BATTEN EM KIT MANUAL & SELF
TEST 2-IN-1
107137
5
Relevant standard
IEC 61347-1
IEC 61347-2-7
EN 55015
EN 61547
EN 61000-3-2
EN 61000-3-3
EN 62493
AS/NZS 60598-2-22
AS2293.3
Dimensions
Self-test
The emergency kits carry out self-tests automatically to ensure its functionality.
The self-test includes 3 types of tests:
Initial test
- As soon as mains supply is connected, the emergency kit will carry out a 3-seconds
functional test automatically.
- In case of a failure, the LED will turn permanent red. Otherwise, the charge mode will start.
Functional test
- Refers to charging, discharging and the functioning of load.
- Carry out for 10 seconds automatically every 30 calendar days.
Duration test
- Refers to the test of batteries capacity.
- Carry out every 180 calendar days.
Rest mode
Rest mode can be initiated during emergency mode by pressing test switch longer than 3
seconds.
The rest mode will be exited automatically after reconnect AC mains.
Please note
If mains supply is off during self-test period, emergency conversion module would
terminate self-test immediately and go into emergency mode.
Self-test is under the regulation of EN 62034.
UK Manufacturer: BH17 7BY
EU Manufacturer: Brilliant AG,
Brilliantstrasse 1, D-27442 Gnarrenburg
Thank you for purchasing this product.
Please read the instruction carefully before
use to ensure safe and satisfactory
operation of this product. Please retain
these instruction for future reference.
Warranty
- Warranty 5 years. (Emergency driver and battery)
- Except for the following circumstances:
1) Improper installation or operation.
2) Misuse.
3) Abuse.
4) Unauthorized or improper repair alteration.
5) Accident or negligence in use, storage, transportation.
6) Any natural acts.
Applications
- Use in dry environment.
- LiFePO4 battery pack.
- For use on a wide range of LED fittings to convert them from standard to emergency
fitting.
- LED fitting would be maintained emergency LED fitting if standard (main powered)
driver, emergency lighting kit and battery are all retained in the circuit. LED fitting
would be non-maintained emergency LED fitting if only emergency lighting kit. And
battery are retained in the circuit.
- Additional Relay that can control standard LED driver.
- Deep discharge protection.
- Connector between emergency kit and battery has the function of polarity reversal
protection.
- Ambient range ta 0....45℃
- IP20 protection, relies on end-product enclosure for protection against accidental
contact live parts.
- Not intended for use in luminaries for high-risk task area lighting.
- Can close self test mode by dial switch.
Ordering data
DC2.5-3.5V 1W
constant power
Technical data
Rated input
Output voltage range
Max output current
Output power
Battery cells voltage
/capacity
Recharge current
Recharge time
Discharge time
Max. casing
temperature tc
Wiring diagram
EM convertor
Battery
Explanation of LED indicator
Color
LED indication
Slow flashing green
Green
(3 sec on, 1 sec off)
Green Permanent green
Fast flashing green
Green
(0.1 sec on, 0.1 sec off)
Slow flashing green
Green
(1 sec on, 1 sec off)
Red
Permanent red
Slow flashing red
Red
(1 sec on, 1 sec off)
Green and red off
Test switch
The test button is a open switch , if you press it, it connects, and then you release it, it
cuts off automatically.
When you are doing the daily maintenance , if you press the test button, the emergency
driver goes into emergency mode, if you release the button, the emergency driver will
go back to normal mode.
V1 20/05/2024
www.saxbylighting.com
E.M Power
Duration
3 Hours
LiFePO4 3.2V 1.5Ah 4.8Wh
Item
220-240VAC,50/60Hz, 20mA, 2W max
DC 2.5-3.5V
130mA
1W max
LiFePO4 3.2V 1.5Ah,4.8Wh
400mA
24hours
180 minutes
80 ºC
Manual &
Self-test Switch
Status
Comment
Charging Mode
AC mode
Fully Charged
AC mode
Function test
underway
Duration test
underway
Open circuit / Short circuit
Load failure
Led failure (emergency mode)
Battery failed the duration
Battery failure
test or function test / No battery
Battery operation
DC mode
(emergency mode)
Battery Pack
Data
