DVD Changer
DV-CP701
Instruction Manual
Thank you for purchasing the Onkyo DV-CP701 DVD
Changer. Read this manual carefully before using your
new DVD Changer. A good understanding of its features
and operation will allow you to achieve optimum perfor-
mance and enjoyment.
Keep this manual for future reference.
Contents
Precautions ....................................... 4
Introduction ....................................... 6
Controls & Connectors ................... 10
Connecting the DV-CP701 .............. 16
Components ................................. 19
DV-CP701 ....................................... 20
Basic Playback ................................ 21
Advanced Playback ........................ 31
Configuring the DV-CP701 ............. 38
Troubleshooting .............................. 45
Specifications ................................. 47
E
n

Advertisement

Table of Contents
loading

Related Manuals for Onkyo DV-CP701

Summary of Contents for Onkyo DV-CP701

  • Page 1: Table Of Contents

    DVD Changer DV-CP701 Instruction Manual Thank you for purchasing the Onkyo DV-CP701 DVD Changer. Read this manual carefully before using your new DVD Changer. A good understanding of its features and operation will allow you to achieve optimum perfor- mance and enjoyment.
  • Page 2 Connecting Your Hi-Fi Amp ...18 Connecting for Dolby Digital or DTS ...18 Connecting -compatible AV Components..19 Connection Diagram ...19 Powering Up & Setting Up the DV-CP701...20 Powering Up the DV-CP701 ...20 First Time Setup...20 Basic Playback...21 Loading & Removing Discs...21 Loading Discs During Playback ...21...

  • Page 3: Important Safety Instructions

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

  • Page 4: Precautions

    Precautions DANGER: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK FAILED OR DEFEATED. DO NOT STARE INTO BEAM. CAUTION: THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCE- DURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
  • Page 5 To maintain the best picture quality, we recommend regular inspection and maintenance (cleaning or worn part replacement) every 1,000 hours of use depending on the operating environment. Contact your Onkyo dealer for details. 11. Moisture Condensation Moisture condensation may damage this unit.

  • Page 6: Introduction

    • Last Memory function allows you to resume playback from a specific point on a DVD-Video disc or Video CD, even if that disc has been removed from the DV-CP701 • Repeat playback options include: Chapter, Title, 1 Disc, All Discs, Track, and Folder (MP3/WMA) •...

  • Page 7: Disc Notes

    CD standard. Since these are nonstandard discs, they may not play properly in the DV-CP701. *3. The DV-CP701 supports CD-R and CD-RW discs recorded in Video CD format, audio CD format, or ISO9660 Level 2 format with MP3, WMA, and JPEG files.
  • Page 8 • The folder numbered “001” appears as “ROOT” in the Disc Navigator. • The DV-CP701 supports up to 999 folders and up to 672 files per folder. • If you try to play an incompatible file, the message “This for- mat cannot be played”...

  • Page 9: Dv-Cp701-Related Terminology

    Macrovision Corporation. Reverse engineering or disassembly is prohibited. DV-CP701-related Terminology ■ CD-R (compact disc recordable): be recorded only once. Can be used to make Video-CDs, audio CDs, or MP3/WMA/JPEG discs.

  • Page 10: Controls & Connectors

    H I J K For detailed information, refer to the pages in parenthesis. STANDBY/ON button (20) This button is used to set the DV-CP701 to On or Standby. Don’t turn on the power until you’ve completed, and double checked all connections (page 16).

  • Page 11: Display

    When the disc tray is closed, all of the disc indicators appear until the DV-CP701 has checked each bay for the presence of a disc. If a bay is found to have no disc, the corresponding indicator disappears.

  • Page 12: Rear Panel

    AV receiver, or surround sound decoder (Dolby Pro Logic). REMOTE CONTROL (19) These (Remote Interactive) connectors can be con- nected to the connectors on your other Onkyo AV components for interactive control. COAXIAL AUDIO OUTPUT DIGITAL...

