Newline DV One+

Quick Start Guide

DV-13524-PLUS

Table of Contents

Need help?

Do you have a question about the DV One+ and is the answer not in the manual?

Questions and answers

Summary of Contents for NewLine DV One+

Page 1 Newline DV One+ Quick Start Guide DV-13524-PLUS...
Page 3: Table Of Contents
1.3.1 Air mouse pairing 2 Installation Guide 2.1 Precautions 2.1.1 Attention 2.1.2 Unpacking 2.2 Wall-mounted Installation 2.2.1 Installation Dimensions 2.2.2 Installation Steps 2.2.3 Installing the Wi-Fi Module 2.2.4 Pull-out drawer maintenance 3 Power On/Off 3.1 Power On 3.2 Power Off newline-interactive.com...
Page 4: Safety Instructions
DO NOT place fire or any device that gives off high heat around the display. Please use original Newline accessories. If you need to use self-purchased accessories, please consult customer service. Arrange professional personnel to inspect the screen regularly.
Page 5: Important Warning
Attention: POWER SUPPLY. When wiring power supply, please pay attention to load balance, overload is strictly prohibited. Before installation, please ensure that the operating voltage of the display is suitable for the local grid voltage. newline-interactive.com...
Page 6: Unpacking
Danger: Failure to take appropriate protective measures may result in death or serious personal injury. Caution: Failure to take appropriate protective measures may result in minor personal injury. Attention: If corresponding protective measures are not taken, it may lead to unexpected results. newline-interactive.com...
Page 7: Documentation
This article is applicable to Newline DV One +. Copyright Notice Newline reserves the right to make changes to this product manual without prior notice. We are not responsible for any direct, indirect, intentional or unintentional damages or hidden dangers caused by not following the product manual for installation or improper use.
Page 8: Product Overview
DV-13524-Plus All-in-One Direct View LED Display 1 Product Overview 1.1 Appearance and Introduction This product is shown in the following figure. Some features have been simplified. Front View Rear View newline-interactive.com...
Page 9: Keys And Interfaces Introduction
Function Description Signal source switch key Used to switch video sources volume - Used for volume reduction volume + Used for volume increase Brightness adjustment key Used for brightness adjustment, 1%~100% cycle Power Key Used for switching on/off the device newline-interactive.com...
Page 10 RJ45 network interface Used for networking HDMI OUT interface Used for video output, 1080p mode RS232 interface Used for achieving centralized control HDMI 2(ARC) interface Used for external device video access USB3.0 interface Used for connecting to USB device newline-interactive.com...
Page 11: Remote Control Introduction
1 Hold the volume - and brightness - buttons simultaneously for 5 seconds to enter pairing mode; the remote control indicator light will flash; 2 Search for DYC-Q5 in the initial pairing page or Setting > Network > Bluetooth for pairing. newline-interactive.com...
Page 12: Installation Guide
Verify that the goods shipped contains the complete device and accessories you ordered separately. If there is any discrepancy or damage during transportation, please contact customer service. The product should not be exposed to the installation site under construction for a long time after unpacking. newline-interactive.com...
Page 13: Wall-Mounted Installation
2.2 Wall-mounted Installation 2.2.1 Installation Dimensions DV-13524-PLUS 3009mm(118.46 in) 30mm(1.18 in) 61mm(2.4 in) 840mm(33.07 in) LED Display Walls newline-interactive.com...
Page 14: Installation Steps
8mm hexagon wrench/ A1 x8 B1 x2 Ratchet Hex Key Wrench Upper wall-mounting bracket 135 L（Left） 135 UR（Right） lower wall-mounting bracket 135 L（Left） 135 DR（Right） Show the final assembly diagram Upper wall-mounting bracket newline-interactive.com...
Page 15 The lower mounting bracket must not be less than 280 mm above the ground. The upper mounting bracket shall have a clearance of 450 mm above and 400 mm to the right. A2 X15 A3 x15 screwdrivers Wall 1490 1490 1039 1490 Power plug (2 x 15A) Ground Unit:mm newline-interactive.com...
