................... 4
Introduction ....................................... 6
Controls & Connectors ................... 10
Connecting the DV-CP702 .............. 16
Components ................................. 19
DV-CP702 ....................................... 20
Basic Playback ................................ 21
Advanced Playback ........................ 31
Configuring the DV-CP702 ............. 38
Troubleshooting .............................. 45
Specifications ................................. 47