  • Page 13: Remote Controller

    RC-542DV For detailed information, refer to the pages in parenthesis. STANDBY button (20) This button is used to set the DV-CP701 to Standby. ON button (20) This button is used to turn on the DV-CP701. Don’t turn on the DV-CP701 until you’ve completed, and double checked all connections (page 16).
  • Page 14 Controls & Connectors—Continued REPEAT button (31) This button is used to set the Repeat Playback functions. A–B button (32) This button is used to set the A–B Repeat Playback func- tion. RANDOM button (32) This button is used with the Random Playback function. DISPLAY button (37) This button is used to display information about the cur- rent disc, title, chapter, or track, including the elapsed...

  • Page 15: Before Using The Dv-Cp701

    • Flat batteries should be removed as soon as possible to pre- vent possible leakage and corrosion. Using the Remote Controller To use the remote controller, point it at the DV-CP701’s remote control sensor, as shown below. Remote control sensor 30˚...

  • Page 16: Connecting The Dv-Cp701

    Connecting the DV-CP701 This chapter explains how to connect the DV-CP701 to your other AV components. Before Making Any Connections • Read the manuals supplied with your AV components. • Don’t connect the power cord until you’ve completed all audio and video connections.

  • Page 17: Connecting Your Tv Or Projector

    Connecting the DV-CP701—Continued Connecting Your TV or Projector This section explains how to connect the DV-CP701 to your TV or projector. In this hookup example, the TV handles the audio and video. If your TV has a Dolby Pro Logic decoder built-in, you’ll be able to enjoy DVDs and videos that bear the Dolby Surround logo.

  • Page 18: Connecting Your Hi-Fi Amp

    Connecting the DV-CP701—Continued Connecting Your Hi-Fi Amp This section explains how to connect the DV-CP701 to a ste- reo hi-fi amp or receiver for better sound quality than that of most TVs. This is ideal for playing your audio CDs and MP3/ WMA discs in the DV-CP701.

  • Page 19: Connecting

    ■ Auto Power On If your DV-CP701 is connected to an AV receiver, when you turn on the DV-CP701, the AV receiver will turn on and select the DV-CP701 as the input source. ■ Auto Source Select If your DV-CP701 is connected to an AV receiver, when you start playback on the DV-CP701, the AV receiver will select the DV-CP701 as the input source.

  • Page 20: Powering Up & Setting Up The Dv-Cp701

    Remote controller Remote controller Remote controller Remote controller Your DV-CP701 is now ready for use. See page 21 for infor- mation on loading discs, and page 22 for information on selecting and playing discs. Notes: • You can change the language of the onscreen setup menus,...

  • Page 21: Basic Playback

    SETUP to load or remove your discs. (The disc tray may take sev- AUDIO ANGLE SUBTITLE eral seconds to open.) • The DV-CP701 supports 8 cm and 12 cm discs. To avoid DISC 1 DISC 2 DISC 3 STEP/SLOW damaging your discs or DV-CP701, always place discs in...

  • Page 22: Selecting Discs

    • The type of disc currently selected is shown on the display: DVD, VCD, or CD (see page 11). • You can select discs while the DV-CP701 is stopped or dur- ing playback. • You can use the [DISC SKIP] button to skip the current disc and start the next disc.
  • Page 23 To prevent this, don’t keep playback paused for too long and always press the Stop [ ] button when you’ve finished playing a DVD-Video disc or Video CD. Your DV-CP701 features a screen saver to protect your TV from the effects of burn-in (see page 43).

  • Page 24: Navigating Disc Menus

    Basic Playback—Continued STANDBY OPEN/ CLOSE SEARCH LAST M MEMORY CHAIN MODE CLEAR TOP MENU TOP MENU ENTER ENTER RETURN RETURN AUDIO ANGLE SUBTITLE AUDIO DISC 1 DISC 2 DISC 3 DISC 4 DISC 5 DISC 6 DISC SKIP PROGRESSIVE DIMMER RC-521DV Navigating Disc Menus DVD-Video discs usually have an onscreen menu from...

