TJM 780STKIT69J Fitting Instructions

Product:
Vehicle:
780STKIT69J
• Before commencing fitment read instructions and ensure all listed
components are supplied.
• Estimated Fitting Time: 2hrs
• Left hand and right hand components are determined as seated in the
vehicle.
• The fitment of TJM products does not nullify the OE manufacturer's
operating guidelines and/or warnings. Ensure you are familiar with and
adhere to the usage instructions specified by the manufacturer in the
owner's manual or other official documentation.
• Check for (and remove) any build up in all threads fitted to the product.
• When removing protective coatings, ensure all new edges are deburred,
clean any swarf from the area and apply rust preventative to exposed
surfaces.
• Always place the product on a soft work space to prevent damage prior to
installation.
Bolt tensions
All bolt tensions
unless otherwise
For product warranty please refer to our website www.tjm.com.au
File: F-13048
FITTING INSTRUCTIONS
Dia. (mm)
5
6
are as follows
8
10
specified.
12
Modular Side Bars
MY24+ LC70
Nm ft.lbs Dia. (inch)
1/4"
5 4
5/16"
9 7
3/8"
22 16
7/16"
44 32
1/2"
77 57