Page 16 D columns, and finally, hang the A and E columns. Be sure to connect the power cord (see reference diagram below) before hanging the F-column cabinet (with pull-out box): Load-bearing Screws Make sure that the load-bearing screws snap into the notches of the wall bracket. newline-interactive.com...
Page 17 Insert the A5 Hexagon socket bolts from right to left into the connection between the two cabinets, and then tighten them with a wrench. Ensure that the adjacent cabinets are flush, as shown in the diagram. A5 x 40 6mm hexagon wrench/Ratchet Hex Key Wrench newline-interactive.com...
Page 18 Network Cable 1 connects to Column E1; Network Cable 2 connects to Column D1; Network Cable 3 connects to Column C1; Network Cable 4 connects to Column B1; Network Cable 5 connects to Column A1. Insert to the left network ports newline-interactive.com...
Page 19 Step 3. Connect the power lines, numbered Line 1-5, to the E1-A1 cabinet in sequence: Connecting the brown wire to the IN 1 terminal; Connecting the blue wire to the IN 2 terminal; Connecting the yellow-green ground wire to the ground of the cabinet. Yellow-green wire Brown wire(IN 1) Blue wire(IN 2) newline-interactive.com...
Page 20 Secure the lower frame using A6 Hexagon socket bolts from top to bottom. Secure the lower-right frame first, then the lower-left frame, ensuring that the installation is flush. A6 x8 4mm hexagon wrench/Ratchet Hex Key Wrench newline-interactive.com...
Page 21 Move the ball plungers near to the screw hole marks marked by the lines as shown in the diagram. A7 x15 Screw hole Marking Next, insert the corner covers into the left side of the upper left frame and the right side of the upper right frame, as indicated by the figure. newline-interactive.com...
Page 22 Then, take the top frame and press the corner cover into the slots of the side frame. Finally, secure the left frame, the right frame and the top frame from the inside of the cabinet outward with A8 Hexagon socket bolts. A8 x15 6mm hexagon wrench/Ratchet Hex Key Wrench newline-interactive.com...
Page 23 XA1-1 XA1-2 XB1-1 XB1-2 XC1-1 XC1-2 XD1-1 XD1-2 XE1-1 XE1-2 Notes After the installation of the LED Panel, if there is a gap or segment difference, you can adjust the screws on the cabinet (corresponding position) to adjust the height of the LED Panel. newline-interactive.com...
Page 24 LEDs. Step 5: Pull the handle on the suction cup down to release the LED Module. newline-interactive.com...
Page 25: Installing The Wi-Fi Module
Step 2: Insert the Wi-Fi Module into the port on the rear of the LED display until firmly seated, using the 2 screws to secure it. Slideway The silver backplane must be stuck to the slideway Insert WiFi module with black fins outward newline-interactive.com...
Page 26: Pull-Out Drawer Maintenance
Step 1: Unscrew the screws on the pull-out drawer; Step 2: Pull the handle to pull out the pull-out drawer. newline-interactive.com...
Page 27: Power On/Off
1 Ensure the two power cables are fully seated into the LED display and wall outlet before powering on the LED display. Notes The power outlet should be installed near the LED display and should be easily accessible. 2 Press the power button on the front panel or on the remote control. newline-interactive.com...
Page 28: Power Off
Please properly shut down the LED display before disconnecting the power source or it may cause damage. Accidental power failure may cause damage to the LED display. Do not repeatedly turn the power on & off in a short period of time as it may cause malfunction. newline-interactive.com...
Page 29 newline-interactive.com...
Page 30 For More Information Please visit our website (https://newline-interactive.com) and select your regional website. Once there, navigate to the Support section and click on Downloads to download the User Manual for detailed instructions. Contact Us for Support Please directly contact the support team within your region.
