Saxby Lighting 101339 Instruction Manual

Battery Replacement
If after routine operation check, the lamp does not remain lit for the three hour period, a new battery pack may be required.
• Switch off the electricity at the mains, both switched and permanent supply.
• Allow battery to fully discharge then reconnect to supply and allow to charge for 24 hours.
• Test again for 3 hours, if light does not remain lit change the battery pack as follows:
- Disconnect from the mains supply both permanent and switched supply.
- Unplug the battery male and female plugs from the EM conversion.
- Remove the battery pack. Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your local authority or retailer for recycling advice.
- Replace the battery with a LiFePO4 6.4V 1500mA, 9.6Wh only.
Use of a different type of battery will damage the product.
- Write current date on the new battery pack.
- Plug battery pack to EM conversion by male and female plugs.
- Restore power and allow to charge for 24 hours.
- Perform full operation check and update test record.
Technical data
Rated input voltage: 220-240V~, 50/60Hz
Input current: <30mA
Input power: 3W Max
Power factor: >0.5
Terminal L-in / L-out(LED driver input constant): AC 0.5A Max
Output voltage range: DC9-80V
Max output current: 100mA
Output power(constant): 2W Max
Battery cells voltage/capacity: LiFePO4 6.4V 1500mA, 9.6Wh
Conformity with all relevant UKCA Directive requirements.
Conformity with all relevant EC Directive requirements.
The power supply is Double Insulated and does not require connection to an Earth circuit.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling advice.
This product is for indoor use only.
Care and Safety
Live Voltages may be present in this unit even when turned off or when completely disconnected.
We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the finish.
For your safety, always switch off the power supply before cleaning.
V1 16/10/2023
UK Manufacturer: BH17 7BY
EU Manufacturer: Brilliant AG,
Brilliantstrasse 1, D-27442 Gnarrenburg
Recharge current: 30-70mA
Recharge time: 24hours
Discharge time: 180minutes
Lumen factor: 140lm/W
Max.casing temperature tc: 70 ºC
Battery warranty: 2 years
Operating Temperature: 0 ºC - 45ºC
Maximum Operatin Humidity: 10-90%
Change over Time: Approximately 1s
Instruction manual
EM Conversion Self Test Kit
101339
www.saxbylighting.com
Accessories
(Included)
Battery Pack
Holder for indicator
Cable with male and female plug