  • Page 25: Selecting Titles & Chapters By Number

    Basic Playback—Continued SEARCH Number buttons PLAY/ENTER Selecting Titles & Chapters by Number This section explains how to select chapters, titles, and discs by number. Load and select a DVD-Video disc. See page 21 and page 22. Press the [SEARCH] button. The Disc Navigator Search window Remote controller appears onscreen, as shown.

  • Page 26: Using The Disc Navigator

    See page 21 and page 22. The Disc Navigator appears, as shown. Disc Navigator disc MODE Folder ROOT 001.ONKYO 002.RUN Select ENTER Back to previous RETURN The number of the currently selected disc is shown on the disc icon. The Folder col- umn lists the folders.

  • Page 27: Memory Playback In The Disc Navigator

    Basic Playback—Continued Memory Playback in the Disc Navigator JPEG You can compile a playlist of tracks and folders in the Disc Navigator as follows. With the Disc Navigator open, press the [MEMORY] button. Remote controller The playlist appears in place of the file MEMORY information.

  • Page 28: Selecting Tracks By Number

    Basic Playback—Continued SEARCH Number buttons PLAY/ENTER Selecting Tracks by Number This section explains how to select tracks by number. Load and select a Video CD, audio CD, or MP3/WMA disc. See page 21 and page 22. Press the [SEARCH] button during playback.

  • Page 29: Frame-By-Frame Playback

    TV screen called screen burn- in. To prevent this, don’t display the same frame for too long. Your DV-CP701 features a screen saver to protect your TV from the effects of burn-in (page 43). Slow-motion Playback With the Slow-motion Playback function you can watch a scene slowly either forward or backward.

  • Page 30: Using Jpeg Cds

    CHAIN MODE STOP PLAY/ENTER Using JPEG CDs The DV-CP701 supports JPEG CDs, so you can view your photos on TV either individually or as a slideshow. Load and select a CD containing JPEG pictures. See “Using the Disc Navigator” on page 26, and follow the procedure up to step 4 so that the first nine pictures are dis-...

  • Page 31: Advanced Playback

    Advanced Playback REPEAT STANDBY OPEN/ CLOSE SEARCH LAST M MEMORY CHAIN MODE SEARCH REPEAT Number buttons RANDOM DISPLAY CLEAR TOP MENU MENU ENTER RETURN SETUP AUDIO ANGLE SUBTITLE DISC 1 DISC 2 DISC 3 STEP/SLOW Locating Specific Points in Time With the Time Search function you can locate specific points in time.

  • Page 32: A-B Repeat Playback

    Advanced Playback—Continued SEARCH PLAY/ENTER A–B Repeat Playback With the A–B Repeat Playback function you can play a spec- ified section over-and-over again. During playback, press the [A–B] button to set the A point (i.e., the Remote controller start of the section you want to A - B repeat).

  • Page 33: Memory Playback

    Advanced Playback—Continued STANDBY OPEN/ CLOSE SEARCH LAST M MEMORY CHAIN MODE REPEAT Number buttons RANDOM DISPLAY CLEAR TOP MENU MENU ENTER ENTER RETURN SETUP AUDIO ANGLE SUBTITLE ANGLE DISC 1 DISC 2 DISC 3 STEP/SLOW Memory Playback JPEG With the Memory Playback function you can create your own memory list of titles, chapters, and tracks.

  • Page 34: Selecting Camera Angles

    Remote controller ton. MEMORY Notes: • The entire memory list is cleared when the DV-CP701 is set to Standby. • With PBC Video CDs, you can’t use this function. Cancel PBC playback first, and then set this function. • A playlist of MP3/WMA files can be made using the Disc Navigator (see page 26).

