USER MANUAL
Product Code:
Serial Number Range:
From:
To:
Year Of Manufacture: 2023
*Please note, when ordering online via our website if the part number is not recognised,
please Email spares@hscgroupuk.co.uk or Telephone 0115 946 1988
KEEP THIS BOOKLET FOR FUTURE REFERENCE
Nottingham: 0115 946 1988 • London: 0208 830 3333
The Hire Supply Company Terms & Conditions Apply At All Time E&OE
240v 7.1kw
Spot Cooler
FSC25
Nottingham: sales@hscgroupuk.co.uk • London: sean@hscgroupuk.co.uk
www.hscgroupuk.co.uk
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fral FSC25.4.3000
Summary of Contents for Fral FSC25.4.3000
- Page 1 USER MANUAL 240v 7.1kw Spot Cooler Product Code: FSC25 Serial Number Range: From: Year Of Manufacture: 2023 *Please note, when ordering online via our website if the part number is not recognised, please Email spares@hscgroupuk.co.uk or Telephone 0115 946 1988 KEEP THIS BOOKLET FOR FUTURE REFERENCE Nottingham: 0115 946 1988 •...
- Page 2 Condizionatore d’aria locale Portable Air Conditioner Tragbare Klimaanlage Climatiseur portable Aire acondicionado portátil FSC25 Manuale Tecnico - Technical Manual - Technische handleiding Manuel technique - Manual técnico M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
- Page 3 Modello e/o tipo: Model and/or Type: Modell und/oder Typ: FSC25 Modèle et/ou type: Modelo y/o tipo: Model og/eller type: Descrizione: CONDIZIONATORE D’ARIA LOCALE Description: PORTABLE AIR CONDITIONER Beschreibung: TRAGBARE KLIMAANLAGE Descripción: CLIMATISEUR PORTABLE M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
- Page 4 Data di pubblicazion Data di Titolo Titolo pubblicazione Date of Date of standard/spec standard/specific Title: ification Title: ation Veröffentlichu Veröffentlichungs Titel: ngsdatum: Titel: datum: Date de Date de Titre: publication: Titre: publication: M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
- Page 5 Carmignano di Brenta, 15/09/2022 (Managing Director) Luogo e data di rilascio Place and date of issue Ort und Datum der Ausstellung Lieu et date de délivrance Lugar y fecha de emisión Sted og dato for udstedelse M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
-
Page 6: English Manual
Appropriate separate collection for the subsequent forwarding of the decommissioned product to recycling, treatment and environmentally compatible disposal helps prevent negative impact on the environment and on health and promotes the reuse and / or recycling of the materials making up. M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023... - Page 7 Warning: This appliance must always be connected using plugs with a grounding cable, as required for all electrical applications; FRAL declines all responsibility for any danger or damage caused if this rule is not respected.
- Page 8 In the case of refrigerant gas refilling, the use of appropriate gloves is mandatory to avoid the risk of freezing. Mask and glasses: during cleaning and maintenance operations, respiratory protection masks and eye protection goggles must be used. M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
- Page 9 The unit reports the following safety signs, which must be respected: Read technical manual Read user’s manual Read operator’s manual Danger of electric shock Flammable material hazard Warning: It is strictly forbidden to remove the safety signs present in the unit. M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
-
Page 10: General Description Of The Unit
The refrigerant gas used in these units is R1234yf. The refrigerant circuit is made in compliance with current standards Flammable material hazard This unit is hermetically sealed and contains R1234yf fluorinated gas. GWP ( R1234yf ) = 4 M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023... -
Page 11: Preliminary Operations
Positioning Place the device in order to guarantee an adequate air flow. Warning: Make sure the device is positioned so that it does not come into contact with water. M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023... -
Page 12: Service Area
Warning: Check that the power supply voltage corresponds to the unit nominal data (voltage, frequency) shown on the plate on the unit. The power connection is via plug with cable. Attention: Grounding is mandatory. M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023... - Page 13 LED ALARM: This LED, if lit, indicates the presence of an alarm. The display will show the error message. LED VENT: This LED if on indicates that the unit is operating in ventilation only. M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
- Page 14 LED ALARM: This LED, if lit, indicates the presence of an alarm. The display will show the error message. LED VENT: This LED if on indicates that the unit is operating in ventilation only. M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
- Page 15 HOUR COUNTER: Press the HOURS button to view the operating hours. HOURS+FAN SPEED: Press the buttons HOURS+FAN SPEED for 4 seconds, when the machine is supply, to activate the remote control. Once the remote control is active the led REMOTE lit. M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
- Page 16 Disconnect the unit from the power supply and reconnect it. + “LoPS” If the alarm persists, contact your authorised service centre. Fixed drain connection A fixed condensate drain can be connected to the tank. 16mm hose connection. M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
-
Page 17: Spare Parts
The unit must be assigned to special specialized centres for the collection and disposal of equipment containing dangerous substances. The refrigerant and the lubricating oil contained in the circuit must be recovered, in accordance with the regulations in force in your country. M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023... - Page 18 Markings and graphic signs that are illegible must be correct; M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
- Page 19 / or hot work, conventional procedures can be followed. If, on the other hand, interventions involving the use of ignition sources and / or hot work must be carried out, M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
- Page 20 Depressurize the cooling system, if possible. e) If the vacuum cannot be obtained, connect a manifold so that the refrigerant fluid can be removed from various parts of the system. M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
- Page 21 Only electric heating to the compressor body must be used to speed up this process. Draining the oil from a system must be done safely. M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
- Page 22 Ø 400 mm Sortie d'air chaud Salida de aire caliente Uscita aria fredda (standard) Cold air outlet (standard) Kaltluftaustritt (Standard) 2 x Ø 135 mm Sortie d'air froid (standard) Salida de aire frío (estándar) M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
- Page 23 Ø 300 mm Sortie d'air froid (accessoire) Salida de aire frío (accesorio) Dimensioni LxPxH Dimensions LxDxH Dimensions (wxdxh) 790x620x1326 mm Dimensiones wxdxh Dimensiones wxdxh Peso netto Weight with Nettogewicht 98 kg Poids net Peso neto M.FSC25.4-05 Manual FRAL _ITA_UK_DE_FR_ES - 28/04/2023...
- Page 27 Recycling ENVIRONMENTAL PROTECTION: Please recycle any unwanted materials as opposed to disposing them as general waste. It is recommended the original is retained and used to store the product when not in use for prolonged periods of time. If this is not applicable ensure the materials are sorted and recycled in accordance with local regulations.
