2 Pre-installation Instructions
A S
NALYZER PACE
P
OWER
The MIC SAS II 5800 is designed to operate with 100-240 VAC ±10% at 50-60 Hz. Noise-free
power of the correct voltage and frequency, with a safety earth ground, should be available
through a standard wall receptacle.
The analyzer and peripheral devices must be installed on their own dedicated power
line. Other devices — such as motors, generators, or ovens — should not be placed
on the same power line.
Replacement power supply cords must be rated for the specifications stated above.
As the power jack is located on the back of the instrument, it should be placed so that
the jack is easily accessible and the instrument does not have to be moved.
2 - 2
Analyzer
Height
Width
Depth
Weight
Gas Supply
1 square ft (0.1 square m) for each gas cylinder
needed for installation. For standard
installations, the cylinders must be within 6 ft (2
m) of the instrument.
MIC SAS II 5800 Pre-installation Instructions and Checklist
50 cm (19.7 in)
44 cm (17 in)
27 cm (10.6 in)
16 kg (35 lbs)
