Technical data
Supply
LED
220-240V~ 50Hz
24V DC
Voltage:
Voltage:
Bulb
98998: 24W LED, 3000K / 98999: 24W LED, 4000K
Type:
99000: 144W LED, 3000K / 99001: 144W LED, 4000K / 101621: 144W LED, 6000K
99002: 48W LED, 3000K / 99003: 48W LED, 4000K
99004: 288W LED, 3000K / 99005: 288W LED, 4000K / 101622: 288W LED, 6000K
Conformity with all relevant UKCA Directive requirements.
Conformity with all relevant EC Directive requirements.
This is a Class 3 product and requires the use of a LED Driver (not supplied).
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling advice.
This product is suitable for dimming.
This product is rated at IP20.
20
IP
Care and Safety
We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the LED's.
For your safety, always switch off the power supply before changing lightbulbs, or cleaning.
V3 16/06/2022
UK Manufacturer: BH17 7BY
EU Manufacturer: Brilliant AG,
Brilliantstrasse 1, D-27442 Gnarrenburg
Instruction manual
Orion20 LED
98998, 98999, 99000, 99001, 101621
99002, 99003, 99004, 99005, 101622
www.saxbylighting.com