  • Page 35: Selecting Languages & Audio Formats

    With the Progressive Scanning function you can enjoy better picture quality. To use Progressive Scanning, your TV or pro- jector must support progressive scanning and you must con- nect it to the DV-CP701’s component video outputs (see page 17). Remote controller...

  • Page 36: Using Last Memory

    • The Last Memory function may not work with some DVD-Video discs. • Even if you select another disc, or inadvertently turn off the DV-CP701 during playback, you can resume playback from the same point when you select the disc again. Memory Clear To resume playback from last mem- ory point, select “Yes,”...

  • Page 37: Displaying Information

    Advanced Playback—Continued Displaying Information You can display various information about the current disc, title, chapter, or track as follows. During playback, press the [DIS- PLAY] button. Various information appears onscreen. The operating status (e.g., Stop, Play, Resume), disc number, and disc type Remote controller information is displayed along the top of the screen.

  • Page 38: Configuring The Dv-Cp701

    Adjust the picture quality for progressive scanning. Specify how the DV-CP701 outputs video signals when playing NTSC discs. Dolby Digital Out Select whether or not the DV-CP701 downmixes Dolby Digital digital audio. Linear PCM Out Select whether or not the DV-CP701 downsamples 96 kHz digital audio.

  • Page 39: Using The Onscreen Setup Menus

    DISC 3 STEP/SLOW Using the Onscreen Setup Menus This section explains how to use the onscreen setup menus. Turn on your DV-CP701 and TV. On your TV, select the video input to which the DV-CP701 is connected. Press the [SETUP] button.
  • Page 40 DISC 3 STEP/SLOW Notes: • These settings are used only when the Progressive function PAL Output Setting (Australian model only) With this setting you can specify how the DV-CP701 outputs video signals when playing NTSC format or Video CDs. Notes: •...

  • Page 41: Audio Menu

    Configuring the DV-CP701—Continued Audio Menu Digital Out With these settings you can specify how the DV-CP701 out- puts digital audio signals. The options you choose will depend on the type of AV component that you connect to the DV-CP701’s digital audio outputs.

  • Page 42: Display Menu

    Sapphire (default): Pearl: Amethyst: Garnet: Background With this setting you can select the color of the background that’s displayed when the DV-CP701 is stopped. Blue: Gray: The theme picture specified for the Graphic (default): On-Screen Display Color setting is used.

  • Page 43: Operation Setting Menu

    STOP [ ] button four times. • When using a disc that uses parental control to restrict playback, occasionally, depending on the DV-CP701’s operating status, you may not be able to remove the disc by using the [OPEN/CLOSE] button. If this does occur, close the disc tray, use the [DISC SKIP] button to select another disc bay, open the tray again, and then remove the disc.

  • Page 44: Initial Setup Menu

    Auto Power Off function on. Initial Setup Menu This menu appears automatically the very first time you turn on the DV-CP701. See “First Time Setup” on page 20 for more information. Selecting Other Languages This section explains how to select other languages for disc menus, audio, and subtitles.

  • Page 45: Troubleshooting

    Remedy Connect the power cord to a suitable wall outlet (page 20). Turn off the DV-CP701, wait five seconds, then try turning it on again. If that fails, disconnect the power cord from the wall outlet, wait five seconds, reconnect it, then try turning it on again.
  • Page 46 ■ Restoring the Default Settings To reset the DV-CP701 to its factory defaults, turn it on and, while holding down the STOP [ ] button, press the [STANDBY/ ON] button. “INITIALIZE” appears on the display. When the reset is complete, “COMPLETE” is displayed, and the DV- CP701 enters Standby mode.

  • Page 47: Specifications

    Specifications Video system Region code Laser DVD linear audio Frequency response CD audio Signal-to-noise ratio (digital audio) Audio dynamic range (digital audio) Harmonic distortion (digital audio) Wow and flutter Temperature Operating conditions Installation COMPONENT VIDEO Video outputs S VIDEO (S-Video) VIDEO (composite video) OPTICAL Audio outputs...
